Резиновая конвейерная лента DIN X EP400x4 B1400 бесплатный
- Категория: Rubber Belts >>>
- Поставщик: Baoding,Huayue,Rubber,Belts,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Aug-15-2025 | 39.53 $* | 40.20 $* |
| Jul-15-2025 | 32.61 $* | 33.38 $* |
| Jun-15-2025 | 39.51 $* | 40.66 $* |
| May-15-2025 | 38.79 $* | 39.54 $* |
| Apr-15-2025 | 31.9 $* | 32.38 $* |
| Mar-15-2025 | 38.38 $* | 39.61 $* |
| Feb-15-2025 | 38.84 $* | 39.30 $* |
| Jan-15-2025 | 37.25 $* | 38.90 $* |
Характеристики
DIN X EP400x4 B1400 Rubber Conveyor Belt Free Sample
Hot Sale
Product Description
1. Specification of Multi-ply Polyester Conveyor Belt
Fabric Type | Fabric Structure | Fabric Specs | Fabric ply No. | Belt width (mm) | Length (m) | Cover Thickness (mm) | ||
Warp | Weft | Top | Bottom | |||||
Polyester (EP) | Polyester (E) | Polyamide (P) | EP100 | 2-6 | 400-2200 | 5-500 | 2-12 | 1.5-6 |
EP125 | 2-6 | 400-2200 | 5-500 | 2-12 | 1.5-6 | |||
EP150 | 2-6 | 400-2200 | 5-500 | 2-12 | 1.5-6 | |||
EP200 | 2-6 | 400-2200 | 5-500 | 2-12 | 1.5-6 | |||
EP250 | 2-6 | 400-2200 | 5-500 | 2-12 | 1.5-6 | |||
EP300 | 2-6 | 400-2200 | 5-500 | 2-12 | 1.5-6 | |||
EP400 | 2-6 | 400-2200 | 5-500 | 2-12 | 1.5-6 | |||
EP500 | 2-6 | 400-2200 | 5-500 | 2-12 | 1.5-6 | |||
2. Physical Properties of Rubber Cover (before ageing) DIN 22102-1/GB/T7984
Grade | Tensile Strength/Mpa ≥ | Breaking Elongation/% ≥ | Abrasion Loss/mm3 ≤ |
DIN W | 18 | 400 | 90 |
DIN X | 25 | 450 | 120 |
| DIN Y | 20 | 400 | 150 |
| DIN Z | 15 | 350 | 250 |
| GB/H | 24 | 450 | 120 |
GB/D | 18 | 400 | 100 |
GB/L | 15 | 350 | 200 |
3. Ply Adhesion
Item | Ply to ply | Rubber cover to ply | |
Rubber cover thickness ≤1.5mm | Rubber cover thickness >1.5mm | ||
All samples average value/ (N/mm) ≥ | 4.5 | 3.2 | 3.5 |
All samples min peak value/ (N/mm) ≥ | 3.9 | 2.4 | 2.9 |
Note: All samples max peak value is not more than 20N/mm. | |||
Wide Range in Applic
About Us
Why Choose Us
Packaging & Shipping
FAQ
Q1. Are you a manufacturer?
A. Yes, we have been producing and selling conveyor belts since 1982.
Q2. Can you produce belts with my own brand?
A. Yes, we can.
Q3. What about the lead time?
A. 1) 5~7 days for sample (free sample)
XX2) 15~30 days according to order quantity
Q4. How about payment terms?
A. 1) We prefer T/T, 30% advance paid upon order, rest upon b/l copy, or
XX2) Sight or deferred L/C, or
XX3) Other payment terms approved.
Q5. How do you ensure product quality?
A. 1) We have a R&D center of an independent design and developing capacity
xxx2) We an independent testing laboratory with full-property testing capacity of conveyor belt. We can
xxxxx.test various materials, rubber, fabric, semi-finished product and finished product.
