Вентиляторные катушки охлажденной воды низкое статическое давление 200-1400 куб.

Описание и отзывы

Трекер стоимости

Характеристики

1. Air returning box & filter is optional. Air returning direction can be exchanged between from rear or from bottom, very flexible during the installation;

2. Heavy gauge zinc coated steel drainage pan with good insulation processing, avoiding sweating or corrosion, providing the max. protection;

3. Left side / right side water pipe connection is optional, providing high flexibility and convenience to installation or maintenance;

4. Slim body design, graceful looking and space saving, with body height of 235mm, suitable for some special installing applications with height limit;

5. Standard external static pressure is 12Pa, while higher ESP 30Pa and 50Pa can be also provided, satisfying different installing applications;

6. High efficiency evaporator adopted 3 rows inner-grooved copper tube and top class fan motor, providing better heat exchanging & capacity in cooling / heating, and lower noise;Low noise fan direct driven by single phase, 3 speed permanent split capacitor motor;

7. Four- pipe system type is available (2 pipe for cooling + 2 pipe for heating), suitable for district cooling system;
