Японские подшипники NSK 7017 7018 7019 7020 7021 7022 7024 P4 A
- Категория: Angular Contact Ball Bearings >>>
- Поставщик: Shandong,Tefule,Bearing,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-19-2025 | 0.91 $* | 0.87 $* |
| Aug-19-2025 | 0.65 $* | 0.99 $* |
| Jul-19-2025 | 0.54 $* | 0.71 $* |
| Jun-19-2025 | 0.17 $* | 0.11 $* |
| May-19-2025 | 0.41 $* | 0.75 $* |
| Apr-19-2025 | 0.7 $* | 0.54 $* |
| Mar-19-2025 | 0.43 $* | 0.28 $* |
| Feb-19-2025 | 0.12 $* | 0.46 $* |
| Jan-19-2025 | 0.91 $* | 0.28 $* |
Характеристики
Product Description
Japan NSK matching bearings 7017 7018 7019 7020 7021 7022 7024 P4 A C
Angular contact ball bearings are particularly suitable for carrying combined (axial and radial) loads. Sometimes, they also can carry pure axial load and operate in higher speed. Under radial load, axial component force will be produced which must be counteracted. So the bearings are normally adjust against a second bearing.
Single row angular contact ball bearings can carry axial load acting in one direction only. In many applications, angular contact ball bearings in pairs or muti-arrangement should be used. The axial load carrying capacity of angular contact ball bearings increases with the increase of contact angle.
Series Range
7000C(∝=15°)
7000AC(∝=25°)
7000B(∝=40°)
Back-to-back configuration, code-named DB (such as 70000 / DB)
Face to face configuration, code-named DF (such as 70000 / DF)
Tandem configuration, code-named DT (such as 70000 / DT)
Angular contact ball bearings are particularly suitable for carrying combined (axial and radial) loads. Sometimes, they also can carry pure axial load and operate in higher speed. Under radial load, axial component force will be produced which must be counteracted. So the bearings are normally adjust against a second bearing.
Single row angular contact ball bearings can carry axial load acting in one direction only. In many applications, angular contact ball bearings in pairs or muti-arrangement should be used. The axial load carrying capacity of angular contact ball bearings increases with the increase of contact angle.
Series Range
7000C(∝=15°)
7000AC(∝=25°)
7000B(∝=40°)
Back-to-back configuration, code-named DB (such as 70000 / DB)
Face to face configuration, code-named DF (such as 70000 / DF)
Tandem configuration, code-named DT (such as 70000 / DT)
Size Information
Model | Old Model | Dimesion(mm) | Weight | ||||
d | D | T | |||||
7000AC | 46100 | 10 | 26 | 8 | 0.02 | ||
7001AC | 46101 | 12 | 28 | 8 | 0.02 | ||
7002AC | 46102 | 15 | 32 | 8 | 0.03 | ||
7003AC | 46103 | 17 | 35 | 10 | 0.03 | ||
7004AC | 46104 | 20 | 42 | 10 | 0.07 | ||
7005AC | 46105 | 25 | 47 | 12 | 0.08 | ||
7006AC | 46106 | 30 | 55 | 13 | 0.12 | ||
7007AC | 46107 | 35 | 62 | 14 | 0.14 | ||
7008AC | 46108 | 40 | 68 | 15 | 0.21 | ||
7016ACM | 46116H | 80 | 125 | 22 | 0.9 | ||
7017AC | 46117 | 85 | 130 | 22 | 0.95 | ||
7017ACM | 46117H | 85 | 130 | 22 | 0.95 | ||
7018AC | 46118 | 90 | 140 | 24 | 0.96 | ||
7018ACM | 46118H | 90 | 140 | 24 | 0.96 | ||
7019AC | 46119 | 95 | 145 | 24 | 1.2 | ||
7019ACM | 46119H | 95 | 145 | 24 | 1.2 | ||
7020AC | 46120 | 100 | 150 | 24 | 1.25 | ||
7020ACM | 46120H | 100 | 150 | 24 | 1.25 | ||
7021ACM | 46121H | 105 | 160 | 26 | 1.61 | ||
7022ACM | 46122H | 110 | 170 | 28 | 2.44 | ||
7024ACM | 46124H | 120 | 180 | 28 | 2.62 | ||
7026ACM | 46126H | 130 | 200 | 33 | 3.912 | ||
7028ACM | 46128H | 140 | 210 | 33 | 4.2 | ||
7030ACM | 46130H | 150 | 225 | 35 | 5 | ||
7032ACM | 46132H | 160 | 240 | 38 | 5.02 | ||
7034ACM | 46134H | 170 | 260 | 42 | 8.3 | ||
7038ACM | 46138H | 190 | 290 | 46 | 11.2 | ||
7040ACM | 46140H | 200 | 310 | 51 | 14.3 | ||
7044ACM | 46144H | 220 | 340 | 56 | 18.5 | ||
7217ACM | 46217H | 85 | 150 | 28 | 1.88 | ||
7222ACM | 46222H | 110 | 200 | 38 | 4.81 | ||
7224ACM | 46224H | 120 | 215 | 40 | 5.6 | ||
7226ACM | 46226H | 130 | 230 | 40 | 7.3 | ||
7228ACM | 46228H | 140 | 250 | 42 | 7.76 | ||
7302AC | 46302 | 15 | 42 | 13 | 0.094 | ||
7303AC | 46303 | 17 | 47 | 14 | 0.12 | ||
7304AC | 46304 | 20 | 52 | 15 | 0.146 | ||
7305AC | 46305 | 25 | 62 | 17 | 0.23 | ||
7306AC | 46306 | 30 | 72 | 19 | 0.35 | ||
7307AC | 46307 | 35 | 80 | 21 | 0.47 | ||
7307ACM | 46307H | 35 | 80 | 21 | 0.47 | ||
7308AC | 46308 | 40 | 90 | 23 | 0.69 | ||
7308ACM | 46308H | 40 | 90 | 23 | 0.69 | ||
7309AC | 46309 | 45 | 100 | 25 | 0.89 | ||
7309ACM | 46309H | 45 | 100 | 25 | 0.89 | ||
Related Products
Packing&Shipping
Packing
A: Tube packing+carton+pallets B: single box packing+carton+pallets
C:as customer's requirement
Shipment
1. By FedEx /DHL /UPS /TNT /EMS door to door services.
2. By Air or by Sea for batch goods; for FCL. You'll have to pick up the goods at the airport or port.
3. Customers specifying freight forwarders or negotiable shipping methods are available.
Payment
1. Payment: 100% T/T, Western Union, or Alibaba Secure Payment in advance;
1. By FedEx /DHL /UPS /TNT /EMS door to door services.
2. By Air or by Sea for batch goods; for FCL. You'll have to pick up the goods at the airport or port.
3. Customers specifying freight forwarders or negotiable shipping methods are available.
Payment
1. Payment: 100% T/T, Western Union, or Alibaba Secure Payment in advance;
Company Introduction
Shandong Tefule Bearing Co.,Ltd
is a professional bearing manufacturer and dealer in china.We have been engaged in bearing industry for 10 years and made international trade of bearing import and export for more than 8 years.We have our own brand "TFL" and applied ISO9001:2000 certificate for certification authority.We attend international bearing fairs, put in many B2B website and achieve many customers all over the world also bulid up good reputation from our customers.
is a professional bearing manufacturer and dealer in china.We have been engaged in bearing industry for 10 years and made international trade of bearing import and export for more than 8 years.We have our own brand "TFL" and applied ISO9001:2000 certificate for certification authority.We attend international bearing fairs, put in many B2B website and achieve many customers all over the world also bulid up good reputation from our customers.
Our company is specialized in ball bearing,roller bearing,housing units, wheel hub bearing,bearing parts and accessories, cross roller bearing.Also we can customize various large non-standard products such as the most competitive products according to customers' demands.
