Mining Truck Weichai Mining Truck 41T- China Best Mining Truck


Mining Truck Weichai Mining Truck 41T- China Best Mining Truck





mining truck (1).jpg





THE BEST MINING TRUCK BY WEICHAI


Weichai wide-body mining truck is developed on the basis of integrating the whole Group’s gold powertrain resources (Weichai Engine, Fast Transmission and Hande Axle), and special design focusing on the requirement of mining industry. Weichai mining truck is the only one passed torque test on the five-Axis drum test bench and the truck has the advantage of high reliability, high loadbearing, overloading starting and high gradeability. So after the mining truck enter into the market, their market share at home and abroad keeps increasing, and their reputation among global users keeps improving.








Mining Truck Weichai Mining Truck 41T- China Best Mining Truck specification

































































































































































































































































































































































VEHICLE   PARAMETER
Driving type6x4Overall dimension8390×2520×4050 mm
Nominal payload25,500 kgMinimum turning radius9000 mm
Kerb weight 15,500 kgMinimum ground clearence325 mm
Gross vehicle weight41,000 kgApproach angle29 degrees
Maximum limited speed49 kmphDeparture angle51 degrees
Maximum gradiability30%Front overhang1543 mm
Wheel base 3800+1400 mmRear overhang1647mm


ENGINE  FRONT SUSPENSION

Electronically   controlled,turbocharger


and intercooler, 4 cycles



Longitudinal steel leaf


spring with semi-elliptical shape


ModelWP10.340E32rubber dampening blocks
No.of cylinders6Number of leaves10
No.of valves per cylinder 4Thickness of leaves18 mm
EmissionEu Stage 2Width of leaves90 mm
Displacement9.726 L
Bore x Stroke126 x 130 mmREAR SUSPENSION
Max.Torque@ Speed1350Nm @ 1100-1600 rpmSteel spring balanced   suspension support type
Rated Power @ Speed340HP @ 2100 rpmNumber of leaves12
  Thickness of leaves25 mm
GEAR BOX Width of leaves90 mm
ModelRTD-11509C
No.of gear shifts9 forward +1 reverseWHEELS AND TYRES
Forward ratios

12.42/8.3/6.08/4.54/


3.36/2.47/


1.81/1.35/1



Reinforced steel rims to


withstand mining conditions


Reverse ratio12.99Tyre TypeBias ply tyre
  Tyre Size12.00-20
FRONT AXLE Wheel Size 8.5-20
Typewelding structure rectangular beamTotal No.of tyres11
Capacity9.5 tons
  TIPPER BODY
REAR AXLE  U shape scoop body / Rock   body / Exhaust heated body
Double   reduction, differential locks-inter-wheel and Inter-axles Standard Bucket Capacity19.6 CuM
Ratio8.88Thickness of body floor12 mm
Capacity (Tandem)32 tonsThickness of body side panel10 mm
  Length of the internal body5600 mm
STEERING Width of the internal body2300 mm
Assistance typeMechanical recirculating ball   steering gear Height of the internal body1500 mm
Steering ratio25
Oil pump pressure17 MPaLIFTING  HYDRAULICS   SYSTEM
  Heavy duty front mounted   telescopic cylinder
BRAKES Hydraulic pressure for lifting cylinder19 Mpa
Service brakeDual circuit brakeDiameter of lifting cyllnder160 mm
Parking brake Spring energy storage brakeLength of lifting cylinder4600 mm
Auxiliary brakeExhaust valve brake
Working pressure1000 kPaFUEL TANK
Air tank capacity 150 LAluminium fuel tank
Braking Distance<12 mCapacity420 L
Parking Ramp(°) 30 degrees (up ramp) /20 degrees   (down ramp)
  CABIN
ELECTRICALS Specially designed wide   cabin for mining purpose
System Voltage24 V Left mounted, half floating, equipped with   A/C
Battery Capacity165AhOverall heat Insulated   with noise reduction
Alternator Power2000 W

Spring driver's seat with


adjustment of height,backrest


,and seat tilt.


  Cabin tilt angle46 degrees
CHASSIS FRAME

U-profile   double frame(10+10),


made with reinforced high strength steel


INTAKE& EXHAUST SYSTEM
Main longitudinal beam section   (mm)400x900x20 mmMulti dust filter mounting on the cabin side
Ladder frame width (mm) 850 mmTee Exhaust valve
