2020 10 кг новый беспилотный сельскохозяйственный опрыскиватель 10л защита растений летательный аппарат с
- Категория: Aircraft >>>
- Поставщик: Shandong,Joyance,Intelligence,Technology,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Aug-20-2025 | 4444.6 $* | 4533.52 $* |
| Jul-20-2025 | 3604.63 $* | 3676.62 $* |
| Jun-20-2025 | 4374.21 $* | 4461.72 $* |
| May-20-2025 | 4339.49 $* | 4426.76 $* |
| Apr-20-2025 | 3464.29 $* | 3533.10 $* |
| Mar-20-2025 | 4269.72 $* | 4354.79 $* |
| Feb-20-2025 | 4234.71 $* | 4319.24 $* |
| Jan-20-2025 | 4199.44 $* | 4283.64 $* |
Характеристики
Sprayer drone Description
Tank size: 10L/ 10kgs
Spray width: 4 - 6 meters
Spray width: 4 - 6 meters
Coverage: 5-6 hectares/hour (1ha=2.5acres)
Highlights: Economical and cost-effective
Agriculture drone for spraying pesticides.
Application:
sowing seeds → solid fertilizer scattering → herbicide/insecticide/bactericide/pesticide spraying → foliar fertilizer spraying
Agriculture drone for spraying pesticides.
Application:
sowing seeds → solid fertilizer scattering → herbicide/insecticide/bactericide/pesticide spraying → foliar fertilizer spraying
Technical parameter | JT10L-606 | JT15L-606 | JT15L-608 Pro | JT20L-606 |
Pesticide load | 10 liters | 15 Liters | 15 liters | 20 liters |
Self weight | 10.5 kg | 13.5 kg | 20 kg | 18.5 kg |
Take-off weight | 23 kg | 31 kg | 39 kg | 44 kg |
Fly time | 10~15 min | 10~15 min | 10~15 min | 10~15 min |
Spraying efficiency | 5~6 hectares/hour | 7~8 hectares/hour | 8~10 Hectares/hour | 9~11 hectares/hour |
Spray width | 4~6 m | 6~7 m | 8~10 m | 7~8 m |
Spray speed | 0~8 m/s | 0~8 m/s | 0~10 m/s | 0~10 m/s |
Nozzle | 2 centrifugal nozzles | 2 centrifugal nozzles | 4 centrifugal nozzles | 4 centrifugal nozzles |
Battery | 2 pcs 6S 17000 mAh | 2 pcs 6S 17000 mAh | 2 pcs * 6S 23000 mAh | 2 pcs * 6S 23000 mAh |
Flying radius | 1000 m | 1000 m | 1000 m | 1000 m |
Spray flow | 1~1.5 L/min | 2~2.5 L/min | 2.5~3 L/min | 2.5~ 3 L/min |
Flying height | 0~30 m | 0~30 m | 0~30 m | 0~30 m |
Work temperature | –10~70 ℃ | –10~70 ℃ | –10~70 ℃ | –10~70 ℃ |
Wind resistance | 10 m/s | 10 m/s | 10 m/s | 10 m/s |
Spread size (m) | 1.3 * 1.3 * 0.45 m | 1.8 *1.8 * 0.48 m | 2.7 *1.55 * 0.5 m | 1.95 *1.95 * 0.57 m |
Folded size (m) | 0.6 * 0.6 * 0.51 m | 0.7 * 0.7 * 0.63 m | 0.85 * 0.75 *0.7 m | 0.7 * 0.7 *0.8 m |
Aluminum box size/weight | 73*67*65 cm / 50 kgs | 75*75*81 cm/70kgs | 81*81*86 cm/80 kgs | 75*85*95 cm/80 kgs |
Basic Function of our agriculture sprayer drones:
Remote controlled and fully automatically operation in APP
1. A key to take off and landing.(easy to operate)
2. Autonomous flying with APP.
3. Avoid re-spraying seedlings or missing spray with record and do break-point continue-spraying
4. Intelligent flow adjust control
5. APP maps, plans operating route and route will be saved automatically for next operation
6. Fail-safe self protection
7. Cloud service and team management
8.Dosage Monitor
9.Low Voltage & Volume Warning, drone back to site automatically
10.FPV camera with light transferring real image in front of drone (optional)
11.Terrain following radar(optional)
12.Obstacle avoidance radar(optional)
13.Granule spreader to scatter seeds fertilizer(optional)
1. A key to take off and landing.(easy to operate)
2. Autonomous flying with APP.
3. Avoid re-spraying seedlings or missing spray with record and do break-point continue-spraying
4. Intelligent flow adjust control
5. APP maps, plans operating route and route will be saved automatically for next operation
6. Fail-safe self protection
7. Cloud service and team management
8.Dosage Monitor
9.Low Voltage & Volume Warning, drone back to site automatically
10.FPV camera with light transferring real image in front of drone (optional)
11.Terrain following radar(optional)
12.Obstacle avoidance radar(optional)
13.Granule spreader to scatter seeds fertilizer(optional)
Sprayer drone Details Images
① Motor
it's waterproof
working hours ≥2,000 hours with long service life
② Centrifugal nozzles
Spray degree: 170 °
Droplet size: 50-200 microns tiny size
Equipment: brushless ESC and motor inside
Equipment: brushless ESC and motor inside
③ Aluminum folding jouint
Foldable, fasten and strong to bear heavy work
④ Propellers
Foldable carbon fiber propellers
⑤ Water pump
Pumping water
⑥ Li-po batteries
6S 17,000/23,000mAh Li-po batteries
≥300 cycles service life
⑦ Central plate
Made of thicker carbon fiber.
Light, strong and waterproof
⑧ Remote controller
Simple pratical RC design to be easier operating
dustproof and waterproof
⑨ Agri assistant App
It can be installed on the phone or tablet to do automous flight.
Company Profile
Joyance Tech
Advantages
● Agricultural Drones Manufacturer
● 9 years of R&D experience
● 200 units per month output
● Shortest delivery time, sufficient spare parts in stock
● Users in 59 countries & regions
● 9 years of R&D experience
● 200 units per month output
● Shortest delivery time, sufficient spare parts in stock
● Users in 59 countries & regions
● Get whole sale price order ≥3units in one time
● 24/7 lifetime after-sale service
● CE, FCC, RoHS, ISO 9001 certification
● Top quality & Competitive price & Your reliable partner
Producing process
① Producing
②Preparing material
③ Welding
④ Assemblying
⑤ Adjust parameters
⑥ Half-products
⑦ Testing
⑧ Prepare to ship
Service
● Warranty: 1 year for the drone and 3 months for spare parts, sufficient parts in stock
● Ready to fly and Quality control:
● Ready to fly and Quality control:
Before dispatch, every drone is 100% tested and has to pass through a rigorous quality control test to
confirm it meets the highest standards in performance and durability.
● Lifelong after-sales service, timely video support is available.
● Free training in our factory, including operation and maintenance, takes 2-3 days.
● Offer operation manual & video in English and online technical support.
● Lifelong after-sales service, timely video support is available.
● Free training in our factory, including operation and maintenance, takes 2-3 days.
● Offer operation manual & video in English and online technical support.
FAQ
Q. What is MOQ?
A: MOQ ≥1. And 1 pc sample drone sprayer for testing is available.
Q.Are you factory?
A: MOQ ≥1. And 1 pc sample drone sprayer for testing is available.
Q.Are you factory?
A: Yes, we are a professional R&D and production of agricultural drones factory. There are 10L, 15L, 16L, and 20L sprayer drones, seed / fertilizer spreading drones and thermal fogger drones.
Q.Is it ready to fly?
A:Yes. all of our agricultural drones are ready to fly. Before dispatch, JOYANCE assembled all the parts and set all the parameters.Every sprayer drone is 100% tested and confirm it meets the highest standards in performance and durability
A:Yes. all of our agricultural drones are ready to fly. Before dispatch, JOYANCE assembled all the parts and set all the parameters.Every sprayer drone is 100% tested and confirm it meets the highest standards in performance and durability
Q: How long is your delivery time?
A:Generally it is 2-3 days we have the agri drones in stock. or it is 7-15 days if the agri drones are not in stock, it is according to quantity.
2020 10 kgs new drone agriculture sprayer 10l drone agriculture sprayer plant protection uav drone with camera
Q: What is your terms of payment ?
A: 50% T/T deposit for sprayer drone production, balance paid before shipment.
