Универсальный двигатель переменного тока Lunyee 220 В 300 Вт/250

Универсальный двигатель переменного тока Lunyee 220 В 300 Вт/250

Категория: AC Motor >>>
Поставщик: Henan,Lunyee,Industrial,Automation,Equipment,Co.,Limited

Цена:*

Количество:

Описание и отзывы

Трекер стоимости

Месяц	Минимальная цена	Макс. стоимость
Sep-17-2025	0.79 $*	0.97 $*
Aug-17-2025	0.78 $*	0.17 $*
Jul-17-2025	0.47 $*	0.5 $*
Jun-17-2025	0.70 $*	0.58 $*
May-17-2025	0.64 $*	0.23 $*
Apr-17-2025	0.9 $*	0.50 $*
Mar-17-2025	0.6 $*	0.0 $*
Feb-17-2025	0.87 $*	0.21 $*
Jan-17-2025	0.85 $*	0.18 $*

Характеристики

Lunyee 220V 380V 250W 300W ac motor speed control

Product Description

In selecting the most suitable motor and reducer, the working con ditions of the load must be ascertained first before load calculations are performed,
the decide the model of the matching motor and gear box required, and finally decide in the installation structure for the motor and gearbox according to installation requirements

Lunyee 220V 380V 250W 300W ac motor speed control

Motor Technical Parameters:

	Motor with round shaft	Motor with gear shaft	Power W	Voltage V	Frequency Hz	Current A	Stating Torque N.M	Rated Torque N.M	Rated Speed r/min	Rated Time min	Capacitor uF/VAC
Induction motor	6IK250/300A-AF	6IK250/300GU-AF	250/300	1HP110V	50	7.371	2.759	2.122	1350	continuously	30/250
					60	7.371	2.217	1.705	1680
	6IK250/300A-CF	6IK250/300GU-CF	250/300	1HP220V	50	3.686	2.759	2.122	1350		10/450
					60	3.686	2.217	1.705	1680
	6IK250/300A-SF	6IK250/300GU-SF	250/300	3HP220V	50	4.631	3.608	2.122	1350
					60	4.631	2.899	1.705	1680
	6IK250/300A-UF	6IK250/300GU-UF	250/300	3HP380V	50	2.681	3.608	2.122	1350
					60	2.681	2.899	1.705	1680
Reversible motor	6RK250/300A-AF	6RK250/300GU-AF	250/300	1HP110V	50	7.371	2.759	2.122	1350	30	30/250
					60	7.371	2.217	1.705	1680
	6RK250/300A-CF	6RK250/300GU-CF	250/300	1HP220V	50	3.686	2.759	2.122	1350	30	10/450
					60	3.686	2.217	1.705	1680
Brake motor	6IK250/300A-AFM	6IK250/300GU-AFM	250/300	1HP110V	50	7.371	2.759	2.122	1350	30	30/250
					60	7.371	2.217	1.705	1680
	6IK250/300A-CFM	6IK250/300GU-CFM	250/300	1HP220V	50	3.686	2.759	2.122	1350	30	10/450
					60	3.686	2.217	1.705	1680
	6IK250/300A-SFM	6IK250/300GU-SFM	250/300	3HP220V	50	4.631	3.608	2.122	1350	continuously
					60	4.631	2.899	1.705	1680
	6IK250/300A-UFM	6IK250/300GU-UFM	250/300	3HP380V	50	2.681	3.608	2.122	1350
					60	2.681	2.899	1.705	1680

Reduction Motor Max Allowable Torque (the Rated Torque):

	Motor with round shaft	Motor with gear shaft	Power W	Voltage V	Frequency Hz	Speed Control Range	Stating Torque N.M	Rated Torque N.M 90r/min 1350r/min		Rated Time min	Capacitor uF/VAC
Induction motor	6IK250/300RA-AF	6IK250/300RGU-AF	250/300	1HP110V	50	90-1400	41.38	31.82	2.12	continuously	30/250
					60	90-1400	41.38	31.82	1.71
	6IK250/300RA-CF	6IK250/300RGU-CF	250/300	1HP220V	50	90-1400	41.38	31.82	2.12		10/450
					60	90-1400	41.38	31.82	1.71

Micro AC gear motor series product model explanation:

Motor drawing:

Gear box drawing:

Motor application:

We are one stop supplier of CNC machine at good cost performance! Our goal is to help our customer get the satisfying machine tool by minimum cost!

The company produces the mini ac geared motor 6W-400W: Small gear reduction motor 01 W-75KW; Linear motor 6w-400w; right-angle reducer 25W-400W;

hyperboloid rectangular axis reducer 25w--750w: Permanent magnet DC motor 6w-750w: High precision economical type planetary gear reducer PL60-160 with precision stepper, servo motor:

The RV turbine gear motor and precise speed controller, etc. Products are widely used in packaging machinery, food machinery, tea machinery, agricultural machinery. biomassboiler, precision machine and tool automation control equipment, etc.
