Смазка регулятора фильтра серии AC F
- Категория: Пневматические детали >>>
- Поставщик: BLCH,Pneumatic,Science,&,Technology,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-17-2025 | 0.67 $* | 0.78 $* |
| Aug-17-2025 | 0.50 $* | 0.15 $* |
| Jul-17-2025 | 0.11 $* | 0.46 $* |
| Jun-17-2025 | 0.25 $* | 0.26 $* |
| May-17-2025 | 0.21 $* | 0.52 $* |
| Apr-17-2025 | 0.51 $* | 0.20 $* |
| Mar-17-2025 | 0.12 $* | 0.5 $* |
| Feb-17-2025 | 0.91 $* | 0.5 $* |
| Jan-17-2025 | 0.30 $* | 0.5 $* |
Характеристики
Product Description
| Model | AC1010-M5 | AC2010-01 | AC2010-02 | AC3010-02 | AC3010-03 | AC4010-03 | AC4010-04 | AC4010-06 | AC5010-06 | AC5010-10 | |
| AC1010-M5D | AC2010-01D | AC2010-02D | AC3010-02D | AC3010-03D | AC4010-03D | AC4010-04D | AC4010-06D | AC5010-06D | AC5010-10D | ||
| Components | Filter-Regulator | AW1000 | AW2000 | AW2000 | AW3000 | AW3000 | AW4000 | AW4000 | AW4000 | AW5000 | AW5000 |
| Lubricator | AL1000 | AL2000 | AL2000 | AL3000 | AL3000 | AL4000 | AL4000 | AL4000 | AL5000 | AL5000 | |
| Port size Rc(G) | M5 x 0.8 | 1/8″ | 1/4″ | 1/4″ | 3/8″ | 3/8″ | 1/2″ | 3/4″ | 3/4″ | 1″ | |
| Pressure gauge port size | M5 x 0.8 | 1/8″ | 1/8″ | 1/8″ | 1/8″ | 1/4″ | 1/4″ | 1/4″ | 1/4″ | 1/4″ | |
| Pressure gauge | Y20 | Y40 | Y40 | Y40 | Y40 | Y50 | Y50 | Y50 | Y50 | Y50 | |
| Max. Flow L/min(ANR) | 90 | 500 | 500 | 1700 | 1700 | 3000 | 3000 | 3000 | 5000 | 5000 | |
| Working pressure Range | 0.15-0.7 Mpa | 0.15-0.85 Mpa | |||||||||
| Max pressure (Mpa) | 1.0 MPa | ||||||||||
| Ambient temperature | - 5~60℃ | ||||||||||
| Filter accuracy | 40um ( standard) 5um (optional) | ||||||||||
| Recommended oil: | Turbine NO.1 oil (ISOVG32) | ||||||||||
| Material of main part | Body | Aluminum alloy | |||||||||
| Bowl | PC | ||||||||||
| Bowl guard | AC1010~ AC2010 : without , AC3010~ AC5010: With (Iron) | ||||||||||
MAIN PRODUCTS
Company Information
FAQ
Q: Are you trading company or manufacturer?
A: We are manufacturer, factory.
Q: What's your main products?
A: BLCH's main products are air treatment unit, pneumatic fittings, solenoid valve, mechanical valve, pneumatic cylinders, PU tubes and other pneumatic parts.
Q: How long is your delivery time?
A: Generally it is 7-10 working days if the goods have stocks. Or it is 10-15 working days if the goods don't have stocks, it is according to quantity and request.
Q: Do you provide samples? Is it free or extra?
A: Our samples are free, we will reduce this cost in your first order.
Q: What is your terms of payment?
A: Alipay, TT, western union
Q: Could you OEM?
A: Yes, we can make OEM for customers.
Packaging & Shipping
