Недорогой токарный станок с ЧПУ CK6140 недорогой горизонтальный
- Категория: Токарный станок с ЧПУ >>>
- Поставщик: Xuzhou,Elsen,Machine,Tool,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-20-2025 | 9996.23 $* | 10496.78 $* |
| Aug-20-2025 | 9912.78 $* | 10408.0 $* |
| Jul-20-2025 | 8316.28 $* | 8732.75 $* |
| Jun-20-2025 | 9744.84 $* | 10231.15 $* |
| May-20-2025 | 8484.81 $* | 8908.37 $* |
| Apr-20-2025 | 9576.62 $* | 10055.55 $* |
| Mar-20-2025 | 9492.15 $* | 9967.56 $* |
| Feb-20-2025 | 9408.86 $* | 9878.54 $* |
| Jan-20-2025 | 9324.34 $* | 9790.80 $* |
Характеристики
Product Description
This machine could process different inner bore, ex-circle, circular conical surface and screw thread ,especially suitable for the small and middle-size shaft and plate work piece from rough processing to finish processing in batch.it has advantage like higher automaticity, simpler programming and higher accuracy.
Specification | Unit | CK6140 |
Max.swing over bed | mm | 400 |
Max.swing over cross slide | mm | 240 |
X/Z axis travel | mm | X:280 Z:550/750/1050 |
Spindle nose | A2-6 (A2-8 opitional) | |
Spindle bore | mm | 48/82 |
Bar capacity | mm | 41/65 |
Max.spindle speed | rpm | 150-2000/150-1800 |
Chuck size | mm | 200/250 |
Spindle motor | kw | 5.5/7.5 |
X/Z axis repetability | mm | 0.005 |
X/Z axis feed motor torque | N.m | X:4 Z:6 |
X/Z Rapid traverse | m/min | X:8 Z:10 |
Tailstock quill dia | mm | 60 |
Quill traverse | mm | 100 |
Quill taper | # | MT4 |
Tool post type | 4 station electric tool holder | |
Cutting tool shape size | mm | 20*20 |
Total power capacity | kva | 11 |
Machine dimension(L*W*H) | mm | 2200*1160*1620 |
Net.weight(about) | kg | 1800 |
Standard configuration:
1) System:GSK980TC3, servo motor and drive.
2) 3-jaw manual chuck.
3) Four station electric tool post.
4) Manual tailstock.
5) Cooling system.
6) Lighting system.
7) Automatic lubrication system.
Optional configuration:
1). CNC system: GSK, Siemens, Fanuc, KND, etc.
2). Hydraulic chuck, pneumatic chuck .
3). Hydraulic tailstock, pneumatic tailstock.
4). 6-station electric tool post, 8- station electric tool post, Gang type tool
5). Automatic bar feeder.
1) System:GSK980TC3, servo motor and drive.
2) 3-jaw manual chuck.
3) Four station electric tool post.
4) Manual tailstock.
5) Cooling system.
6) Lighting system.
7) Automatic lubrication system.
Optional configuration:
1). CNC system: GSK, Siemens, Fanuc, KND, etc.
2). Hydraulic chuck, pneumatic chuck .
3). Hydraulic tailstock, pneumatic tailstock.
4). 6-station electric tool post, 8- station electric tool post, Gang type tool
5). Automatic bar feeder.
Machine Details
Related Products
Company Information
Packing&Shipping
FAQ
1: Are you a manufacture?
A: Yes,we are a real manufacture.Welcome to visit our factory!
2: What is your payment terms?
A: Our payment terms is 30% T/T in advance,70% balance T/T before shipment.
3: Can you offer customized service ?
A: Machines listed on our website are just part of our conventional models,we can also provide customized service according to your requirements.
4: How can I choose the most suitable machines ?
A: Please tell me your need specifications ,we can introduce the best model for you , or you can choose the exact model . You can also send us the products drawing ,we will introduce the most suitable machines for you .
5: Can you offer the training ?
A: Yes,we can provide a cost-free training,Teach you how to operate our machine,some common problems,and how maintain the machine etc. It would be great honor to us.
6: How about your after-sales service ?
A: Machines overall warranty is two years.During the normal using,we can send you the machine's components for free,not damaged on purpose.Our engineers are available to service overseas, we will offer lifetime service for machine.
