F3015 4000W Laser Cutting Machine price with Three Years Warranty
Product Description
NO.1 Characteristics of our laser cutting machine
1.Iron Casting Machine Bed
1.Integrally formed, reject splicing
2.Auto focus laser head
Free your hands, enjoy auto focus
(1)Auto-focus
(2)Free
(3)Fast
(4)Accuracy
(5)Durable
3.Operating system display
Elegant appearance curve
4.Cast aluminum crossbeam
Integral steel mold pressure casting, light, flexible and efficient
5.Bodor Por 2.0
Independent R&Doperating system, perfectly combines highefficiency and simplicity withinclusiveness
The operating system can realize intelligent layout of graphics cutting and support the import of multiple graphics, optimizing cutting orders automatically, searching edges smartly and automatic positioning. Control system adopts the best logic programming and software interaction, provides stunning operation experience, effectively enhancing the utilization of sheet metal and reducing waste. Simple and fast operation system, efficient and accurate cutting instructions, effectively improve the user experience. NO.2 Machine Application Field Application Materials: Fiber Laser Cutting Equipment is suitable for metal cutting with Stainless Steel Sheet, Mild Steel Plate, Carbon Steel Sheet, Alloy Steel Plate, Spring Steel Sheet, Iron Plate, Galvanized Iron, Galvanized Sheet, Aluminum Plate, Copper Sheet, Brass Sheet, Bronze Plate, Gold Plate, Silver Plate, Titanium Plate, Metal Sheet, Metal Plate, Tubes and Pipes, etc.
NO.3 Samples
NO.4 Parameters of laser cutting machine
Model
F3015
F6015
Option
Max Cutting Range
3000*1524mm
6000*1500mm
According to
Demands
Machine Size(L*W*H)
2.4*4.7*1.9m
2.4*5.7*1.9m
Accessory Parts(L*W*H)
Chitler 1*1*1.2m Control Box 1*0.8*1.8m
Fiber Module 0.5*0.6*0.14m
Laser Medium
Single Core Junction Semiconductor Module
Max Cutting Speed
35m/min
Cooling Way
Water Cooling
Laser Power
4000W
Min Line Width
0.1mm
Cutting Depth
0.2-6mm
Driving and Transmission Way
Imported Servo Motor and Linear Guide Rail
Power Requirements
380V/50Hz/16A
Continuous Working Time
24Hours
Related Weight
Machine Body 2732kg Trolley 116kg
Computer Cabinet 56kg Servo Cabinet 75kg
Transformer 77kg Chiller 93kg Fiber Module 50kg
NO.1 Our Factory And Quality Control
Quality is our paramount mission that underpinning the lifeline of the company, and it is the most important factor to maintain long-term business relationships with customers. Special attention is paid to the quality of every unit of BODOR laser cutting machine. 1.Guarantee for 3 years. 2. Maintenance free of charge for 3 years . 3.We will provide the consumable parts at an agency price. 4.24 hours online service, free technical support. 5.Machine has been adjusted before delivery, operation disk is included in the delivery. If there is any other questions, pls kindly tell me. 6.We have manual instruction and CD (Guiding Videos) for software Installation, operation and machine's using and maintenance.
NO.3 Packaging & Shipping & Payment
The exports of fiber laser cutting machine are NO.1 in China
1)Packaging: Whole film packaging machine; anti-collision package edge; fumigation-free plywood wooden box and pallets with iron binding belt. 2)Shipping: We cooperate with SINOTRANS company whose experience in the ocean transportation will guarantee your machine safety. We also provide train transport, especially to Russia, Ukraine and other inland countries. 3)Payment: We support T/T, L/C, VISA, Mastercard payment terms with Alibaba Trade Assurance.
Q1: I knew nothing about this machine, what kind of machine i should choose?
Very easy to choose. Just tell us what you want to do by using CNC laser machine, then let us give you perfect solutions and suggestions. Q2: When I got this machine, but I don’t know how to use it. What should I do?
We will send video and English manual with the machine. If you still have some doubts, we can talk by telephone or skype and e-mail. Q3: If some problems happen to this machine during warranty period, what should I do?
We will supply free parts during machine warranty period if machine have some problems. While we also supply free life long after-sales service. So any doubts, just let us know, we will give you solutions.
