Промышленный управляемый переключатель SFP 8*10/100/1000T + 8 * 1000X
- Категория: >>>
- Поставщик: Shenzhen,3C-Link,Opto,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Aug-19-2025 | 184.37 $* | 188.19 $* |
| Jul-19-2025 | 149.45 $* | 152.5 $* |
| Jun-19-2025 | 181.31 $* | 185.4 $* |
| May-19-2025 | 180.44 $* | 184.63 $* |
| Apr-19-2025 | 144.46 $* | 147.37 $* |
| Mar-19-2025 | 177.0 $* | 181.65 $* |
| Feb-19-2025 | 175.25 $* | 179.78 $* |
| Jan-19-2025 | 174.45 $* | 177.36 $* |
Характеристики
INDUSTRIAL 8* 10/100/1000T + 8* 1000X SFP MANAGED SWITCH(3CI-SFP0808GM)
-------------------------------Industrial Converter---------------------------
Certifications
Product Description
---------------------------------Description--------------------------------
The 3CI-SFP0808GM series is a full Gigabit managed industrial Ethernet switch independently developed by 3C-LINK. It has 8*10/100/1000M RJ45 ports and 8* 100/1000M SFP slot ports. 3CI-SFP0808GM can support L2+ network management function, supports IPV4/IPV6 management, it has rich network management features, and complete network security policy configuration, suitable for intelligent transportation, rail transit, electric power, mining, petroleum, shipping, metallurgy, and green energy construction. Industrial scenes form a cost-effective and stable communication network.
3CI-SFP0808GM has industry-leading ring network technology, supports a variety of industrial-grade redundant ring network protocols, any port can be looped, supporting chain, star, the double star, ring, tangent ring, intersecting ring, coupling Ring, ring net self-healing within 20ms. This series of models has high reliability, high security, and high manageability. It ensures reliable transmission of critical data, supports remote management, and can be clustered with the 3C-LINK-NMS network management platform of the optical network to achieve blind management. 3CI-SFP0808GM industrial grade series products fully comply with industrial product design and materials. The shell is made of aluminum alloy to enhance heat dissipation performance, and has excellent industrial field environment adaptability (including mechanical stability, climatic environment adaptability, electromagnetic environment adaptability, etc. ), protection class up to IP40, support dual redundant power supply, low power fanless cooling technology, MTBF average trouble-free working time up to 35 years, 5 years warranty.
3CI-SFP0808GM has industry-leading ring network technology, supports a variety of industrial-grade redundant ring network protocols, any port can be looped, supporting chain, star, the double star, ring, tangent ring, intersecting ring, coupling Ring, ring net self-healing within 20ms. This series of models has high reliability, high security, and high manageability. It ensures reliable transmission of critical data, supports remote management, and can be clustered with the 3C-LINK-NMS network management platform of the optical network to achieve blind management. 3CI-SFP0808GM industrial grade series products fully comply with industrial product design and materials. The shell is made of aluminum alloy to enhance heat dissipation performance, and has excellent industrial field environment adaptability (including mechanical stability, climatic environment adaptability, electromagnetic environment adaptability, etc. ), protection class up to IP40, support dual redundant power supply, low power fanless cooling technology, MTBF average trouble-free working time up to 35 years, 5 years warranty.
-----------------------------------Features----------------------------------
Full gigabit port
*All series supports " Ethernet ports and SFP fiber ports" combination, which enables users to flexibly build networking to meet the needs of various scenarios.
* Support non-blocking wire speed forwarding .
* Support full duplex based on IEEE802.3x and half duplex based on backpressure .
* Support non-blocking wire speed forwarding .
* Support full duplex based on IEEE802.3x and half duplex based on backpressure .
Strong business processing capability
*Support IEEE 802.1Q VLAN, users can flexibly divide VLAN according to needs, and support QinQ configuration.
*Support QoS, support port based, 802.1P based and DSCP based three priority modes and Equ, SP, WRR, SP+WRR four queue scheduling algorithms.
*ACL supports the filtering of data packets by configuring matching rules, processing operations and time permissions, and provides a flexible access control strategy.
*Support IGMP V1/V2 multicast protocol and support IGMP Snooping to meet the multi terminal HD video surveillance and video conference access requirements.
*Support STP/RSTP/MSTP production tree protocol, support G.8032 protocol ERPS rapid industrial ring to eliminate two-tier loops and achieve link backup.
*Support static convergence and dynamic convergence, effectively increases link bandwidth, achieves load balancing, link backup, and improves link reliability.
*Support IEEE 802.1Q VLAN, users can flexibly divide VLAN according to needs, and support QinQ configuration.
*Support QoS, support port based, 802.1P based and DSCP based three priority modes and Equ, SP, WRR, SP+WRR four queue scheduling algorithms.
*ACL supports the filtering of data packets by configuring matching rules, processing operations and time permissions, and provides a flexible access control strategy.
*Support IGMP V1/V2 multicast protocol and support IGMP Snooping to meet the multi terminal HD video surveillance and video conference access requirements.
*Support STP/RSTP/MSTP production tree protocol, support G.8032 protocol ERPS rapid industrial ring to eliminate two-tier loops and achieve link backup.
*Support static convergence and dynamic convergence, effectively increases link bandwidth, achieves load balancing, link backup, and improves link reliability.
Advanced security system
*Support 802.1X Authentication
*Support Port Isolation
*Support Storm Control
*Support Port-MAC Binding, IP-MAC-Port Binding.
*Support 802.1X Authentication
*Support Port Isolation
*Support Storm Control
*Support Port-MAC Binding, IP-MAC-Port Binding.
The equipment is stable and reliable
*The host has low power consumption, no fan mute design, aluminum alloy metal shell, excellent heat dissipation, and ensure stable operation of products.
*The equipment meets .CE.FCC and RoHS safety regulations, and is safe and reliable.
*The user can easily understand the working status of the device through the power indicator (PWR), port status indicator (Link/Act) operation indicator.
*The host has low power consumption, no fan mute design, aluminum alloy metal shell, excellent heat dissipation, and ensure stable operation of products.
*The equipment meets .CE.FCC and RoHS safety regulations, and is safe and reliable.
*The user can easily understand the working status of the device through the power indicator (PWR), port status indicator (Link/Act) operation indicator.
Efficient Management
For efficient management, the 3CIH-SFP0204GM Managed Ethernet Switch series is equipped with console, Web and SNMP management interfaces. With the built-in Web-based management interface, the 3CIH-SFP0204GM series offers an easy-to-use, platform-independent management and configuration facility. For text-based management, the 3CIH-SFP0204GM series can be accessed via console port. Moreover, it also offers secure remote management via any standard-based management software by supporting SNMPv1/v2/v3 connection which encrypts the packet content at each session.
For efficient management, the 3CIH-SFP0204GM Managed Ethernet Switch series is equipped with console, Web and SNMP management interfaces. With the built-in Web-based management interface, the 3CIH-SFP0204GM series offers an easy-to-use, platform-independent management and configuration facility. For text-based management, the 3CIH-SFP0204GM series can be accessed via console port. Moreover, it also offers secure remote management via any standard-based management software by supporting SNMPv1/v2/v3 connection which encrypts the packet content at each session.
Easy operation and maintenance management
*Supports various management and maintenance methods such as Web management, CLI command line (Console, Telnet), SNMP (V1/V2/V3).
*Supports encryption methods such as HTTPS, SSLV3, and SSHV1/V2 for more secure management.
*Support RMON, system log, port traffic statistics, easy network optimization and transformation.
*Support LLDP, which is convenient for the network management system to query and judge the communication status of the link.
*Support CPU monitoring, memory monitoring, ping detection, cable length detection.
*Supports various management and maintenance methods such as Web management, CLI command line (Console, Telnet), SNMP (V1/V2/V3).
*Supports encryption methods such as HTTPS, SSLV3, and SSHV1/V2 for more secure management.
*Support RMON, system log, port traffic statistics, easy network optimization and transformation.
*Support LLDP, which is convenient for the network management system to query and judge the communication status of the link.
*Support CPU monitoring, memory monitoring, ping detection, cable length detection.
Redundant Ring, Fast Recovery for Critical Network Applications
The 3CIH-SFP0204GM supports redundant ring technology and features strong, rapid self-recovery capability to prevent interruptions and external intrusions. It incorporates advanced ITU-T G.8032 ERPS (Ethernet Ring Protection Switching) technology, Spanning Tree Protocol (802.1s MSTP), and redundant power input system into customer’s industrial automation network to enhance system reliability and uptime in harsh factory environments. In a certain simple Ring network, the recovery time of data link can be as fast as 10ms.
The 3CIH-SFP0204GM supports redundant ring technology and features strong, rapid self-recovery capability to prevent interruptions and external intrusions. It incorporates advanced ITU-T G.8032 ERPS (Ethernet Ring Protection Switching) technology, Spanning Tree Protocol (802.1s MSTP), and redundant power input system into customer’s industrial automation network to enhance system reliability and uptime in harsh factory environments. In a certain simple Ring network, the recovery time of data link can be as fast as 10ms.
| Model | 3CI-SFP0808GM |
| Interface | 8*10/100/1000M RJ45 ports (Data); 8*100/1000M SFP solt ports(Data) 1 * RS232 console port(115200,N,8,1) 2 groups V+, V- redundant DC power interface (3P phoenix terminal) |
| Network Protocol | IEEE802.3 10BASE-T; IEEE802.3i 10Base-T; IEEE802.3u 100Base-TX; IEEE802.3ab 1000Base-T; IEEE802.3z 1000Base-X; IEEE802.3x |
| Ethernet Port Feature | Port 1-4 can support 10/100/1000BaseT(X),auto-sensing, full/half duplex MDI/MDI-X self-adaption |
| SFP Port | Gigabit SFP optical fiber interface, default matching optical modules, need to buy separately, (optional order mode / multi-mode, single fiber / double fiber optical module. |
| Forwarding Mode | Store and Forward(Full Wire Speed) |
| Switching Capacity | 128Gbps |
| Forwarding Rate@64byte | 8.93Mpps |
| MAC | 8K |
| Buffer Memory | 4M |
| Twisted Pair Transmission | 10BASE-T: Cat3,4,5 UTP(≤100 meter) ; 100BASE-TX: Cat5e or later UTP(≤100 meter) ; 1000BASE-T: Cat5e or later UTP(≤100 meter) |
| Fiber Cable | Multi-mode:850nm 0~550M,Single-mode:1310nm 0~40KM,1550nm 0~120KM. |
| Operating Voltage | DC power supply, DC48-57V ultra-wide power supply voltage, workmanship 5P Phoenix terminal connection, support anti-reverse protection |
| LED | Power Indicator : PWR (green); System Indicator :SYS (green); Network Indicator: Link/ (yellow);SFP Indicator: L/A (green); |
| Reset switch | Yes,support one key to restore factory settings. |
| Power Supply | No, you can purchase industrial power supply24V/24W, see the accessory information table for purchase. |
| Operation TEMP / Humidity | -40~+80°C;5%~90% RH Non condensing |
| Storage TEMP / Humidity | -40~+85°C;5%~95% RH Non condensing |
| Dimension | 181*146*47mm |
| Net /Gross Weight | <0.8kg / <1.2kg |
| Installation Method | Desktop type,DIN rail mounting |
| Lightning Protection / Protection Level | Port lightning protection : 6KV 8/20us;Protection level: IP40 IEC61000-4-2(ESD)±8kV Contact Discharge,±15kV Air Discharge IEC61000-4-3(RS)10V/m (80~1000MHz) IEC61000-4-4(EFT)Power Line: ±4kV; Data Line: ±2kV IEC61000-4-5(Surge)Power Line,CM±4kV/DM±2kV;Data Line,±4kV IEC61000-4-6 (Radio Frequency Conduction) 10V (150kHz~80MHz) IEC61000-4-8 (Power Frequency Magnetic Field) 100A/m Continued; 1000A/m,1s to 3s IEC61000-4-9 (Pulsed Magnetic Field) 1000A/m IEC61000-4-10 (Damping Oscillation) 30A/m ,1MHz IEC61000-4-12/18 (SHOCKWAVE) CM 2.5kV, DM 1kV IEC61000-4-16 (Common Mode Conduction) 30V Continued; 300V,1s FCC Part 15/CISPR22(EN55022) Class B IEC61000-6-2(General Industry standard) |
| Mechanical Properties | IEC60068-2-6 (anti vibration) IEC60068-2-27 (anti shock) IEC60068-2-32 (free fall) |
| Certification | CCC; CE mark, commercial;CE/LVD EN60950;FCC Part 15 Class B; ROHS; |
| Warranty | 5 years, lifelong maintenance. |
| Business features (only restricted management function models) | |
| Port | Support IEEE802.3x flow control (full duplex) Support for broadcast storm suppression based on port rate support speed limit for incoming and offline message traffic, with a minimum particle size of 64Kbps. Support port temperature protection settings Support port EEE green Ethernet energy saving configuration |
| Layer 3 Function | Support L2+ Layer 3 soft routing forwarding, non-linear speed Support static routing / default routing 128, 1024 ARP software forwarding |
| VLAN | Support port based VLAN (4K), IEEE802.1q Support protocol based VLAN Support Access, Trunk, Hybrid three types of port configuration Support QinQ configuration |
| Port Aggregation | Support LACP Support static polymerization Support the largest 8 aggregation groups, each aggregation group supports 8 ports. |
| Spanning Tree | Support STP (IEEE802.1d) Support STPRSTP (IEEE802.1w) Support STP MSTP (IEEE802.1s) |
| Industrial Ring Network Protocol | Support G.8032 (ERPS), support 255 loops at most, and supports 1024 devices per ring. The self healing time of the ring network is less than 20ms |
| Multicast | Support IGMP Snooping V1/V2 and support 1024 multicast groups at most. Support the user's quick departure mechanism Support MLD Snooping V1/V2 Support multicast VLAN |
| Image | Bi-directional traffic mirroring supporting the basic port |
| QoS | Support Diff-Serv QoS Each port supports 8 output queues Support 802.1p/DSCP priority mapping Support queue scheduling mechanism (SP, WRR, SP+WRR) Support priority tag Mark/Remark Support stream based packet filtering Support for stream based redirection Support flow based speed limit |
| ACL | Support L2 to L4 packet filtering function, can match the first 80 bytes of the message, provide based on the source MAC address, destination MAC address, source IP address, destination IP address, IP protocol type, TCP/UDP port, TCP/UDP port range, VLAN and other definition ACL. Support ACL based on port and VLAN |
| Safety Characteristics | Support user grading management and password protection Support IEEE802.1X authentication / centralized MAC address authentication Support AAA&RADIUS authentication Support the number of MAC address learning restrictions Support MAC address black hole Support SSH 2 to provide secure passwords for user login. Support SSL to ensure data transmission security Support port isolation Support the speed limit function of ARP message Support IP source address protection Support ARP intrusion detection function Support against DoS attacks Support port broadcast message suppression Support host data backup mechanism Binding capabilities of IP+MAC+VLAN+ ports |
| DHCP | Support DHCP Client Support DHCP Snooping Suport DHCP Serve Suport DHCP Relay |
| Management And Maintenance | Support Console/AUX Modem/Telnet/SSH2.0 CLI command line configuration Support WEB network management (HTTPS) Support FTP, TFTP, Xmodem, SFTP file download management Support SNMP V1/V2C/V3 Support one bond reduction Support NTP clock Support system work log Support Ping detection Support cable state detection Support CPU instant utilization status view Support link layer discovery protocol LLDP Support 3C-LINK NMS intelligent management center |
---------------------------------Applictaion--------------------------------
-------------------------------Order Information------------------------------
| Order Information | |
| 3CI-SFP0808GM | Industrial Ethernet Switch, 8 SFP Slots+ 8 * 10/100/1000M. DC 12~48V |
| 3CI-PSE0808GM | Industrial Ethernet Switch, 8 SFP Slots+ 8 * 10/100/1000M POE ( 802.3af/ 802.3at) DC 48~56V |
