Trina Солнечная медовая черная 320 Вт 330 солнечная панель 3 кВт
- Категория: Солнечные панели >>>
- Поставщик: Rosen,Solar,Energy,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-18-2025 | 0.0 $* | 0.92 $* |
| Aug-18-2025 | 0.37 $* | 0.39 $* |
| Jul-18-2025 | 0.35 $* | 0.48 $* |
| Jun-18-2025 | 0.37 $* | 0.81 $* |
| May-18-2025 | 0.24 $* | 0.57 $* |
| Apr-18-2025 | 0.24 $* | 0.70 $* |
| Mar-18-2025 | 0.13 $* | 0.56 $* |
| Feb-18-2025 | 0.67 $* | 0.31 $* |
| Jan-18-2025 | 0.31 $* | 0.48 $* |
Характеристики
Product Description
Technical Specification
Model | RS300M-60 | RS310M-60 | RS320M-60 | RS325M-60 | RS330M-60 | ||||
Rated Maximum Power at STC | 300W | 310W | 320W | 325W | 330W | ||||
Open Circuit Voltage(Voc) | 39.84 | 40.30 | 40.78 | 41.04 | 41.30 | ||||
Maximum Power Voltage(Vmp) | 32.02 | 32.60 | 33.17 | 33.44 | 33.75 | ||||
Short Circuit Current(Isc) | 9.90 | 10.04 | 10.18 | 10.25 | 10.32 | ||||
Maximum Power Current(Imp) | 9.37 | 9.51 | 9.65 | 9.72 | 9.78 | ||||
Module Efficiency(%) | 18.3 | 18.8 | 19.4 | 19.7 | 20.0 | ||||
Standard Test Condition(STC) | Irradiance 1000w/m2, Cell Temperature 25°C, Air Mass 1.5 | ||||||||
ELECTRICAL DATA(NMOT) | ||||||||||
Maximum Power-PMAX (Wp) | 221 | 229 | 237 | 241 | 244 | |||||
Maximum Power Voltage(VMPP) | 30.03 | 30.67 | 31.32 | 31.64 | 31.96 | |||||
Maximum Power Current(Imp) | 7.39 | 7.48 | 7.57 | 7.62 | 7.64 | |||||
Open Circuit Voltage-VOC (V) | 37.35 | 37.95 | 38.56 | 38.85 | 39.16 | |||||
Short Circuit Current-ISC (A) | 7.85 | 7.93 | 8.01 | 8.05 | 8.09 | |||||
NOCT:Irradiance 800W/m2,Ambient Temperature 20°C,Wind Speed 1m/s. | ||||||||||
Detailed Images
EVA
High Transmittance EVA,High GEL Content To Provide Good Encapsulation And Protect Cells From Vibration With Longer Durability.
Solar Cell
5BB, 6BB, 9BB Available
156mm, 158.75mm, 166mm, 182mm, 210mm High Efficiency Cells
Anti-Pid
Frame
35mm 40mm Anodized Aluminium Alloy
Black/Silver Color Optional
Junction--Box
IP 68 rated Waterproof
Innovative Full-Glue-Filled
Portrait/Landscape Length Optional
Innovative Full-Glue-Filled
Portrait/Landscape Length Optional
Compatible MC4
MC4 Compatible /MC4 EVO2/TS4*
500N Tensile Strength
Female/Male/Fuse
Label
Waterproof Customized Label
OEM/ODM with your Logo
Professional Silver Color
Packing & Delivery
Packing Details : In carton on pallet or wooden box, OEM with your logo available
Delivery Details : 5-10 working days
Delivery Details : 5-10 working days
