Высокое качество non-изолированные
- Категория: Terminals >>>
- Поставщик: Zhejiang,Kise,Terminal,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-19-2025 | 0.43 $* | 0.79 $* |
| Aug-19-2025 | 0.68 $* | 0.93 $* |
| Jul-19-2025 | 0.77 $* | 0.49 $* |
| Jun-19-2025 | 0.60 $* | 0.42 $* |
| May-19-2025 | 0.26 $* | 0.3 $* |
| Apr-19-2025 | 0.3 $* | 0.3 $* |
| Mar-19-2025 | 0.67 $* | 0.7 $* |
| Feb-19-2025 | 0.6 $* | 0.55 $* |
| Jan-19-2025 | 0.45 $* | 0.60 $* |
Характеристики
Wire Range | SKU# | Description | Stud Size | Dimensions Inch (mm) | |||||||
USA | d2 | B | F | L | E | D | d | T | |||
A.W.G. 22-20 | KFO0000 | 22-20 AWG Non-insulated Spade Terminal 0.5-3 | #4 | 0.087 | 0.205 | 0.256 | 0.488 | 0.197 | 0.043 | 0.079 | 0.03 |
A.W.G. 22-20 | KFO0001 | 22-20 AWG Non-insulated Spade Terminal 0.5-3.5 | #6 | 0.146 | 0.26 | 0.256 | 0.551 | 0.197 | 0.043 | 0.079 | 0.03 |
A.W.G. 22-20 | KFO0002 | 22-20 AWGNon-insulated Ring Terminal 0.5-4 | #8 | 0.169 | 0.26 | 0.256 | 0.551 | 0.197 | 0.043 | 0.079 | 0.03 |
A.W.G. 22-16 | KFO0010 | 22-16 AWG Non-insulated Spade Terminal 1.25-3 | #4 | 0.126 | 0.217 | 0.256 | 0.63 | 0.197 | 0.138 | 0.079 | 0.03 |
A.W.G. 22-16 | KFO0011 | 22-16 AWG Non-insulated Spade Terminal 1.25-3.5S | #6 | 0.146 | 0.217 | 0.256 | 0.63 | 0.197 | 0.138 | 0.079 | 0.03 |
A.W.G. 22-16 | KFO0012 | 22-16 AWG Non-insulated Spade Terminal 1.25-3.5L | #6 | 0.146 | 0.256 | 0.256 | 0.63 | 0.197 | 0.138 | 0.079 | 0.03 |
A.W.G. 22-16 | KFO0013 | 22-16 AWG Non-insulated Spade Terminal 1.25-4S | #8 | 0.169 | 0.256 | 0.256 | 0.63 | 0.197 | 0.138 | 0.079 | 0.03 |
A.W.G. 22-16 | KFO0014 | 22-16 AWG Non-insulated Spade Terminal 1.25-4M | #8 | 0.169 | 0.276 | 0.256 | 0.63 | 0.197 | 0.138 | 0.079 | 0.03 |
A.W.G. 22-16 | KFO0015 | 22-16 AWG Non-insulated Spade Terminal 1.25-4L | #8 | 0.169 | 0.315 | 0.256 | 0.63 | 0.197 | 0.138 | 0.079 | 0.03 |
Company Information
ABOUT US |
Founded in 1994, Zhejiang KISE Terminal Co., Ltd. has positioned itself as a first class manufacturer of terminals since its establishment, and possesses two trademarks – KIS and KF. KISE has been sticking to the development strategy of “being specific, precise, and advanced” for more than 20 years. Relying on the solid foundation in professional knowledge and innovative spirit, the technical team of the company adheres to the innovation pattern of “independent research & development, joint development, and technology introduction” and has established an excellent R&D system. The company has powerful capabilities in mould development and has gradually gained a technical advantage in the field of terminals. The company established an independent UL laboratory in 2015, which enables KISE to obtain timely and effective data, and in turn, delivering satisfactory results in regards to both the technical verification in product development and the regular quality inspection of manufactured products. |
