Безмасляный кислородный бустер компрессор больничный медицинский цилиндр наполнение газ 100нм
- Категория: Воздушный компрессор >>>
- Поставщик: Dhh,Compressor,Jiangsu,Co.,Ltd
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-16-2025 | 1326738.65 $* | 1393075.33 $* |
| Aug-16-2025 | 1315589.47 $* | 1381368.2 $* |
| Jul-16-2025 | 1103757.72 $* | 1158945.7 $* |
| Jun-16-2025 | 1293291.67 $* | 1357956.74 $* |
| May-16-2025 | 1126055.3 $* | 1182358.92 $* |
| Apr-16-2025 | 1270993.69 $* | 1334543.8 $* |
| Mar-16-2025 | 1259844.26 $* | 1322836.56 $* |
| Feb-16-2025 | 1248695.49 $* | 1311130.52 $* |
| Jan-16-2025 | 1237546.30 $* | 1299423.5 $* |
Характеристики
Product Description
1. Medium: Oxygen
2. Inlet pressure: 1.5bar
3. Temp. Input: ≤ 40 ℃
4. Discharge pressure: 200bar
5. Temp. discharge: ≤ 50 ℃
6. Volume: 100 Nm3 / h
7. Piston stroke: 110mm
8. Compression level: 4stages
9. Structure type: Vertical 100% oil-free
10. Number of cylinders: 4 cylinders
11. RPM: 320r / min
12. Voltage: 220v / 60hz / 3ph
13. Cooling: water
14. Cooling volume: 5T-hour
15. Spindle power: ≤36.5kw
16. Engine rpm: 970r / min
17. Oxygen inlet / outlet: 50, M22 mm
18. 40mm water inlet and outlet
19. Dimensions: 2100X1100X1600mm 20. Weight: 1.6T
21. Coupling: Belt
22. Material of cylinder, valve, piping, cooler: stainless steel
|
Medium |
oxygen |
Number |
|
|
|
Inlet pressure MPa(G) |
0.15 |
Intake air temperature ℃ |
≤ 40 |
|
|
Exhaust pressure Mpa(G) |
20.0 |
Exhaust temperature (after cooling) ℃ |
≤ 50 |
|
|
Volumeflow ( Nm3/h) |
100 |
Piston stroke mm |
110 |
|
|
Model |
GOW-100/1.5-200 |
Compression stages |
4 |
|
|
Structure type |
Fully oil-free vertical |
Number of cylinders |
4 |
|
|
Crankshaft speed (r/min) |
320 |
Voltage V |
220 |
|
|
Cooling method |
Water cooling |
Cooling water flow( t/h) |
5.0 |
|
|
Shaft power (kW) |
≤36.5kw |
Motor speed (r/min) |
970 |
|
|
Inlet and outlet interface (mm) |
50,M22 |
Water inlet and outlet (mm) |
40 |
|
|
Motor |
45KW 220V 60Hz |
|||
|
Dimensions(mm*mm*mm) |
2100X1100X1600 |
Unit weight T |
1.6 |
|
|
Transfer method |
Belt drive |
|||
|
Material of parts in contact with gas |
Cylinder |
Stainless steel |
||
|
Air valve |
Stainless steel |
|||
|
Piping, cooler |
Stainless steel |
|||
Certifications
About us
Dehaha Compressor was founded in 1996 with over 150 skilled employees and more than 25 R&D engineersteams ’ .We focus on the research & develop,manufacture and energy-saving solutions of screw air compressor to create value for customers and society.In 2018 our total sales volume approached 15 million US dollars.By over 23 years enhanced experiences of designing,producing and marketing,today our valued customers are over 130 countries.
Germany Standard and 13 years exporting experience help us won more than 50 loyal overseas agents.
Dehaha’s primary businesses focus in following key areas:
Oil-injected rotary screw compressors
Portable screw air compressors
Oil free air compressors
High pressure air compressors
Air treatment equipment
At Dehaha,we earn our customers' trust and satisfaction by manufacturing the superior quality compressed air
products for all industries.All of our products are designed for reliable performance,easy maintenance,and maximum energy efficiency.We have sales representatives who can speak English,Spanish,French,and Russian which makes it easier for our clients from all over the world to interact and negotiate with us.
Dehaha continuously innovates product development and management to meet customers' demand.The powerful enterprise culture and continuous innovation make Dehaha improved rapidly to reach the business principle"Energy Saving First, Mutual Value Shared". Dehaha mission is to be a world-renowned high-end brand,with sustainable development,constantly improving its own value and sharing it with our customers and staff.Committed to offer our customers a silent and energy-saving manufactured products.
