Маленькая Лабораторная шаровая мельница с большой производительностью для добычи
- Категория: Горнообогатительная установка >>>
- Поставщик: Ganzhou,Li,Ang,Machinery,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-15-2025 | 1785.67 $* | 1874.68 $* |
| Aug-15-2025 | 1770.87 $* | 1859.59 $* |
| Jul-15-2025 | 1485.6 $* | 1559.68 $* |
| Jun-15-2025 | 1740.51 $* | 1827.73 $* |
| May-15-2025 | 1515.11 $* | 1591.17 $* |
| Apr-15-2025 | 1710.53 $* | 1796.2 $* |
| Mar-15-2025 | 1695.36 $* | 1780.54 $* |
| Feb-15-2025 | 1680.58 $* | 1764.65 $* |
| Jan-15-2025 | 1665.66 $* | 1748.26 $* |
Характеристики
Large Capacity Lab Cylinder Ball Mill for Both Wet and Dry Fine Grinding of Ores
Small ball mill is totally enclosed intermittent grinding equipment which is capable of both dry grinding and wet grinding.The grinding feed sizes are 2-15M/M and the grinding amount for each time is 15-30kgs.
It is used to grind materials in half industrial laboratories and other small scale industries such as non-ferrous ores,iron and maganese ores,cement,refractories,slag,ceremics,building materials,coall,chemicals,agriculture,forestry,environmenta,fireproof materials,metallurgy and light chemical.
During the study of ores’ separability, this machine is not only used as a ball mill, but also meet requirement of getting the desired particle size of grinded materials according to beneficiation method, steel rods can be the grinding media to be used for rod mill.
Since this machine has large handling capacity,it is the best kind of transitional grinding equipment between continuous grinding and intermittent grinding. It’s a kind of suitable grinding equipment used during geological experiment work before heavy placer minerals are separated.
Features of Lab Cylinder Ball Mill
- Feeding size and output sizes can be made according to different needs.
-Big processing capacity each time, easy feeding and discharging,large feeding amount and discharging amount.
-High effect for both dry and wet milling.
-Milling time can be set as per your needs,continuous working;
-With compact mechanical structure, reliable transmission mechanism design, reasonable and simple design.
Easy ore discharging,cleaning and operation;improving working conditions,perfecting the quality of experimental work.
-Easy fabrication and maintenance.Avoiding splashing of mineral dust or slurry during ore discharging as well as dropping of steel balls everywhere.
-Big processing capacity each time, easy feeding and discharging,large feeding amount and discharging amount.
-High effect for both dry and wet milling.
-Milling time can be set as per your needs,continuous working;
-With compact mechanical structure, reliable transmission mechanism design, reasonable and simple design.
Easy ore discharging,cleaning and operation;improving working conditions,perfecting the quality of experimental work.
-Easy fabrication and maintenance.Avoiding splashing of mineral dust or slurry during ore discharging as well as dropping of steel balls everywhere.
Description of Lab Cylinder Ball Mill Principle:
This machine is a horizontal cylindrical rotating device, external belt drive, two warehouses, lattice type energy-saving ball mill. The material is uniformly fed into the mill first-storage by the feeding device through the hollow shaft of the feeding material. The chamber has a step liner or a corrugated liner, which is filled with steel balls of different specifications, and the cylinder rotates to generate centrif
ugal force to bring the steel ball to a certain height. After falling, it will hit and grind the material.
After the material reaches the rough grinding in the first bin, it enters the second bin through the single-layer partition plate.The bin is embedded with a flat liner with steel balls inside to further grind the material. The powder is discharged through the discharge raft to complete the grinding operation.
ugal force to bring the steel ball to a certain height. After falling, it will hit and grind the material.
After the material reaches the rough grinding in the first bin, it enters the second bin through the single-layer partition plate.The bin is embedded with a flat liner with steel balls inside to further grind the material. The powder is discharged through the discharge raft to complete the grinding operation.
Model | QM-400*600 | ||||||
Maximum Feeding Amount (kg/time) | 50 | ||||||
Capacity (kg/h) | Output size(mm) | Capacity | |||||
0.8 | 350 | ||||||
0.3 | 300 | ||||||
0.2 | 150 | ||||||
0.15 | 90 | ||||||
0.074 | 45 | ||||||
0.05 | 25 | ||||||
Power(kw) | 15 | ||||||
Overall Size(mm) | 1650*900*1050 | ||||||
Weight(kg) | 630 | ||||||
Our lab cylinder ball mill will be packed in wooden cases or iron frame,which makes sure of their safety during the international transportation.
\t\t\t\t\t\t\t\t\tOur company \t\t\t\t\t\t\t
Ganzhou Li Ang Machinery Co.,Ltd. is specialize in mining machine including shaking table, Jig, Spriral separator, Gold concentrator, Ball mill, Jaw crusher, flotation, magnetic separator,electrostatic separator, vibrating screen, gold pan, feeder, classifier, ore washing machine and lab equipment ect.
We also do research and manufacture various laboratory pretreatment equipment,such as lab crusher,lab ball mill&grinder,lab flotation machine,lab gravity separation equipment,lab sample pulverizer,lab crusher divider,lab hammer crusher divider,lab jaw crusher divider,lab magnetic separator,lab leaching agitator,lab rotary kiln,lab vacuum filter,lab drying machine,lab screening&classification machine,smelting furnace and other lab equipment.
Our machines are applied to separate GOLD, copper, manganes, chrome, tungsten, tin, nickel, iron, titanium, lead, zinc, tantalum and some non-ferrous metals like quart, zircon, barite,ect.
And our equipments are also mainly used in laboratory of university, government environmental protection agency, third-party test company and mine company.
Over the years we won a very good reputation from overseas customers.We believe it is our excellent product quality, reasonable prices and excellent service that make us won a lot of customers and also their recognition.
Believe us! We are your relieable parter and ideal choice!
Pre-Sales Service：
1.We can help you select equipment model and design resonable and complete production line flow according to clients’s requirements and budget.
2.Welcome to do the sample testing in our factory.A lot of clients sent or brought them to us to do the test.
3.OEM service is available.We can design and manufacturer products based on clients’ requests.
4.We can supply the technical parameters of the equipment.
After-Sales Service：
1.In order to make sure there is no quality problem,we shall pre-check and test the products before sending them out.We take pictures of finished products before delivery.
2.We shall track the logistic information until the products are well received.
3.We shall prepare the documents of custom clearance to help you receive your goods smoothly.
4.We can send professional engineers to help you install and debug the machine,train the operators and technical personnel and meet some other requirements if you need on site.
5.We can provide lifelong service of quick-wear part and technical exchanging for you.
6.We shall make prompt response to any problem about the machine within 24 hours if you have.And shall provide trouble-shooting solutions until the fault is completely eliminated.
7.To establish long-term friendship, we will regulary contact with our customers.
Q1: For providing you the suitable quotation we need to know the following information:
1.What is the raw material to handle ? Minerals eg: gold,coltan,diamond,tin, etc
2. What is the capacity per hour you required? 5tph,50tph,100 tph
3. What is the maximum input size of the raw material? 130mm,200mm,50mm
4. What is the output size and application for the final product?
Once we get your answers, I can provide you the best quotation immediately.
Q2: Do you provide ODM/OEM service?
A: OEM/ODM is welcome.A lot of clients placed an customized order from our factory.
Q3. What warranty do you give for your machine?
A:---We can supply spare parts .
---The quality assurance date we give is one year for the main parts after commissioning.
---We provide lifelong maintainence and technical support.
Q4.What is your Payment Terms?
A: We usually use the following payment terms.
Q5：What’s your means of transportation?
A:We have these means of transportation as below.
Q6. What is your delivery time?
A:Please find the answers as below.
Product | Lead time | |
shaking table | <=10days | |
laboratory mining equipment | <=10days | |
large mining equipment | 30-40 days. | |
customized machine | 30-40 days. | |
Tip: Exact delivery shall be confirmed when placing the order. | ||
Please do not hesitate to contact with us!
