22kw корма для животных шлифовальная машина с вертикальным валом воздействия удобрения цепная дробилка Емкость 5-8

Product introduction

The chain crusher is divided into two types:vertical chain crusher and horizontal chain crusher.Vertical chain crusher has single rotor,and horizontal chain crusher has double rotor.Chain crusher is suitable for crushing of block in compound fertilizer production and the crushing of return material in fertilizer production.

Performance characteristics

1.Double rotor structure, each rotor shaft has its own drive motor, the circumferential speed of the chain head.

2.The machine consists of a feed port, a body, a discharge port, a rotor (including bearings), a transmission and a damper.

3.In order to prevent the friction between the adhesive and the steel plate of the body, a rubber plate is lined in the machine body, and a quick opening type access door is arranged on both sides of the body.

Working principle

According to the installation form, the chain crusher is divided into two types: vertical chain crusher and horizontal chain crusher. The vertical chain crusher is a single rotor, and the horizontal chain crusher is a double rotor. The main working part of the chain crusher is a rotor with a steel chain. One end of the chain is connected to the rotor, and the other end of the chain is provided with a ring head made of wear-resistant steel. The chain crusher is an impact crusher that pulverizes the impact of the block by a chain that rotates at a high speed.The double-rotor structure of the horizontal chain crusher, each rotor shaft has its own transmission motor, the peripheral speed of the chain head in the range of 28~78m/s.The horizontal chain crusher consists of a feed port, a body, a discharge port, a rotor (including bearings), a transmission and a damper.In order to prevent the friction between the adhesive material and the steel plate of the machine body, a rubber plate is lined in the machine body, and a quick opening type maintenance door is arranged on both sides of the body, the body and the transmission device are mounted on a base made of a steel, and a vibration damper is mounted on the lower part of the base. And connected to the foundation.
