Coloreeze автомобильная портативная Автомобильная окрасочная камера

Features

Total Power 58kw;380v/3phase/50hz Noise<80db

1.Wallboard & roof panel

-EPS colorful steel panel board, 75mm thick, tongue & groove style, steel 0.6mm thickness. Compound construction, anti-flame and
heat-insulation, galvanized steel roof panel.

2. Basement

- Metal Pedestal (Galvanized then powder coated on the surface), with Filter Tray* 5rows & Ramps a couple

- Grid Plates (Galvanized)* 5rows

3. Heating System
(gas and electricity)

- Gas Burner (Italy Riello,FS20,200000Kcal/h)* 1unit
- Heating Exchanger (Stainless Steel material)* 1unit
- Electric heating: Quantum radiator 36kw, part of them could be moved.
- Heating energy recycling: One set of heating energy recycling system to recycle 60% heat energy for reusing.
- 5-10 minutes reaching the baking temperature 60-80°C
- Cabinet (rock wool insulation) for the burner & heat exchanger* 1unit; Air Ducts* 2pcs

4. Four-stage Filter System

- A Primary Filter* 1set, HP Ultrathin filter
- B Air-Intake Filter* 1set, CC-600G high efficiency filter(ceiling filrer), flame-resisting levelclass F5, thickness 25mm.
- C Air-Exhaust Filter* 2set of fiberglass flter.
- D Air-Exhaust Filter* 1set of worm curtain and ultrafilter. The worm curtain made by 304 stainless Steel, the ultrafilter could
be reused.

5. Air circulation System

- Air-Intake Fan* 1unit, DDF-630B turbo Fan with 7.5kw motor air flow 22000m3/hour.
- Air-Exhaust Fan* 1unit, DDF-630B turbo Fan with 7.5kw motor air flow 22000m3/hour.
- Exaust air pressure regulator* 1 set.
- Cabinet for the fans* 1 unit, the frame made by 50*50 powder coated square steel, the cabinet panel made by powder coated
galvanized steel, 0.8 thickness, insulated with 30mm rockwool.
- Air Ducts* 3pcs, and Air Damper (pneumatic)* 1 unit.

6. Water-based paint system

- Spary nozzle*59pcs, direction adjustable. The air duct made by 0.7mm galvanized steel.
- Air intake fan* 2set, YDW4.5AL, air flow 20000m3/hour.

7. Illumination

- Ceiling Lights* 32pcs, 36w each, with electronic ballasts, powder-coated light box, tempered glass.
- Side Lights* 20pcs, 30w each, with electronic ballasts, powder-coated light box, tempered glass.

8. Control Panel

- *1 unit, PLC control, including Power switch, common paint spary/baking switch, water-based paint spray/baking, light switch,
temperature display, humidity display, time setting, fault alarm, emergency stop, etc.

9. Eviromental handling

- Water rotary machine* 1 unit, to handle the exhause paint mist.
- The water base paint could be reused after filtered by untrafilter system. The common paint could be fired or be buried.
