OEM (изготовитель комплектного оборудования) высоко эффективная энергосберегающая шланг-Катушка Для Шланга Ирригатор для полости рта
- Категория: Система орошения для фермы >>>
- Поставщик: Jiangsu,Jitian,International,Trade,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-18-2025 | 2975.10 $* | 3124.75 $* |
| Aug-18-2025 | 2950.90 $* | 3098.79 $* |
| Jul-18-2025 | 2475.3 $* | 2599.61 $* |
| Jun-18-2025 | 2900.5 $* | 3045.6 $* |
| May-18-2025 | 2525.78 $* | 2651.99 $* |
| Apr-18-2025 | 2850.37 $* | 2993.55 $* |
| Mar-18-2025 | 2825.62 $* | 2966.50 $* |
| Feb-18-2025 | 2800.22 $* | 2940.78 $* |
| Jan-18-2025 | 2775.22 $* | 2914.52 $* |
Характеристики
Product Description
JP series volume disc sprinkler series USES water turbine (sprinkler pressure water drive), internal combustion engine, hydraulic Mazda, motor drive a variety of ways, through variable speed device driver winch spinning and drawing water from automatic movement and spray irrigation machinery, depending on the nozzle, usually divided into spray gun type and frame yan type two kinds. Walking sprinkler irrigation has the advantages of convenient movement, simple operation, time-saving, water-saving effect, uniform spraying and so on, which can effectively provide the required water and improve crop yield.
Large and small crops irrigation, gardens, urban greening, fruits and vegetables, tea, herbage, tobacco, sugar cane, as well as power plants, docks, construction sites, coal dust and other fields.
Water turbine drive. Hydraulic drive, electric drive, internal combustion engine drive.
Single spray gun spray, double spray gun spray, rack spray
Project | Sseries Model | |||||||
unit | JP32 JP32/D | JP40 JP40/D | JP50 JP50/D | JP65 JP65/D | ||||
interlayer velocity difference | % | <20 D/<15 | <20 D/<15 | <20 D/<15 | <20 D/<15 | |||
precipitation | mm | 5-30 | 5-30 | 6-44 | 8-50 | |||
nozzle type | / | PYK20 | PYK30 | PYK40 | PYC50 | |||
nozzle height | mm | 800 | 800 | 1000-1800 | 1300- 2800 | |||
nozzle car track | mm | 300 | 500 | 600 | 1300 | |||
car climbing | % | 20 | 20 | 20 | 20 | |||
traction height | mm | / | / | 300 | 300- 500 | |||
ground clearance | mm | 200 | 200 | 300 | 300 | |||
chassis | / | 4.00-8 | 150-8 | 145-12 | 165/70 R-13 | |||
wheel tire rim maximum width | mm | 840 | 1030 | 1580 | 2000 | |||
Project | Uint | Series Model | ||||||
JP75 JP75/D | JP90 JP90/D | JP110 JP110/Y | JP125/Y | |||||
interlayer velocity difference | % | <20 D/<15 | <20 D/<15 | <20 Y/<15 N/<15 | <15 N/<15 | |||
precipitation | mm | 8-50 | 8-50 | 7.3-92 | 10-100 | |||
nozzle type | / | PYC50 | PYC50 | PYC75 | PYC75 | |||
nozzle height | mm | 1300- 2800 | 1300- 2800 | 2000- 3000 | 2000- 3000 | |||
nozzle car track | mm | 1300 | 1300 | 1300-1500 | 1300-1500 | |||
car climbing | % | 20 | 20 | 20 | 20 | |||
traction height | mm | 300- 500 | 300- 500 | 300- 500 | 300- 550 | |||
ground clearance | mm | 300 | 300 | 300 | 300 | |||
chassis | / | 185R 14c | 10.0/80 -12 | 10.0/75 -15.3 | 10.0/75 -15.3 | |||
wheel tire rim maximum width | mm | 2000 | 2310 | 2400 | 2510 | |||
Project | UnIt | Series Model | ||||||
JP32 JP32/D | JP40 JP40/D | JP50 JP50/D | JP65 JP65/D | |||||
PE pipe diameter | mm | 32 | 40 | 50 | 65 | |||
PE pipe length | m | 70-100 | 90-120 | 150-250 | 200-350 | |||
into the machine working pressure | MPa | 0.3-0.5D /0.2-0.4/ | 0.3-0.6D /0.25-0.5/ | 0.4-0.78D/ 0.35-0.68/ | 0.5-1.0D/ 0.4-0.9/ | |||
nozzle pressure | MPa | 0.15-0.3 | 0.15-0.3 | 0.2-0.4 | 0.2-0.6 | |||
nozzle diameter | mm | 6-10 | 8-12 | 9-16 | 14-18 | |||
flow rate | m7h | 3-6 | 5-9 | 5-19.7 | 11-31 | |||
range | m | 12-18 | 12-18 | 19-30 | 28-43 | |||
spray width | m | 20-30 | 20-30 | 32-51 | 47-74 | |||
combination uniformity coefficient | % | ≥85 | ≥85 | ≥85 | ≥85 | |||
Series Model | ||||||||
JP75 JP75/D | JP90 JP90/D | JP110 JP110/Y | JP125/Y | |||||
PE pipe diameter | mm | 75 | 90 | 110 | 125 | |||
PE pipe length | m | 250-450 | 300-450 | 300-500 | 200-330 | |||
into the machine working pressure | MPa | 0.5-1.0D/ 0.4-0.9/ | 0.5-1.0D/ 0.4-0.9/ | 0.55-1.25 Y/0.5-1.0 N/0.5-1.0 | 0.55-1.25 Y/0.5-1.0 N/0.5-1.0 | |||
nozzle pressure | MPa | 0.3-0.6 | 0.4-0.6 | 0.5-0.8 | 0.5-0.8 | |||
nozzle diameter | mm | 16-22 | 20-26 | 24-32 | 28-36 | |||
flow rate | m7h | 13-38 | 17-52 | 45-106 | 68-130 | |||
range | m | 28-43 | 35-52 | 45-68 | 55-72 | |||
spray width | m | 47-74 | 60-90 | 77-116 | 95-124 | |||
combination uniformity coefficient | % | ≥85 | ≥85 | ≥85 | ≥85 | |||
