 Factory price Ceramic Fiber Rope for electric kiln

High temperature resistant ceramic fiber rope, kiln ceramic fiber rope roots are made of high quality ceramic fiber l, added light spinning yarn, knitted by special technology. According to different temperatures, different occasions, glass fiber reinforced wire or heat resistant alloy steel wire and other reinforcing materials can be added. They mainly play the role of thermal insulation. They are suitable for mechanical sealing of high temperature and pressure, pumps and valves. Ceramic fiber roots are excellent. Ceramic fibers are woven with good wear resistance and high temperature resistance. It is widely used in high temperature sealing parts such as steel works and petrochemical plants. Ceramic fiber roots can be used as substitutes for asbestos roots.

Ceramic Fiber Rope is a length of fibers, twisted or braided together to improve strength for pulling & connecting and can also be called as fibril or filament. . We provide round rope, square rope and twisted rope. Both kind has two type, glass filament reinforced and stainless stainless steel reinforced.The following is the  description of ceramic fiber twisted  rope:

Description	Ceramic Fiber (SS reinforced)	Ceramic Fiber (Glass fiber reinforced)
Max working temperature ( ℃)	1050	650
Melting point ( ℃)	1760	1760
Density (Kg/m3 )	350-600	350-600
Thermal conductivity rate (W/mK ,ASTM C201, Average 800℃)	0.17	0.17
Loss after firing (%)	5-10	5-10
Chemical composition
Al2O3	46.6	46.6
Al2O3 + SiO2	99.4	99.4
Ceramic Fiber Twisted Rope	Diameter: 3 , 4 , 5 , 6 , 8 , 10 , 12 , 14 ,  15 , 16 , 18 , 20 , 25 , 30 , 35 , 40mm
Ceramic Fiber Round Braid	Diameter: 5 , 6 , 8 , 10 , 12 , 14 , 15 , 16 , 18 , 20 , 25 , 30 , 35 , 40 , 45 , 50mm
Ceramic Fiber Square Braid	5*5 , 6*6 , 8*8 , 10*10 , 12*12 , 14*14 , 15*15 , 16*16 , 18*18 , 20*20 , 25*25 , 30*30 , 35*35 , 40*40 , 45*45 , 50*50mm



 Specifications of ceramic fiber twisted rope: diameter: 3mm to 50mm, and length of the ceramic fiber twisted rope can be according to your requirements, as long as our worker can take them.

 Application of ceramic fiber  rope:(1) High temperature pipe insulation and sealing

                                                              (2) cable insulation coating

                                                              (3) coke oven opening sealing

                                                              (4) pyrolyzer brick wall expansion joints

                                                              (5) electric stove and bake oven’s door sealing, boiler

                                                              (6) high temperature gas seals

                                                              (7) flexible expansion joint connection;



Characteristics of ceramic fiber  rope :(1) Excellent refractoriness

                                                                     (2) Excellent chemical stability and thermal stability

                                                                     (3) Low thermal conductivity, low thermal capacity

                                                                     (4) Resist to external mechanical forces

                                                                     (5) Able to withstand any thermal shock

                                                                    (6) Generate no gaps between modules
