two roll mill rubber



Specification

1'The roller is made of Chilled Cast Iron(hardness:68-72HSD):Smooth Surface,Highly Polished,Scratch proof by cutting knife etc.

2'The roller is supported by Copper bush with oil LUB so it has low noise and a long service life.

3'Machine will be tripped off if overloaded to protect valuable electrical circuit.

4'It has appropriate arrangement for cooling and heating,circulation of steam and cooling water can be through the rollers to control the temperature.

5'All electrical connections are safe:short circuit is not possible by any means.



 Version and its Technique Parameters:





Technique Parameters	XK-160	XK-250
Roll diameter(mm)	160	250
Roll length(mm)	320	620
Front roll surface speed(m/min)	8.95	15.3
Friction ratio	1:1.35	1:1.1
Max.nip	4.5	8
Feeding capacity per	1-2	10-15
Power	5.5	18.5
Size(lenght*width*height)(mm)	1226*830*1295	3200*1300*1600
Weight(Kg)	1280	2700
