Маленький мотор переменного тока с высоким крутящим моментом Реверсивный миниатюрный бесщеточный двигатель для гранул редукторный
- Категория: Двигатель переменного тока >>>
- Поставщик: Chengdu,Lunyee,Imp.,&,Exp.,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Aug-20-2025 | 42.29 $* | 43.94 $* |
| Jul-20-2025 | 34.14 $* | 35.69 $* |
| Jun-20-2025 | 41.23 $* | 42.48 $* |
| May-20-2025 | 41.73 $* | 42.75 $* |
| Apr-20-2025 | 33.5 $* | 34.94 $* |
| Mar-20-2025 | 40.66 $* | 41.81 $* |
| Feb-20-2025 | 40.93 $* | 41.81 $* |
| Jan-20-2025 | 40.85 $* | 41.71 $* |
Характеристики
Small High Torque AC Motor Reverisable Tiny brushless Motor Pellet Stove Gear Motor
Products Description
The following are the specifications that our company's Micro AC gear motors 140w can achieved. You can also contact us to tell us the power, voltage, torque and other parameters you need. We can accept and customize. and You can also contact us for drawings and detailed parameters. | ||
Band name | Lunyee | |
Output Power | 140w | |
Dimension | 90mm | |
Voltage | 110v | |
Frequency | 50Hz 60Hz | |
Phase | Single phase | |
Rated Speed | 1350/1680 r/min | |
Current | 3.44 A | |
Starting torque | 1.038/1.287 N.M | |
Rated torqur | 0.796/0.99 N.M | |
Rated time | 30 minutes | |
Capacitor | 25/250 uF/VAC | |
Motor Shaft type | Pinion shaft Round shaft Keyway | |
Accessories that can be added | gear box Terminal box w/fan w/ forced fan eleceromagnetic brake thermally | |
Micro ac gear motor type | Induction motor Reversible motor Torque motor Speed control motor Right angle gear motor Brake motor | |
Reduction motor max allowable torque(the rated torque)
Motor drawings
Product Overview
Features:
Space-saving High efficiency Reliable and durable
High torque Low speed
High torque Low speed
High overload capacity
Superior performance
Low energy consumption
Low noise Long life small vibration
Strong reliability Running smoothly
Low noise Long life small vibration
Strong reliability Running smoothly
Brushless environmental protection
Simple structure easy to use
Factory supplier best price
unique waterproof and moisture-proof design
Suitable for extreme environments
Wide range of applications
Simple structure easy to use
Factory supplier best price
unique waterproof and moisture-proof design
Suitable for extreme environments
Wide range of applications
Product Details
Compact structure, good sealing performance, low noise, long life，low operating temperature Adjustable speed, reversible, forward and reverse
Application
AC gear motor widely used in Industrial equipment, machine tools, agricultural appliances, commercial office, medical equipment, household appliances, aviation and other fields. Such as treadmill, sewing machine, meat grinder , tortilla press maker, Apparel Machine, Textile Machine, Metal Coating Machinery, Pumps, Sprayers, heavy mine equipment, Packing Machine, nebulizer, table fan, Face Mask Machine, Rehabilitation Therapy Supplies, refrigerator, Air Purifiers, Fermenting Equipment. Automatic Electric BBQ rotisserie grill, Harvesting machine, Electric fireplace Pellet Stove , industrial Boiler, Stir Fry Machine, Nuts roaster roller, Rolling billboard, Pasteurization Machine, Vending machine, Note Counting Machine, stiring device, packing equipment, transmit equipment, etc.
