Месяц | Минимальная цена | Макс. стоимость |
---|---|---|
Sep-15-2025 | 95.67 $* | 100.55 $* |
Aug-15-2025 | 94.30 $* | 99.57 $* |
Jul-15-2025 | 79.3 $* | 83.39 $* |
Jun-15-2025 | 93.32 $* | 98.5 $* |
May-15-2025 | 81.94 $* | 85.95 $* |
Apr-15-2025 | 91.54 $* | 96.20 $* |
Mar-15-2025 | 90.93 $* | 95.72 $* |
Feb-15-2025 | 90.43 $* | 95.11 $* |
Jan-15-2025 | 89.91 $* | 93.29 $* |
Item | Parameter | Remarks |
System Voltage | 12V | Nominal Voltage 11.1V |
Battery Capacity | 60Ah | Can be customized(10-100Ah) |
Battery Cell Model | 18650 NCM Battery |
|
Shell Material | Aluminum Alloy & iron end plate |
|
IP Grate | IP66 |
|
LED Terminal | 2×1.0mm²/150mm/female connector | 4 pins |
PV Terminal | 2×1.5mm²/150mm/male connector |
|
Size | 75mm(hight)*128mm(width)*350mm(Length) | Length can be customized according to Battery Capacity |
Lifespan | 5-8years. |
|
Warranty | 3 years |
|
Solar controller parameter |
|
|
Charging Mode | PWM | Can be customized if you need MPPT |
Charge Efficiency | >95% |
|
Max charge current | 10A |
|
Over charge protection | 12.6V | Programmable |
Over charge protection Recover | 12.4V | Programmable |
Over discharge protection | 9.0V | Programmable |
Over discharge protection recover | 10.0V | Programmable |
Working Mode | Light Control + Time Control |
|
Intelligent Energy Saving | Yes |
|
Status Indication | 3 LEDs indicating status of PV,battery and load |
|
Light control Voltage | 5.0V |
|
Max Output Power | 40W |
|
Suggestion on PV and LED |
|
|
PV Power | <180W |
|
PV Voltage | <18.0V |
|
LED Power | <40W |
|
LED Voltage | 15.0V-50.0V |
|
Wiring Method & Accessories |
|
|
Item | Specification | Remarks |
LED Cable | 2×0.75mm²/0.6m/male connector with 4 holes
| 1 pcs |
PV Cable | 2×1.5mm²/2.5m/female connector
| 1 pcs |
Remote Controller | IR | Optional |
Screw Nut | M5*30mm | 4 sets |
• OEM & ODM
• Professional solution customization
• Low MOQ: 1 pcs
• Quick response within 12 hours
• Video teaching for using products
• 2 stations of 100% test on production line
• Aging test
• Random inspection before delivery
