RFM69HW 120dBm 433/868/915Mhz RF Transceiver Module RFM69HW-433S2 RFM69HW-868S2 RFM69HW-915S2

Please be ware of that there are some copies / fakes with low quality in market, neither have CE / ROHS / FCC ... certificates approved.



The RFM69HW is a low cost low power long range highly integrated wireless RF Sub-ghz transceiver module capable of operation over a wide frequency range, including the 433, 868 and 915 MHz license-free ISM (Industry Scientific and Medical) frequency bands. Its highly integrated architecture allows for a minimum of external components whilst maintaining maximum design flexibility.

KEY PRODUCT FEATURES

‹ +20 dBm - 100 mW Power Output Capability ‹ High Sensitivity: down to -120 dBm at 1.2 kbps ‹ High Selectivity: 16-tap FIR Channel Filter ‹ Bullet-proof front end: IIP3 = -18 dBm, IIP2 = +35 dBm,80 dB Blocking Immunity, no Image Frequency response ‹ Low current: Rx = 16 mA, 100nA register retention ‹ Programmable Pout: -18 to +20 dBm in 1dB steps ‹ Constant RF performance over voltage range of module ‹ FSK Bit rates up to 300 kb/s ‹ Fully integrated synthesizer with a resolution of 61 Hz ‹ FSK, GFSK, MSK, GMSK and OOK modulations ‹ Built-in Bit Synchronizer performing Clock Recovery ‹ Incoming Sync Word Recognition ‹ 115 dB+ Dynamic Range RSSI ‹ Automatic RF Sense with ultra-fast AFC ‹ Packet engine with CRC-16, AES-128, 66-byte FIFO Built-in temperature sensor

APPLICATIONS

‹ Automated Meter Reading ‹ Wireless Sensor Networks ‹ Home and Building Automation ‹ Wireless Alarm and Security Systems ‹ Industrial Monitoring and Control ‹ Wireless M-BUS ‹ Module Size:19.7X16mm
