Сварочный аппарат TIG 200A
US $152.00-$161.00
Бтиз инвертор портативный цифровой сварочный аппарат переменного тока 200 А алюминиевый tig
- Категория: Аппарат для аргонно-дуговой сварки >>>
- Поставщик: Wenzhou,Chiefstone,C&T,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-19-2025 | 176.92 $* | 185.54 $* |
| Aug-19-2025 | 175.74 $* | 184.91 $* |
| Jul-19-2025 | 147.36 $* | 154.45 $* |
| Jun-19-2025 | 172.7 $* | 181.78 $* |
| May-19-2025 | 149.86 $* | 156.26 $* |
| Apr-19-2025 | 169.18 $* | 177.96 $* |
| Mar-19-2025 | 167.60 $* | 175.86 $* |
| Feb-19-2025 | 166.29 $* | 174.15 $* |
| Jan-19-2025 | 164.57 $* | 172.18 $* |
Характеристики
Product Description
Support: MMA/TIG/PULSE TIG
HF TIG arc starting
Protection: over-heat and over current.
Material: Stainless steel, Carbon steel and so on
HF TIG arc starting
Protection: over-heat and over current.
Material: Stainless steel, Carbon steel and so on
Technical data
Model | TIG-200P | ||
Input voltage(V) | 1PH AC220V±15% | ||
Input power(KVA) | 4.8 @TIG; 6 @MMA | ||
Input current (A) | 22A@TIG; 27A@MMA | ||
Rated output | 17.6V/190A | ||
Output current(A) | 5-190 | ||
No-load voltage (V) | 56±5 | ||
Duty Cycle% (40℃ 10min) | 190A 30% | ||
104A 100% | |||
Efficiency (%) | 70 | ||
Protection grade | IP21 | ||
Insulation grade | F | ||
Net weight (KG) | 7.1 | ||
Gross weight (KG) | 9.1 | ||
Dimension of machine (mm) | 410*162*305 | ||
Dimension of package (mm) | 480*240*408 | ||
Post-flow time(S) | 0-15 | ||
Up-slope time(S) | 0-15 | ||
Down-slope time(S) | 0-15 | ||
Rated duty cycle | 40% | ||
Efficiency | 70% | ||
Power factor | 0.93 | ||
Insulation grade | F | ||
IP grade | IP21S | ||
Net weight | 14.75Kg | ||
Dimension of machine | 496*212*380 | ||
Related Products
More products
Company Introduction
We, Wenzhou Chiefstone C&T Co., Ltd., also known as Sinoweld Manufacturer and Exporter, is a specialized welding products manufacturer in China. Except for our own products, we have very close and long-term relationship with lots of leading welding products manufacturers in China, which allows us to provide the one-stop service for the majority of welding products.
Our products possess superior quality in compliance with European standard but gives Chinese competitive price. Also, our one-stop shopping service will significantly reduce the time and cost of our customers. We can give the best choice for your demand of welding products. Thus, our company is highly acclaimed in the global market.
In the past over 15 years, we have accumulated valuable experience in producing and exporting welding products. We always help our customer to develop whole series of welding products which are fit for their market. This high-quality service makes our company develop fast with an annual sales volume of more than 10 million dollars.
Except for welding wire, we also provide all kinds of welding products, such as welding machines, air plasma cutting machines, welding or cutting torches, safety supplies, welding consumable materials.
Our products possess superior quality in compliance with European standard but gives Chinese competitive price. Also, our one-stop shopping service will significantly reduce the time and cost of our customers. We can give the best choice for your demand of welding products. Thus, our company is highly acclaimed in the global market.
In the past over 15 years, we have accumulated valuable experience in producing and exporting welding products. We always help our customer to develop whole series of welding products which are fit for their market. This high-quality service makes our company develop fast with an annual sales volume of more than 10 million dollars.
Except for welding wire, we also provide all kinds of welding products, such as welding machines, air plasma cutting machines, welding or cutting torches, safety supplies, welding consumable materials.
FAQ
Q1. Will you deliver the right goods as ordered? How can I trust you?
A: We are a member of Alibaba Trade Assurance which is a new service provided by Alibaba, safeguarding buyer's payment to suppliers to ensure suppliers fulfill their obligations regarding order delivery and product quality. If any different with the contact, customer can get refund from Alibaba.
Q2: What’s the delivery time? Do you have products in stock?
A: The number of stock depends on the demands. After receiving the deposit we will get your goods ready as soon as possible. The delivery time for urgent order is negotiable.
Q3: Could I visit the factory?
A: Yes, please contact us in advance to make an appointment.
Q4: Could I get any sample?
A: Yes, we provide free sample under 3kg because we are confident for the product of our quality!
