Станок для черчения медной проволоки 2
- Категория: Wire Drawing Machines >>>
- Поставщик: Jiangsu,Jiacheng,Technology,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-16-2025 | 12.10 $* | 13.62 $* |
| Aug-16-2025 | 12.2 $* | 13.84 $* |
| Jul-16-2025 | 10.82 $* | 11.32 $* |
| Jun-16-2025 | 12.96 $* | 13.7 $* |
| May-16-2025 | 10.94 $* | 11.72 $* |
| Apr-16-2025 | 11.23 $* | 12.77 $* |
| Mar-16-2025 | 11.69 $* | 12.87 $* |
| Feb-16-2025 | 11.42 $* | 12.38 $* |
| Jan-16-2025 | 11.11 $* | 12.34 $* |
Характеристики
copper wire drawing machine 2 wires
Why Choose Us?
- Do a Little More(take High Speed Rod Breakdown Machine for example)
1. Body frame: enblock casting
Material: HT200 grey cast iron
Advantages:
a. good stability
b. not deform
c. low noise
2. Drawing wheel type: drum type
Advantages(compare with drawing capstan type):
a. drum ring widening design(width: 65mm)
b. both two face can drawing: when one face wearing, can change another face continue to use(one drum can drawing above 10,000 tons in normal)
c. just only change the drum ring instead of whole drum while two face wearing, easy to operate and with lower cost
d. bigger bending radius(φ450mm), easy to threading and winding
e. equipped with high-power motor and inverter, suitable for long continuous production
f. tungsten carbide coated: with high hardness, wearable and low noise
3. Transmission type: high precision grinding bevel gear
Material: 20CrMnTi, processed by carburizing and quenching
Processing equipment: processed by gear grinding machine imported from Germany
Advantages:
a. high precision
b. wearable
c. low noise
4. Add final rotating die system
Final outlet die play an important role in the final quality of the wire. final drawing die holder with rotating design, and outlet die driven by an independent motor, when the machine working properly, it will run in 31r/min constant rotation speed, to ensure uniform wearing of the mould, thus ensuring the final quality of the finished wire
5. Add quick die change system
Final drum driven by an independent motor, and the outlet diameter can be changed easily without stringing up the machine again(motor can directly match the speed ratio by changing the drawing die only)
Advantages:
a. easy to operate, save time and with high efficiency
b. can speed up
c. reduce power loss(energy-saving)
6. Take-up type: auto double bobbin take-up(Pneumatic type)
Advantages(compare with hydraulic pressure type):
a. easy to operate: both clamp and gore out device adopt button instead of hand operation, easy to operate, and better protection of bearings
b. auto bobbin changed
c. auto bobbin changed without stopping the machine, can be non-stop continuous production
- Think a Little More(take High Speed Rod Breakdown Machine for example)
1. Matching machines:
a. wire pointing and threading machine
b. hot/cold welding machine
c. air compressor
d. steam generater(if with annealing machine)
2. Matching parts:
a. wire bobbin
b.drawing mould/die
c.drawing oil
3. Matching documents:
a. investigation report
b. industry comparison table
c. output & consumption table
d. moulds/dies arrangement table
e. user's video
f. plant layout
g. foundation drawing
h. electric principle diagram
i. operating manual
j. inverter specification
Finished Products
Certifications
Wonderful Time
Packing & Delivery
Our Services
- Good Quality Control Concerning with every detail, every processing procedure of our products, using reliable components. Running test will be carried out before delivery.
- Technical Support Related drawings can be provided; Technician will be assigned to user's plant for installtion and commissioning as per demand.
- Warranty Period Mechanical parts 12 months, electrical parts 6 months.
Related Products
FAQ
- 01 Are you a trading company or a manufacturer?
- We are a manufacturer, we supply the factory price with good quality, welcome to visit!
- 02 When can i get my machine after i paid?
- The delivery time is based on the exact machine you confirmed.
- 03 How about the spare parts?
- After we finish our deal, we will offer you a spare parts list for your reference.
- 04 Where are you?
- Zhangjiagang city, Jiangsu Province - 2.5 hours from Shanghai Pudong international airport.
- 05 Series products?
- Wire Drawing Machine Series:
- copper / brass / aluminum / aluminum alloy rod breakdown machine
- copper / brass / aluminum / aluminum alloy intermediate wire drawing machine
- copper / brass / aluminum / aluminum alloy / stainless steel / iron fine wire drawing machine
- copper super fine wire drawing machine
- Annealing Machine Series:
- online annealing machine
- 40 heads offline annealing machine
- Coating Machine Series:
- copper wire tin hot-dip coating machine
- copper electroplating machine(for CCAW / CCSW / Cu-Cu production line)
- Stranding Machine Series:
- double twist bunching machine
- automatic high speed twist bunching machine
- cantilever single twist machine
- tubular stranding machine
- rigid frame stranding machine
- Wrapping Machine Series:
- double layer wrapping machine
- triple layer wrapping machine
- multi layer wrapping machine
- Plastic Cable Extruder Series:
- PVC / PP / PE / NYLON / TEFLON / SILICON / RUBBER / PHYSICAL FOAMING cable plastic insolated extruder
- PVC / PP / PE / NYLON / TEFLON / SILICON / RUBBER / PHYSICAL FOAMING cable plastic sheathed extruder
- Wire Coiling and Packing Machine Series:
- wire coiling machine
- automatic wire coiling and packing machine
