can be accept all kinds of wood into smaller and quality wood chips. These chips are raw materials for biomass
industry, fiber and particleboard plants, pulp & paper industry, and also well suitable as fuel in modern heating plants.
We can design different models to meets your requirements .
chips sizes can be adjust from 8mm-50mm :
⇒ ⇒
Working Principle of drum wood chipper:
This machine is made up of feed inlet, upper cover, rotor, hammers, pin roll, outlet, motor, base, fan blower and cyclone etc.
Materials fall into the crushing room through feed inlet. Ther are crushed under the action of high
speed rotating hammer blowing and screener friction, go through the screener hole and discharge
from the outlet unser the action of centrifugal force and flow.
Tech data :
Model
BX-216
BX-218
BX-2113
BX-2113D
BX-2115
BX2116D
Main motor (KW)
55
110
220
250
315
710
Knife Qty(PCS)
2
2
3
3*2
4*2
5*2
Feeder opener (MM)
540x260
680x300
700x400
700x510
1020x510
1250*600
Max. Feeding diameter (MM)
230
260
350
450
450
600
Chips size (MM)
30-45
30-45
30-45
30-45
30-45
30-45
Capacity(T/H)
6-8
8-12
25-30
35-40
55-65
70-90
Weight (KGS)
4680
9100
11800
14000
17000
32000
Feeding conveyor(MM)
6000x550
6000x700
8000x720
10000x720
10000x1100
12000x1250
Outlet conveyor(MM)
10000x600
10000x800
12000x800
12000x800
12000x1200
15000x1250
PRODUCTION DETAILS :
Company Information
Zibo chenze Machinery Co., Ltd is located in zibo city, Shandong province China. Professional manufacturer of machine for biomass energy, forest, agriculture, fishery more than 10 years. Main products: Wood chipper, hammer mill, pellet, debarker, feeding system for boiler, pelleting machine line machinery. We have good sales markets in Europe, North America, Africa, East and South Asia and other countries and regions. We have series high precision test equipment. Each products is strictly inspected while under producing. After finish, all the products will be load tested before delivery. Every machine made by us have it's own file recording all the producing data, parts replace, after sale service and so on. Also have professional engineers and salesmen to serve all of our customs, We always here waiting for an opportunity to serve you.
Packaging & Shipping
Our Services
FAQ
--FAQ before placing order of this machine: A--------What is your raw material and the material diameter(will be check the infeed mouth sizes) B-----The capacity you want(confrim the model ) C-------The final product size requirement (thicknes and the lenght) B-----The driving types: The motor or the diesel drive B-----what's your voltage requirement (we can produce the machine voltage as your requirement)
⇒
⇒
