Портативный высокоточный инфракрасный количественный детектор утечки газа COP58SF6/измерительное оборудование/детектор сжиженного углеводородного
- Категория: Газоанализаторы >>>
- Поставщик: Angelmart,Trading,Development,Company,Limited
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-16-2025 | 3508.27 $* | 3683.19 $* |
| Aug-16-2025 | 3479.59 $* | 3653.78 $* |
| Jul-16-2025 | 2919.35 $* | 3065.58 $* |
| Jun-16-2025 | 3420.33 $* | 3591.63 $* |
| May-16-2025 | 2977.16 $* | 3126.43 $* |
| Apr-16-2025 | 3361.40 $* | 3529.71 $* |
| Mar-16-2025 | 3331.98 $* | 3498.81 $* |
| Feb-16-2025 | 3302.5 $* | 3467.70 $* |
| Jan-16-2025 | 3272.22 $* | 3436.24 $* |
Характеристики
Product Description
Specification
Technical parameters:
* The minimum detection value: 1ppm、 01ppm
* Detection range: 0-1,000ppm、0~50ppm
* Response time: <3s
* Recovery time: <5s
* Quoted error: ≤±2％[0~1000] ppm ≤±10％[1000~5000] ppm(High range type)
≤±2％[0~50] ppm ≤±10％[50~300] ppm(High precision type)
* Repetitive error: ≤2％
* Display mode: 3.5-inch color touch screen
* Detection length of detection gun: bar-type 130mm
* Continuous working time: ≥8hour
* Power supply of instrument: four-core lithium battery
* Charging voltage: 8.4V, photoelectric time: 5 hours (continuous charging time does not exceed 12 hours)
* Operating environment: temperature: -10℃-50℃
Relative humidity: ≤95%
* Total weight: 0.3kg
* Volume: length*width*height=230mm*120mm*60mm
Outer box: length*width*height=450 mm*230 mm*130mm
* Detection range: 0-1,000ppm、0~50ppm
* Response time: <3s
* Recovery time: <5s
* Quoted error: ≤±2％[0~1000] ppm ≤±10％[1000~5000] ppm(High range type)
≤±2％[0~50] ppm ≤±10％[50~300] ppm(High precision type)
* Repetitive error: ≤2％
* Display mode: 3.5-inch color touch screen
* Detection length of detection gun: bar-type 130mm
* Continuous working time: ≥8hour
* Power supply of instrument: four-core lithium battery
* Charging voltage: 8.4V, photoelectric time: 5 hours (continuous charging time does not exceed 12 hours)
* Operating environment: temperature: -10℃-50℃
Relative humidity: ≤95%
* Total weight: 0.3kg
* Volume: length*width*height=230mm*120mm*60mm
Outer box: length*width*height=450 mm*230 mm*130mm
Calibrating period and safety measures of the equipment
1) Operating functions of the equipment shall be checked every two years.
2) To guarantee the safety of operators and the safety of equipment, articles in notice must be followed up.
3) The equipment is a special tool applicable to detect SF6 gas, prohibited to detecting other gases, and prohibited to illegally use.
4) The equipment cannot be applicable to working areas where mixed explosive gas is unconfirmed.
Requirements for operators using the equipment:
1) The operating manual must be kept by operators with the equipment at any time.
2) Operators must be familiar with the technical description and operating instructions specified in the manual.
3) Operators must be familiar with safety measures, safety operations, cleaning and maintenance of the equipment.
4) The equipment must be operated by engineers or technical personnel with certain professional knowledge.
5) Operators must read this manual and understand the safety importance of SF6 gas measurement.
6) Personnel managing the equipment must careful, reliable and responsible, and shall have certain profession knowledge.
7) Person whose thinking is disturbed after drinking or who is not professionally trained is prohibited from operating the
equipment.
8) Person is responsible for damages caused by changing without permission or folding the equipment or breaking the operating rules.
1) Operating functions of the equipment shall be checked every two years.
2) To guarantee the safety of operators and the safety of equipment, articles in notice must be followed up.
3) The equipment is a special tool applicable to detect SF6 gas, prohibited to detecting other gases, and prohibited to illegally use.
4) The equipment cannot be applicable to working areas where mixed explosive gas is unconfirmed.
Requirements for operators using the equipment:
1) The operating manual must be kept by operators with the equipment at any time.
2) Operators must be familiar with the technical description and operating instructions specified in the manual.
3) Operators must be familiar with safety measures, safety operations, cleaning and maintenance of the equipment.
4) The equipment must be operated by engineers or technical personnel with certain professional knowledge.
5) Operators must read this manual and understand the safety importance of SF6 gas measurement.
6) Personnel managing the equipment must careful, reliable and responsible, and shall have certain profession knowledge.
7) Person whose thinking is disturbed after drinking or who is not professionally trained is prohibited from operating the
equipment.
8) Person is responsible for damages caused by changing without permission or folding the equipment or breaking the operating rules.
