ZT-H100 тестер сопротивления
- Категория: Resistance Meters >>>
- Поставщик: Zhuhai,Hengtai,Electric,Power,Technology,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-20-2025 | 0.14 $* | 0.90 $* |
| Aug-20-2025 | 0.12 $* | 0.27 $* |
| Jul-20-2025 | 0.27 $* | 0.19 $* |
| Jun-20-2025 | 0.64 $* | 0.23 $* |
| May-20-2025 | 0.83 $* | 0.5 $* |
| Apr-20-2025 | 0.28 $* | 0.52 $* |
| Mar-20-2025 | 0.62 $* | 0.32 $* |
| Feb-20-2025 | 0.40 $* | 0.69 $* |
| Jan-20-2025 | 0.39 $* | 0.41 $* |
Характеристики
Product Description
Brief introduction:
The instrument panel is ergonomically designed, in line with operating practices, use high-frequency switching power supplies and digital circuit technology for measuring the contact resistance of the circuit switch control device. Test current is DC 100A. In the case of DC 100A can be directly measured contact resistance test result with a large-screen LCD display, and with data storage, print, time settings and other functions, and another gear 50A for user selection; custom test time, maximum 599S, much larger than the standard requirements of 60S; resolution 0.01μΩ and very stable. Meet the power; the electricity sector on-site high voltage switch maintenance and high-voltage switch factory contact resistance testing requirements.
Products features:
1. High current, adopts new switching power techniques, can output current long time and continuously , overcome the malpractice of instantaneous current of the impulse type power, can effectively break through the oxide film of the switch contact, get accurate test result.
2. High stability, under strong interference, the last number displayed by the LCD within the range of ±1, with steady reading and good reproducibility.
3. High precision: adopts double channels high-speed 16bits Σ－Δ AD to sample, digital signal processing technique, the maximum resolution up to 0.01μΩ.
4. Intelligent: use high performance CPU, system can switch the measurement range according the size of the signal when testing, ensure the accuracy. The over-temperature protection circuit can auto stop output the current when the device exceeds the rated temperature to ensure the safety.
5. High quality: key components adopts imported components, uses temperature compensating circuit in perfect design which eliminates the effect to test result by temperature, meanwhile strengthen the resistance to shock by using the military connector.
6. Powerful: current could be 50A, 100A, measurement time 5s~599s, more powerful than other equipments.
7. Friendly man-machine interface: enter the data by rotating mouse, easy and convenient, can set the data, time by yourself, save and print the test result in time.
8. USB COMM.: The tester can communicate with computer through USB data line and upload the measured data to computer for further analysis and processing.
9. Easy to carry: small in volume, light in weight.
2. High stability, under strong interference, the last number displayed by the LCD within the range of ±1, with steady reading and good reproducibility.
3. High precision: adopts double channels high-speed 16bits Σ－Δ AD to sample, digital signal processing technique, the maximum resolution up to 0.01μΩ.
4. Intelligent: use high performance CPU, system can switch the measurement range according the size of the signal when testing, ensure the accuracy. The over-temperature protection circuit can auto stop output the current when the device exceeds the rated temperature to ensure the safety.
5. High quality: key components adopts imported components, uses temperature compensating circuit in perfect design which eliminates the effect to test result by temperature, meanwhile strengthen the resistance to shock by using the military connector.
6. Powerful: current could be 50A, 100A, measurement time 5s~599s, more powerful than other equipments.
7. Friendly man-machine interface: enter the data by rotating mouse, easy and convenient, can set the data, time by yourself, save and print the test result in time.
8. USB COMM.: The tester can communicate with computer through USB data line and upload the measured data to computer for further analysis and processing.
9. Easy to carry: small in volume, light in weight.
Specification
item | value |
Place of Origin | China |
Guangdong | |
Brand Name | Hengtai |
Model Number | ZT-H100 |
Display Type | Digital Only |
Measuring Range | 0~2999.9μΩ |
Testing Voltage | 250V 500V 1000V 2500V 5000V |
Accuracy Class | ±(0.5% rd+2d) |
Operating Temperature | - 10℃~40℃ |
Dimensions | 360*300*250 mm3 |
Product name | Earth Resistance Tester |
Company Profile
ZHUHAI HENGTAI electric power technology Co.,ltd is a high-tech enterprise specializing in high-voltage power transmission and transformation test equipment R&D,production and operation.We sincerely hold the tenet of "quality first,customers supreme,honor commitment trustworthy".
Over the years,our company stays commitment R&D about electric power detection equipment and electric power automation,since its foundation,the company keeps living up to the belief of: "Create high-quality brand ,casting first-class enterprise image".Also,we make the "steady development,the best quality"as the core concept of the enterprise.While we are constantly strengthening the company's own R&D capabilities,learning from Europe and the United States leading technology and successful experience to enable enterprise to maintain a leading edge in technology and operations.It's certain that users are provided with "efficient,safe,innovative"services and technical support to provide customers with more satisfactory products. The company's main products are: high-voltage switch tester, loop resistance tester, transformer DC resistance tester, frequency conversion series resonance, transformer ratio tester, automatic dielectric loss tester, insulating oil dielectric strength tester, transformer comprehensive tester, DC high voltage generator, zinc oxide arrester live tester, intelligent cable fault tester and so on.
Talent is the foundation of an enterprise.The company has hired a group of experts and senior engineers with high theoretical engineering masters,doctors and field experience in power systems to strengthen the company's development to meet the needs of every user.Our products have passed the ISO 9001 international quality system certification and the provincial power research institute, the pilot institute of inspection and certification,and they are widely used in electric power, metallurgy, petrochemical, railway, research institutes, military industry and various types of large factories, mining enterprises, power equipment production enterprises.
Strict discipline, scientific management, standardized operation,we are sedulously improving and innovating in the field of power testing ,and we are deeply impressed by the quality,which makes our products have been widely appreciated and favored by our customers.
We will make unremitting efforts to provide new and old customers with better equipment and better service. Let us work hand in hand with you to contribute to the construction and maintenance of the national grid.
Over the years,our company stays commitment R&D about electric power detection equipment and electric power automation,since its foundation,the company keeps living up to the belief of: "Create high-quality brand ,casting first-class enterprise image".Also,we make the "steady development,the best quality"as the core concept of the enterprise.While we are constantly strengthening the company's own R&D capabilities,learning from Europe and the United States leading technology and successful experience to enable enterprise to maintain a leading edge in technology and operations.It's certain that users are provided with "efficient,safe,innovative"services and technical support to provide customers with more satisfactory products. The company's main products are: high-voltage switch tester, loop resistance tester, transformer DC resistance tester, frequency conversion series resonance, transformer ratio tester, automatic dielectric loss tester, insulating oil dielectric strength tester, transformer comprehensive tester, DC high voltage generator, zinc oxide arrester live tester, intelligent cable fault tester and so on.
Talent is the foundation of an enterprise.The company has hired a group of experts and senior engineers with high theoretical engineering masters,doctors and field experience in power systems to strengthen the company's development to meet the needs of every user.Our products have passed the ISO 9001 international quality system certification and the provincial power research institute, the pilot institute of inspection and certification,and they are widely used in electric power, metallurgy, petrochemical, railway, research institutes, military industry and various types of large factories, mining enterprises, power equipment production enterprises.
Strict discipline, scientific management, standardized operation,we are sedulously improving and innovating in the field of power testing ,and we are deeply impressed by the quality,which makes our products have been widely appreciated and favored by our customers.
We will make unremitting efforts to provide new and old customers with better equipment and better service. Let us work hand in hand with you to contribute to the construction and maintenance of the national grid.
Packing & Delivery
FAQ
1. who are we?
We are based in Guangdong, China, start from 2004,sell to Domestic Market(90.00%),Southeast Asia(5.00%),Africa(3.00%),South America(2.00%). There are total about null people in our office.
2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.what can you buy from us?
Switching mechanical characteristics,Series Pressure Resistance Test Device,Transformer DC resistance tester,Insulation resistance tester,AC DC test Transformer
4. why should you buy from us not from other suppliers?
Zhuhai Hengtai Power Technology Co. Ltd. has been engaged in the production of high-pressure testing equipment in China for many years. it was named "Guangdong Provincial Contract Honor Credit Company." in China. Advanced equipment technology, lightweight
5. what services can we provide?
Accepted Delivery Terms: FOB；
Accepted Payment Currency:null;
Accepted Payment Type: T/T,L/C,Credit Card,Cash;
Language Spoken:English,Chinese
We are based in Guangdong, China, start from 2004,sell to Domestic Market(90.00%),Southeast Asia(5.00%),Africa(3.00%),South America(2.00%). There are total about null people in our office.
2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.what can you buy from us?
Switching mechanical characteristics,Series Pressure Resistance Test Device,Transformer DC resistance tester,Insulation resistance tester,AC DC test Transformer
4. why should you buy from us not from other suppliers?
Zhuhai Hengtai Power Technology Co. Ltd. has been engaged in the production of high-pressure testing equipment in China for many years. it was named "Guangdong Provincial Contract Honor Credit Company." in China. Advanced equipment technology, lightweight
5. what services can we provide?
Accepted Delivery Terms: FOB；
Accepted Payment Currency:null;
Accepted Payment Type: T/T,L/C,Credit Card,Cash;
Language Spoken:English,Chinese
