Санитарный пневматический диафрагменный клапан из нержавеющей стали поставщик
- Категория: Мембранные клапаны >>>
- Поставщик: Fujian,Hanji,Environment,Technology,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-19-2025 | 0.63 $* | 0.65 $* |
| Aug-19-2025 | 0.2 $* | 0.78 $* |
| Jul-19-2025 | 0.32 $* | 0.42 $* |
| Jun-19-2025 | 0.29 $* | 0.97 $* |
| May-19-2025 | 0.57 $* | 0.64 $* |
| Apr-19-2025 | 0.43 $* | 0.96 $* |
| Mar-19-2025 | 0.93 $* | 0.42 $* |
| Feb-19-2025 | 0.23 $* | 0.51 $* |
| Jan-19-2025 | 0.92 $* | 0.70 $* |
Характеристики
Product Description
Technical parameters of sanitary pneumatic diaphragm valve | ||
Material | 316L stainless steel | |
Interface method | ANSI or DIN standard flange, clamp fast assembly, welding | |
Diaphragm material | EPDM, FPM, PTFE, CSM, NBR, EPDM/PTFE | |
Drive way | Manual, pneumatic and electric | |
Main connection shape and size | ||||||||||||||
DN | 15 | 20 | 25 | 32 | 40 | 50 | 65 | |||||||
L | 127 | 127 | 127 | 159 | 159 | 190 | 216 | |||||||
H | 195 | 198 | 200 | 235 | 240 | 245 | 260 | |||||||
D | 50.5 | 50.5 | 50.5 | 50.5 | 64 | 77.5 | 91 | |||||||
d | 15 | 19 | 24 | 29 | 36 | 48 | 63 | |||||||
B | G1/4" | G1/4" | G1/4" | G1/4" | G1/4" | G1/4" | G1/4 | |||||||
Sanitary pneumatic diaphragm valve product features
Sanitary stainless steel diaphragm valve can be installed in any position, the flow of media on the valve open and close does not affect the compact structure, pneumatic diaphragm valve is suitable for a variety of surface polishing in a narrow space, no dead Angle can automatically empty.
Sanitary stainless steel diaphragm valve can be installed in any position, the flow of media on the valve open and close does not affect the compact structure, pneumatic diaphragm valve is suitable for a variety of surface polishing in a narrow space, no dead Angle can automatically empty.
Products Description
Product overview
Pneumatic sanitary diaphragm valve is a widely used diaphragm products, suitable for pharmaceutical, biological, dairy, beverage, chemical, cosmetics, food, electronics and other fluid related industries fluid control system. Its advantages are no dead Angle, no leakage, easy to clean, low maintenance cost, easy to operate and so on. Automatic control and manual control can be realized, providing good products for reducing operating costs of enterprises, and clean emissions during installation at 35 degrees; There is no risk of leakage in the valve; High corrosion resistance; The material with high viscosity can easily replace the ball valve and butterfly valve with products with high cleanliness requirements
Product Usage
Sanitary pneumatic diaphragm valve product material
Sanitary pneumatic diaphragm valve steel parts: stainless steel 304, stainless steel 316L.
Sealing parts: EPDM+RTFE (EPDM+ TEflon) The sealing parts are imported sealing materials (in accordance with FDA177.2600 standard). Using Riter technology, a connection bolt is combined with EPDM/PTFE as an integral sealing component, which is made of PTFE material in contact with the medium with good cold resistance (-25℃), good heat resistance (+250℃) to a variety of chemicals and good wear resistance to fluids!
Related Products
Packing&Shipping
Packing: Can be exported to wooden boxes or specified by customers
Transportation: We ship to customers worldwide through UPS, DHL, air or sea
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services
will be provided.
will be provided.
Company Introduction
Fujian Hanji Environmental Technology Co., Ltd., with a registered capital of 10 million, the company has a number of cooperative factories, mainly engaged in: production, sales, installation, maintenance, equipment leasing, engineering design, technology of refrigeration and air conditioning equipment, heating and cooling equipment and energy-saving environmental protection equipment R&D, technology transfer, technical consultation, technical services, VOC environmental protection equipment, sludge drying equipment and accessories, inhibitor ethylene glycol, corrosion inhibitor, refrigerant synergist and other cold storage assembly and ammonia storage transformation,
In cooperation with us, LIK valves were certified by DIN EN ISO 9001 quality management system in 1995, and then by CE certification, TA-LuFT certification, so we can ensure that LIK valves provide customers with high quality valves. Therefore can enter the world valve high precision technology market competitors. In 1999, LIK Valves opened a modern foundry and became operational. This foundry covers all the high quality castings needed for valves, and offers low cost and environmentally friendly products.
In cooperation with us, LIK valves were certified by DIN EN ISO 9001 quality management system in 1995, and then by CE certification, TA-LuFT certification, so we can ensure that LIK valves provide customers with high quality valves. Therefore can enter the world valve high precision technology market competitors. In 1999, LIK Valves opened a modern foundry and became operational. This foundry covers all the high quality castings needed for valves, and offers low cost and environmentally friendly products.
Certifications
FAQ
1. What is the application field of your product?
A: Our products have been widely used in many industries, such as: injection molding, automotive, electronics, metallurgy, machinery manufacturing, petrochemical, steel and other industrial fields.
2. Can you customize?
A: Yes, we have strong technical design and manufacturing capabilities and can provide any customization for OEM/ODM according to your needs.
3. Do you provide product guarantee?
Answer: Yes, we provide a 1-year warranty for our products.
4:How long is your lead time?
a：Our delivery time is usually about 30 days.This depends on the quantity and model ordered by the customer.
5:What about the quality of your products?
A:Each of our products has strict production quality certification, with the corresponding qualification certificate and qualification。
6. Can the product be customized?
A:Of course, we have a professional production line, please tell us。
7.How can I place an order?
A:You can send email or inquiry to us through alibaba.
A: Our products have been widely used in many industries, such as: injection molding, automotive, electronics, metallurgy, machinery manufacturing, petrochemical, steel and other industrial fields.
2. Can you customize?
A: Yes, we have strong technical design and manufacturing capabilities and can provide any customization for OEM/ODM according to your needs.
3. Do you provide product guarantee?
Answer: Yes, we provide a 1-year warranty for our products.
4:How long is your lead time?
a：Our delivery time is usually about 30 days.This depends on the quantity and model ordered by the customer.
5:What about the quality of your products?
A:Each of our products has strict production quality certification, with the corresponding qualification certificate and qualification。
6. Can the product be customized?
A:Of course, we have a professional production line, please tell us。
7.How can I place an order?
A:You can send email or inquiry to us through alibaba.
