Высокочастотный источник бесперебойного питания Ups 80

MODEL

33 80KS plus

Rated power

80KVA/64KW

Input

Range of voltage(full load)

207~475Vac  3P4W+G

Range of frequency

40-70Hz(adjusted)

Power factor

≥0.99

output

Rated voltage

380Vac(1±1%)  3P4W+G

frequency

1.The output frequency synchronizes with the input frequency when the input frequency is in the range of 46 Hz~ 54 Hz.

2.The output frequency is 50Hz when the input frequency is not in the range of 40 Hz~ 46 Hz and 54Hz~60Hz.

 3.BAT mode:50Hz.

Rated current

121A

Power factor

0.8

Distortion

≤3%

Ratio

3:1

Over load

105% ±5% < Load ≤ 125% ± 5% 60s transfer to bypass

125% ±5% < Load < 135% ± 5% 30s transfer to bypass

Load > 135% ± 5%, 300ms transfer to bypass

Line—bat transfer time

0ms

Efficiency

> 90%

Bat

Rated voltage

480Vdc

No.

40

Charge current

10A(5-20A can be set)

Size (L*W*H)mm

910*515*1145

Weight

208

Work temp.(℃)

0℃~40℃

Work humidity

20%~95%

Noise(dB)

≤60dB
