Силовой Резистор в коробке блок сопротивления для торможения при промышленном
- Категория: Резисторы >>>
- Поставщик: Xinghua,Jingding,Electric,And,Instruments,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-16-2025 | 0.1 $* | 0.90 $* |
| Aug-16-2025 | 0.68 $* | 0.7 $* |
| Jul-16-2025 | 0.25 $* | 0.52 $* |
| Jun-16-2025 | 0.4 $* | 0.68 $* |
| May-16-2025 | 0.60 $* | 0.32 $* |
| Apr-16-2025 | 0.46 $* | 0.13 $* |
| Mar-16-2025 | 0.38 $* | 0.94 $* |
| Feb-16-2025 | 0.87 $* | 0.70 $* |
| Jan-16-2025 | 0.1 $* | 0.35 $* |
Характеристики
Product Description
Technical parameters:
·Power range: 500w-15kw
·Resistance range: 10 Ω -- 180 Ω
·Withstand voltage range: ac2.5kv/1min, leakage current ≤ 20mA
·Rated temperature rise: ≤ 600 ℃
·Packaging: carton packaging
Technical parameters of resistance box:
| Serial number | length (mm) L | width (mm) W | height(mm) H | installation hole distance (mm) L1 * W2) | rated power (KW) | resistance value (Ω) | ±5%(J) ±10%(K) |
| 1 | 370 | 260 | 100 | 350*200 | 0.5KW-1.6KW | 5-180 | |
| 2 | 370 | 260 | 150 | 350*200 | 3.2KW | 5-135 | |
| 3 | 460 | 260 | 100 | 440*200 | 2.0KW-2.5KW | 5-180 | |
| 4 | 460 | 260 | 150 | 440*200 | 3.0KW-5.0KW | 5-180 | |
| 5 | 460 | 260 | 200 | 440*200 | 5.5KW-10KW | 5-180 | |
| 6 | 530 | 260 | 150 | 440*200 | 6.0KW-6.4KW | 5-180 | |
| 7 | 530 | 260 | 200 | 440*200 | 8.0KW-9.6KW | 5-180 | |
| 8 | 530 | 260 | 230 | 440*200 | 8.0KW-15KW | 5-180 | |
| 9 | 460 | 200 | 100 | 440*120 | 0.5KW-2.5KW | 5-135 | |
| 10 | 460 | 200 | 150 | 440*120 | 3.0KW-8.0KW | 5-135 |
Application
Elevator industry
products are widely applied in elevator industry which bring you more convenient in your work and life, with the perfect combination, elevator could work safely and steadily and offer comfortable service for all of you.
