HDMI-IP-кодировщик 1080p h.264 iptv прямая трансляция видео
- Категория: TV Receivers & Accessories >>>
- Поставщик: Nantong,ZYDZ,Electronic,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Aug-18-2025 | 171.42 $* | 174.32 $* |
| Jul-18-2025 | 139.62 $* | 142.10 $* |
| Jun-18-2025 | 169.36 $* | 172.66 $* |
| May-18-2025 | 167.31 $* | 170.5 $* |
| Apr-18-2025 | 134.50 $* | 137.0 $* |
| Mar-18-2025 | 165.78 $* | 168.68 $* |
| Feb-18-2025 | 163.44 $* | 166.5 $* |
| Jan-18-2025 | 162.5 $* | 165.36 $* |
Характеристики
Product Description
1080P H.264&H.265 HD IPTV Encoder For Youtube Facebook Live Streaming HDMI IP Video Encoder
.
Good New: Product upgrade support POE, if you need this function pls contact us before order. POE is not supported on the device shipped by default
Good New: Product upgrade support POE, if you need this function pls contact us before order. POE is not supported on the device shipped by default
Product performance
✔ H.264&H.265 video encoding
✔ Maximum resolution is 1080P@60hz
✔ HDMI 1.4/HDCP 1.4 Standards
✔ HDMI built-in audio
✔HTTP/RTSP/RTMP/RTMPS/UDP/RTP/FLV
/FLS/ONVIF/Multicast…
✔ OSD Set, Support TXT and pictures
✔ WEB management interface
✔ Remote management
✔ Free firmware updating
✔ NTP Setting: support to add time zone server in encoder, and synchronous display
the word time. Such as:YY/Month/Dat
✔ HDMI 1.4/HDCP 1.4 Standards
✔ HDMI built-in audio
✔HTTP/RTSP/RTMP/RTMPS/UDP/RTP/FLV
/FLS/ONVIF/Multicast…
✔ OSD Set, Support TXT and pictures
✔ WEB management interface
✔ Remote management
✔ Free firmware updating
✔ NTP Setting: support to add time zone server in encoder, and synchronous display
the word time. Such as:YY/Month/Dat
Product Advantages
✎ Powerful streaming media service function
1. HTTP, UDP/RTP, RTSP, RTMP/RTMPS, ONVIF, HLS, FLV and some other streaming
media.Protocols supported for live broadcast on Facebook, YouTube, Ustream, Twitch, Wowza etc or security platform/ NVR system.
2. Dual-stream output, the main-encode resolution up to 1080P@60Hz and the sub-stream resolution up to 720P@60Hz video encoding.
✎ Good performance: Transmit high definition, low-latency, the non-padding image under low bit network
1. With branded chips solution together with video dynamic noise reduction and image enhancement technology, it can realize good
encoding image under low bit transmission. Good video image can be achieved at 1Mbps@720p, 2Mbps@1080p network.
2. Latency≤200ms, Note: (≤200ms) refers to the delay of the encoder end, and the end-to-end delay also relates to network,
decoding, etc
3. Adjustable bit rate from 16kbit/s～12Mbit/s.
✎ Strong flexibility to support secondary development, customized service available
1. SDK provided for second development
2. OEM/ODM
3. Free firmware upgrade for lifetime
4. Print customer’s logo on the shell of the device and web interface
✎ Easy operation and professional quality
1. Using Web interface to manage device. and setting are very easy. It is widely used in broadcast and TV
2. interactive media, IPTV systems, network education, secure safety and other fields, professional and stable.
media.Protocols supported for live broadcast on Facebook, YouTube, Ustream, Twitch, Wowza etc or security platform/ NVR system.
2. Dual-stream output, the main-encode resolution up to 1080P@60Hz and the sub-stream resolution up to 720P@60Hz video encoding.
✎ Good performance: Transmit high definition, low-latency, the non-padding image under low bit network
1. With branded chips solution together with video dynamic noise reduction and image enhancement technology, it can realize good
encoding image under low bit transmission. Good video image can be achieved at 1Mbps@720p, 2Mbps@1080p network.
2. Latency≤200ms, Note: (≤200ms) refers to the delay of the encoder end, and the end-to-end delay also relates to network,
decoding, etc
3. Adjustable bit rate from 16kbit/s～12Mbit/s.
✎ Strong flexibility to support secondary development, customized service available
1. SDK provided for second development
2. OEM/ODM
3. Free firmware upgrade for lifetime
4. Print customer’s logo on the shell of the device and web interface
✎ Easy operation and professional quality
1. Using Web interface to manage device. and setting are very easy. It is widely used in broadcast and TV
2. interactive media, IPTV systems, network education, secure safety and other fields, professional and stable.
Product Specifications
Model | ZY-EH311 | |
Video | Sponge | |
Input interface | 1×HDMI | |
Support resolution | 1920*1080P@60fps,30fps 1680*1050/1600*900/1440*900/1400*1050/1366*768/1360*768/1280*1024/1280*960/1280*800 1280*768/1280*720/1280*600/1152*864/1024*768/800*600 etc. | |
Output interface | 1×Ethernet port(RJ45) HDMI Loop-out | |
Output resolution | Auto 1920*1080/1680*1200/1440*1050/1440*900/1360*768/1280*720/1280*800/1280*768 1024*768/1024*576/960*540/850*480/800*600/720*540/720*480/720*404/704*576 640*480/640*360/480*270 | |
Video encoding | H.264 Baseline Profile H.264 Main Profile H.264 High Profile | |
Code Rate control | 16kbps- 12Mbps | |
Code Rate | CBR/VBR | |
Audio | ||
Input interface | External audio* 1 | |
Audio encoding | ACC, MP3 | |
Sampling rate | Auto | |
Bit-rate Option | 32k,44.1K,48K,64K,96K,128K,160K,192K,384K | |
Sampling Accuracy | 24 Bit | |
Audio Data-rate | 64Kb/s to 384Kb/s | |
Network | ||
RJ45 | 10M/1000M Ethernet port | |
Program streaming | HTTP, UDP/RTP, RTSP, RTMP/RTMPS, ONVIF, HLS, FLV | |
Control Panel | Web panel ( Language is English), remote upgrade | |
Firmware Update | Enable by uploading files to the dashboard | |
General | ||
Dimension(W*L*H) | Dimension(W*L*H) | |
Gross Weight | 0.3kg | |
Temperature | 0 ~ 45℃（for working）,-20~60℃（for storing) | |
Humidity | <90%, non-condensing | |
Input Voltage | DC 12V/1A | |
Power Consumption | 5W | |
Topological Diagram
Product Application
Product Family
Model | H.264/H.265 | Input Interface | Local Loopout | Wifi Module | Audio | Maximum Resolution | Size |
ZY-EH111 | H.264 | HDMI * 1 | √ | × | HDMI Built in audio 3.5mm external audio | 1080P@60hz,30hz | Small box |
ZY-EH111W | H.264 | HDMI * 1 | √ | √ | HDMI Built in audio 3.5mm external audio | 1080P@60hz,30hz | Small box |
ZY-EH401 | H.264 | HDMI * 1 | √ | × | HDMI Built in audio 3.5mm external audio | 4K@30 | Small box |
ZY-EH404 | H.264 | HDMI * 4 | × | × | HDMI Built in audio 3.5mm external audio | 4K@30 | Small box |
ZY-EH408 | H.264 | HDMI * 8 | × | × | HDMI Built in audio 3.5mm external audio | 1080P@60hz,30hz | 1U Rack |
ZY-EH121 | H.264 | HDMI * 1 | √ | × | HDMI Built in audio 3.5mm external audio | 1080P@60hz,30hz | 1U Rack |
ZY-EH114 | H.264 | HDMI * 4 | √ | × | HDMI Built in audio 3.5mm external audio | 1080P@60hz,30hz | 1U Rack |
ZY-EH1016 | H.264 | HDMI * 16 | × | × | HDMI Built in audio | 1080P@60hz,30hz | 3U Rack |
ZY-EH1116 | H.264 | HDMI * 16 | √ | × | HDMI Built in audio 3.5mm external audio | 1080P@60hz,30hz | 3U Rack |
FAQ
1. Provide OEM & ODM
OEM: Add customer information in software version and control web for free, MOQ is 1 unit
OEM: Add customer logo on the shell of the device for free, MOQ is 10 units
ODM: The customers can provide your customized requirements, We can evaluate production possibilities for our customers for free,but have to pay for development cost.
2. Provide remote technical support service
Our engineers can provide professional technical support services to customers through remote software, such as
Teamviewer,Skype,whatsapp etc.
3. 3 years warranty
We provide new free spare parts in 3 years because of the product quality problems, except for man-made damage.
4. Provide factory repair service
If the customer has a problem with the equipment, he can send it back to the factory for repair. Maintenance is free, but there will be a material charge.
5. About Import tax
I hope you know that import duty is paid on imported goods in most countries. Our all quote and price don't include your import tax. As to specific rates, please consult your local customs office. I appreciate your understanding!
6. About delivery time
OEM: Add customer information in software version and control web for free, MOQ is 1 unit
OEM: Add customer logo on the shell of the device for free, MOQ is 10 units
ODM: The customers can provide your customized requirements, We can evaluate production possibilities for our customers for free,but have to pay for development cost.
2. Provide remote technical support service
Our engineers can provide professional technical support services to customers through remote software, such as
Teamviewer,Skype,whatsapp etc.
3. 3 years warranty
We provide new free spare parts in 3 years because of the product quality problems, except for man-made damage.
4. Provide factory repair service
If the customer has a problem with the equipment, he can send it back to the factory for repair. Maintenance is free, but there will be a material charge.
5. About Import tax
I hope you know that import duty is paid on imported goods in most countries. Our all quote and price don't include your import tax. As to specific rates, please consult your local customs office. I appreciate your understanding!
6. About delivery time
Our the fast delivery time will be within 3 days after payment. But we promise to arrange the delivery
within 7 days after receiving the payment, In case of special circumstances.If you want to know more about the delivery time, pls contact us.
7.About the shipping way
Customers can choose their own logistics company when placing orders. Or contact us to specify our desired logistics company. Such us FedEx/ UPS/EMS/ ARAMEX/DHL etc. If you need to know the specific shipping time, please contact us.
within 7 days after receiving the payment, In case of special circumstances.If you want to know more about the delivery time, pls contact us.
7.About the shipping way
Customers can choose their own logistics company when placing orders. Or contact us to specify our desired logistics company. Such us FedEx/ UPS/EMS/ ARAMEX/DHL etc. If you need to know the specific shipping time, please contact us.
Contact Us
♡ If you have problem of shipping & making payment, please contact us.
♡ If you are worried about customhouse charge, please contact us.
♡ If you require Logo Print, SDK And API, Other OEM of the product, please contact us.
♡ If you require Some Other Accessories, please contact us.
♡ If you want to know More Product Details, please contact us.
♡ If you are worried about customhouse charge, please contact us.
♡ If you require Logo Print, SDK And API, Other OEM of the product, please contact us.
♡ If you require Some Other Accessories, please contact us.
♡ If you want to know More Product Details, please contact us.
