Теплопроводящее покрытие из стекла с гравировкой 25 мм * 1 солнечная батарея эксперименты по производству энергии для
- Категория: Building & Industrial Glass >>>
- Поставщик: Dongguan,Qunguan,Electronic,Technology,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-19-2025 | 0.35 $* | 0.99 $* |
| Aug-19-2025 | 0.94 $* | 0.24 $* |
| Jul-19-2025 | 0.64 $* | 0.41 $* |
| Jun-19-2025 | 0.43 $* | 0.7 $* |
| May-19-2025 | 0.37 $* | 0.48 $* |
| Apr-19-2025 | 0.30 $* | 0.66 $* |
| Mar-19-2025 | 0.38 $* | 0.7 $* |
| Feb-19-2025 | 0.65 $* | 0.69 $* |
| Jan-19-2025 | 0.42 $* | 0.73 $* |
Характеристики
You can customize conductive glass of any size and thickness
specification | Sheet resistance | Conductive film thickness | Transmittance | Etching time |
3 ohm | 3-4ohm | 380±50nm | ≥80% | ≤400S |
5 ohm | 4-6ohm | 380±50nm | ≥82% | ≤400S |
6 ohm | 5-7ohm | 220±50nm | ≥84% | ≤400S |
7 ohm | 6-8ohm | 200±50nm | ≥84% | ≤400S |
8 ohm | 7-10ohm | 185±50nm | ≥84% | ≤400S |
15 ohm | 10-15ohm | 135±50nm | ≥86% | ≤400S |
20 ohm | 15-20ohm | 95±50nm | ≥87% | ≤400S |
30 ohm | 20-30ohm | 65±50nm | ≥88% | ≤400S |
FTO Conductive Glass
1. FTO conductive glass is fluorine-doped SnO2 transparent conductive glass (SnO2: F), referred to as FTO.
2. SnO2 is a wide
band-gap oxide semiconductor that is transparent to visible light, with a band gap of 3.7-4.0eV, and has a regular tetrahedral
gold red structure. After being doped with fluorine, the SnO2 film has the advantages of good light transmittance to visible
light, large ultraviolet absorption coefficient, low resistivity, stable chemical properties, the most prominent feature is that FTO glass can resist strong acids and alkalis.
band-gap oxide semiconductor that is transparent to visible light, with a band gap of 3.7-4.0eV, and has a regular tetrahedral
gold red structure. After being doped with fluorine, the SnO2 film has the advantages of good light transmittance to visible
light, large ultraviolet absorption coefficient, low resistivity, stable chemical properties, the most prominent feature is that FTO glass can resist strong acids and alkalis.
ITO GLASS LIST | ||
thickness | Sheet resistance | |
1.1mm | 3ohm/sq~100ohm/sq | |
3mm | 4~6ohm/sq and 3~5ohm/sq | |
4mm | 25ohm/sq | |
0.4/0.5/0.7/0.8/1.0/1.5/1.8/2mm | 7~10ohm/sq | |
FTO GLASS LIST | ||
1.1mm | 15~20ohm/sq | |
1.6mm | 14~15ohm/sq | |
2.2mm | 7~8ohm/sq; 6~10ohm/sq; 14~15ohm/sq | |
3.0mm | 12~14ohm/sq | |
4.0mm | 12~14ohm/sq | |
Every piece of glass we send will go through strict quality inspection
Clean working environment
Advanced production equipment
If you are looking for a strong supplier
Please contact us
Skype : touchglass@aliyun.com
Phone: 86 18925789558
e-mail: 591104604@qq.com / touchglass@aliyun.com
WeChat：wangaihuax2017
Skype : touchglass@aliyun.com
Phone: 86 18925789558
e-mail: 591104604@qq.com / touchglass@aliyun.com
WeChat：wangaihuax2017
Usage and cleaning method
How to use and store conductive glass.
1. When taking and putting it down, it can only touch the four sides, not the conductive glass ITO surface;
2. Handle with care, not collide with other fixtures and machines;
3. If you store for a long time, you must pay attention to moisture, so as not to affect the resistance and transmittance of the glass; ITO conductive glass
2. Handle with care, not collide with other fixtures and machines;
3. If you store for a long time, you must pay attention to moisture, so as not to affect the resistance and transmittance of the glass; ITO conductive glass
Conductive glass cleaning.
During the production, packaging, and transportation of ITO/FTO conductive glass, the surface of the glass may be contaminated by impurities such as dust or grease. Before using ITO/FTO conductive glass, it is necessary to clean it. There are many cleaning
methods, the most commonly used is ultrasonic cleaning with organic solvents. Grease stained on the glass surface is insoluble in water, but it is soluble in organic solvents such as toluene, acetone, and ethanol.
Among them, toluene has the strongest degreasing ability, so first clean with toluene, but toluene will remain on the glass
surface. Since toluene is soluble in acetone, it can be cleaned with acetone, which not only cleans out the residual grease, but also dissolves toluene. Similarly, acetone will remain on the glass surface. Since acetone is soluble in ethanol, continue to clean with ethanol. Ethanol and water dissolve each other in any ratio, and then use a large amount of deionized water to dissolve the ethanol, and finally put it in anhydrous alcohol for storage, and then take it out for use when it is used, so that many tablets can be washed at one time.
methods, the most commonly used is ultrasonic cleaning with organic solvents. Grease stained on the glass surface is insoluble in water, but it is soluble in organic solvents such as toluene, acetone, and ethanol.
Among them, toluene has the strongest degreasing ability, so first clean with toluene, but toluene will remain on the glass
surface. Since toluene is soluble in acetone, it can be cleaned with acetone, which not only cleans out the residual grease, but also dissolves toluene. Similarly, acetone will remain on the glass surface. Since acetone is soluble in ethanol, continue to clean with ethanol. Ethanol and water dissolve each other in any ratio, and then use a large amount of deionized water to dissolve the ethanol, and finally put it in anhydrous alcohol for storage, and then take it out for use when it is used, so that many tablets can be washed at one time.
order：
Toluene（10--20min）→ acetone（10—20min）→ Ethanol（10—20min）→ Deionized water（20—30min） Perform ultrasonic cleaning in the above order,Finally, preserved in anhydrous alcohol, can be stored for a long time
Toluene（10--20min）→ acetone（10—20min）→ Ethanol（10—20min）→ Deionized water（20—30min） Perform ultrasonic cleaning in the above order,Finally, preserved in anhydrous alcohol, can be stored for a long time
If you still need ITO conductive film, please click this picture.
If you need to etch conductive glass, please click this picture.
Click on the picture
Conductive glass cleaning rack
Click on the picture
Flexible interdigital electrode
