Product Description

Side Water Spray Retort's description

1. Uniform temperature distribution: in the process of heating and sterilization, the water is continuously sprayed from nozzles adopted high speed spraying, so that the temperature in the autoclave for retort pouch is kept stable and the sterilization effect is improved.
2. Direct heating and indirect cooling, and prevent the second pollution. Sterilizing and cooling processes use the same water.
Circulating water is directly heated by steam diffusion tube in the heating process. Under 0. 5MPa pressure, it only takes 6-12min to rise the temperature from 20 degrees to 121 degree. Continuous cooling by heating exchanger is isolated from
the products, preventing the second pollution in the cooling effectively.

This water spray retort with a little upper tank. It is specilist designed for glass jar food, which filling temperature is over 50 degrees.

In upper tank the sterilizing water preheats to over filling temperature. Then the hot water falls down to lower retort to continue heating to sterilizing temperature like 121 degree.

This water spray retort works without upper tank. It used for the glass jar product, which the filling temperature is room temperature.

But I have to notice you that the retort for glass jar should be with heat exchanger. We use plate type heat exchanger on our retorts. It has good effection to sterilize. If you want to know details, please write to me.

This type of sterilization machine can work with glass jar jam. Cause it has a heating exchanger. If you want to know more, please write to me.

This is PP bottles with coconut milk.

You can use this water spray sterilization machine, or you can use water immersion retort sterilizer.

Sterilization machine with water spray from side is specially used for retort pouch. It has best sterilization effect.

This sterilization machine with function of top and side water spray.

It has good heat penetration effect.

This is side water spray sterilization machine. It is specilizing in sterilization retort pouch.

This is cascading sterilization machine.

It is suitable for all kinds of packages except retort pouch.

Technical Parameters

Model	FMPL.1218.S.4	FMPL.1227.S.4	FMPL.1236.S.4
Diameter	1200mm	1200mm	1200mm
Length	1800mm	2700mm	3600mm
Volume	2.43m³	3.46m³	4.46m³
Total Power	5.5kw	5.5kw	7.5kw
Dimension	357016801800mm	426016801800mm	513016801800mm
Body Thickness	5mm	5mm	5mm
Max working pressure	0.35mpa	0.35mpa	0.35mpa
Max working temprature	147℃	147℃	147℃
Weight	1t	1.5t	2t
Control System	Fully automatic	Fully automatic	Fully automatic

Certifications

Detailed Images

Machine Spare Parts

Name: Chain for sterilization equipments spray

Brand: Fm

Original: China

This chain is for transportation baskets or trays of sterilization. Automatic go in and out. Easy operation and save manual working.

Automatic working system

Name: PLC for sterilization equipments spray
Brand: Siemense
Original: Germany
Siemense control system makes sterilization machine more professional. Easy operation.

Machine Parts

Name: Pressure gage for sterilization equipments spray
Brand: Afriso
Original: Germany
Afriso brand pressure gage for food sterilization machine measures the pressure more accurate.

Basket for sterilization equipments spray

Baskets for sterilization machine. The specification is depanding on client's products.

Basket for sterilization machine

This type of basket is working for water spray or steam retort sterilizer.

Clapboard for baskets

Clapboards for working baskets. The thickness has 6mm or 8mm. Or customed.

Trolleys for baskets

The trolleys for baskets are making according baskets. All parts made by Stainless steel 304.

Our Service

Pre-Sales Service

* Inquiry and consulting support.
* Sample testing support.
* View our Factory.

After-Sales Service

* Training how to instal the machine, training how to use the machine.
* Engineers available to service machinery overseas.

Packing & Delivery

Water spray retort's delivery

We will deliver your sterilization machine by LCL/20'FCL/40'FCL depending on your order.
Before delivery, our professional technician will do trial run for each machine to check until everything is functional, you also can come to our factory and test our machine together with us.
When loading, our workers will fix the retorts tightly with wire rope so that the retorts can't move in the container.

Our Company

Shandong Food Reliable Mach-Tech Co., Ltd is located in Zhucheng City, which is the hometown of dinosaurs. We are specialized in manufacturing Sausage Production Line, Vacuum Sweet Corns Production Line and Food Machines for food industry. With an experienced and professional team, we have exported our products to many countries and regions all over the world. Our products enjoy a good reputation among our customers. We welcome customers, business associations and friends from all parts of the world to contact us and seek cooperation for mutual benefits.

FAQ

1. How to heat up the water spray retort?
Equipped with high pressure steam boiler, to provide high pressure and temperature steam.
Via electric heating pipe, need stable electricity.

2.How to decide the size of water spray retort we need?
Please show us the packing details of your product and the production per day. We will show you suitable type.

3.What is the control type of the water spray retort?
You can choose from semi-automatic type or automatic type.
