1)Electrical connections

Input voltage: ac90-245v / 50-60hz

Rated power: 18 (W)

Power connection: power input and output

dmx connection: dmx input and dmx output

2)Optical system

Light source:18x1W(RGB)28PCS 5050 LEDS

 Life time:10 0 000 h

3) Control mode

Control: DMX512 master-slave control, auto,sound, gradual change, Jump change

Channel: 4/8 channels (digital display)

Dimming: linear dimming effect (0-100% 16Bi dimming)

Function effect: shaking the display board to control static, custom mode, 0-25Hz strobe

4) Housing

Housing: die-cast aluminum

Color:black or white

Waterproof and dustproof mirror: tempered glass

IP:IP20

Lighting wide receiver: Power line in ,dmx in and out

Cooling System: conductivity

5) Certification

CE ,ROHS

6) Working environment

-20℃~45℃

7) Package

Package size(Normal carton):51*51*37CM/20PCS

N.W.:0.5kg/pcs

G.W.:0.7g/pcs

 Guangdong Jiale Electronics Co.,Ltd is a professional stage light & studio light factory for more than 15 years,and with 30 years experienced engineers team near Guangzhou.
