SS Mini Size Dual Wheel AGV Caster Wheels Shock Absorbing Structure
Product Description
SS Mini Size Dual Wheel AGV Caster Wheels Shock Absorbing Structure
What are the most important factors for an AGV wheel?
1) If you have an experience that used a poor quality AGV wheel before, maybe you know that when the wheel runs by a fast speed the wheel tread temperature will be very high and sometimes in an extreme case that the wheel tread broken down from the wheel core.
STARDRAWING AGV wheels adopt patented formulated wheel material and unique wheel bonding technology to prevent such unhappy case.
STARDRAWING started from forklift polyurethane wheel manufacturing for several well-known forklift brands around the world since 1999, we have the "know-how" and good at the integrated total solution for the one station manufacturing.
2) The space for a wheel is normally limited under the chassis of the AGV.
We always keep this in our mind. Generally you can find that our wheel with a small swivel radius. This is the point.
3) A sensitive swivel head features an efficient rotating function when in a sharp direction turning. The force from left and right sides sometimes is bigger than from front and back. A long life service AGV wheel must with a tough and durable swivel head. The structure mechanism inside the raceway is one of the core technologies for a caster wheel manufacturer.
4) High quality is everything for us. We never use a "RECYCLED" bearing in our wheel.
Main Features
1)Carbon and Forged Steel bracket fork
2)Kingpin strongly welded and bolted wheel axle
3)Powder coating bracket surface treatment
4)Stardrawing unique formulated high quality polyurethane tread, firmly bonded, very clean tread form by surface treatment.
5)Precision double ball bearings in the wheel center
6) 4KM/H speed suitable for most AGV application environments
7) -20 to 70℃ temperature range
8)Engineered aluminum wheel core designed for competitive light self-weight
9) Small swivel radius
10)PU wheel tread hardness is 95 Shore A
11)Spring and solid PU loaded shock absorbing design
12)Have 55/65/75/100 mm wheel diameter as mini size options
13)Have plate swivel and M12x25mm threaded stem swivel mounting type as options
Wheel dia (mm) | Load (kg) | Tread width (mm) | Max height (mm) | Minimum height (mm) | Swivel radius (mm) | Plate size (mm) | Bolt hole pattern (mm) | |
55 | 150 | 23x2 | 96 | 82 | 56 | 110x85 | 85x60 | |
65 | 180 | 23x2 | 106 | 92 | 56 | 110x85 | 85x60 | |
75 | 200 | 23x2 | 116 | 102 | 59.5 | 110x85 | 85x60 | |
100 | 350 | 55 | 148 | 136 | 79.5 | 114x100 | 84x71 | |
Wheel dia (mm) | Load (kg) | Tread width (mm) | Max height (mm) | Minimum height (mm) | Swivel radius (mm) | Treaded stem size (mm) | ||
55 | 150 | 23x2 | 96 | 82 | 56 | M12x25 | ||
65 | 180 | 23x2 | 106 | 92 | 56 | |||
75 | 200 | 23x2 | 116 | 102 | 59.5 | |||
Applications
SS Mini Size Dual Wheel AGV Caster Wheels Shock Absorbing Structure is Ideal for Automated Guided Vehicles, Laser LGV Guided Vehicles, RGV Rail Guided Vehicle and some logistic equipments. Some 24 hour operation equipments.
