Распродажа Профессиональные вращающиеся потенциометры с переключателем по низкой цене 5
- Категория: Potentiometers >>>
- Поставщик: Huizhou,Huiyuansheng,Technology,Electronics,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-20-2025 | 0.84 $* | 0.94 $* |
| Aug-20-2025 | 0.47 $* | 0.19 $* |
| Jul-20-2025 | 0.10 $* | 0.16 $* |
| Jun-20-2025 | 0.52 $* | 0.36 $* |
| May-20-2025 | 0.96 $* | 0.56 $* |
| Apr-20-2025 | 0.0 $* | 0.62 $* |
| Mar-20-2025 | 0.9 $* | 0.49 $* |
| Feb-20-2025 | 0.29 $* | 0.50 $* |
| Jan-20-2025 | 0.88 $* | 0.77 $* |
Характеристики
Product Description
Specification
Electrical characteristics | ||
Total Resistance Range | 500Ω≤TR≤1MΩ | |
Resistance Tolerance | ±20% | |
Resistance Taper | A,B,C taper. | |
Rating Power | B taper: 0.05W ; Other taper: 0.02W | |
Slide Noise | Less than 100mV | |
Residual Resistance Value | Less than 20Ω | |
Dielectric Voltage | For 1 minute or more AC 250V | |
Insulation resistance | More than 100MΩ at DC 250 | |
Tracking Error | -40~0dB ≤ ±3dB | |
Switch Contact Resistance | 200mΩ Max | |
Mechanical characteristics | 280°±10° | |
Total Rotational Angle | 300°±10° | |
Rotational Torque | 20gf.cm〜250 gf.cm | |
Number of click | 1CC,11CC,21CC,41CC | |
Click Torque | 100gf.cm~300 gf.cm | |
Stop Strength | 4kgf.cm | |
Shaft Push & Pull Strength | 10kgf.cm | |
Switch Rotation Angle | 50。±10。 | |
Switch Action | 100~450gf.cm | |
