Pump Sensor Switch Water Fow switch Power Air Relay Color Signal Output Liquid Water Pipe



Model No.:QXL-120



1, Usage

According to different switch control methods, it can be used for two ways: water supply or water discharge. It can be used for rapid water heater water supply control and water storage type electric water heater water supply and power failure control.



2, Working Principal

When there is water flowing in the water flow switch, when the water flow rate is ≥1.0L/min, the magnetic core in the water flow switch is driven to be displaced by the water flow, and the magnetic core displacement drives the magnetic source to generate a magnetic control action to make the water flow switch output a “on” signal. The signal input device control system realizes the control function through the control system. When the water flow rate is less than the startup flow rate, the water flow switch outputs a “off” signal. The control system produces the opposite control effect as described above.



3, Working Parameter

No.	Attribute	Parameter
1	Model No.	QXL-120
2	Product Name	Brass Flow Switch
3	Port Diameter	G1/2 Male Thread
4	Switching Current	0-6A
5	Switching Power	90W-2200W
6	Switching Voltage	0-220VDC
7	Switching Flow Range	1-30L/min
8	Working temperature	1~120℃
9	Maximum water pressure	2.0MPA
10	Service Life	100,000 times
