Автоматический гибкий шнековый конвейер из нержавеющей стали для подачи сахарного
- Категория: Material Handling Equipment >>>
- Поставщик: Botou,Ever,Lucky,Environmental,Protection,Machinery,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-19-2025 | 5950.47 $* | 6248.24 $* |
| Aug-19-2025 | 5900.86 $* | 6195.51 $* |
| Jul-19-2025 | 4950.17 $* | 5198.95 $* |
| Jun-19-2025 | 5800.47 $* | 6090.89 $* |
| May-19-2025 | 5050.95 $* | 5303.27 $* |
| Apr-19-2025 | 5700.75 $* | 5985.9 $* |
| Mar-19-2025 | 5650.99 $* | 5933.30 $* |
| Feb-19-2025 | 5600.94 $* | 5880.2 $* |
| Jan-19-2025 | 5550.51 $* | 5828.88 $* |
Характеристики
Product Description
The vertical screw conveyor
The vertical screw conveyor is a continuous conveying device that uses a forced feed screw to rotate and convey material to be lifted.LC-type vertical screw conveyor is suitable for powder,block, granular materials,such as flour, cereals,cement,fertilizer,ash, sand,stones,coal powder,1lump coal and other materials.
It is suitable for building materials, metallurgy,chemical industry,mining, machinery manufacturing,coal ash, tobacco,food,food,medicine and other industries.Due to the small flow area in the hub,the LC type vertical screw conveyor is not suitable for conveying materials that are easily degenerate, have high viscosity and are easy to be agglomerated.
Model number | LSY140 | LSY160 | LSY200 | LSY250 | LSY300 | LSY400 | ||
Screw diameter(mm) | 140 | 163 | 187 | 238 | 290 | 365 | ||
Rotating speed(r/min) | 300 | 300 | 260 | 200 | 175/300 | 175 | ||
Outer diameter(mm) | 168 | 194 | 219 | 273 | 325 | 402 | ||
Max length(m) | 11 | 12 | 13 | 16 | 18 | 18 | ||
Incline degree(α°) | 90° | 90° | 90° | 90° | 90° | 90° | ||
Conveying capacity(t/h) | 17-9 | 30-20 | 50-32 | 70-53 | 82-60/120-85 | 140-110 | ||
Motor | Model | L≤-7 | Y132S-4 | Y132S-4 | Y132M-4 | Y160L-6 | Y180M-4 | Y180M-4 |
Power(kw) | 5.5 | 5.5 | 7.5 | 11 | 18.5 | 18.5 | ||
Model | L>7 | Y132S-4 | Y132M-4 | Y160M-4 | Y180L-6 | Y180L-4 | Y180L-4 | |
Power(kw) | 5.5 | 7.5 | 11 | 15 | 22 | 22 | ||
Product Display
Product Application
Related Product
Product testing & packaging
About us
FAQ
1.How about your machine quality?
We have own research and development team,rich experiences technicians,and professional workers. We pay attention to every detail in manufacturing to ensure machines with high quality.
2.What is the status of After-sale Services for customers and machineries?
We provide the technical support for the whole life for free. Also, Engineers available to service machinery overseas. But the customers/buyer should pay for engineer salary 100$/day.
3. How to visit our company?
1.Fly to Beijing airport: By high speed train From Beijing Nan to Cangzhou Xi(1hour),then we can pick up you.
2.Fly to Shanghai Airport:By high speed train From Shanghai Hongqiao to Cangzhou Xi(4.5 hours),then we can pick up you.
3.Fly to Guangzhou aiport:By air From Guangzhou to Beijing airpot:By high speed train From Beijing Nan to Cangzhou Xi(1 hour), then we can pick up you.
4.How many years since you have been in this field?
Our company has been in this field for almost 20years. We have rich experience for manufacturing and designing the machines.
5.How can I contact you ?
Please look at my contact card. You can talk to me anytime.Or send me enquiry email, I will reply you in 24 hours and offer the optimum solution to you.
