9 мм углеродная пленка один блок вращающийся горизонтальный
- Категория: Potentiometers >>>
- Поставщик: Huizhou,Huiyuansheng,Technology,Electronics,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-20-2025 | 0.91 $* | 0.32 $* |
| Aug-20-2025 | 0.97 $* | 0.82 $* |
| Jul-20-2025 | 0.34 $* | 0.46 $* |
| Jun-20-2025 | 0.31 $* | 0.61 $* |
| May-20-2025 | 0.60 $* | 0.99 $* |
| Apr-20-2025 | 0.27 $* | 0.7 $* |
| Mar-20-2025 | 0.26 $* | 0.31 $* |
| Feb-20-2025 | 0.99 $* | 0.63 $* |
| Jan-20-2025 | 0.57 $* | 0.41 $* |
Характеристики
Product Description
Specification
Electrical characteristics | ||
Total Resistance Range | 1K≦TR≦1MΩ | |
Resistance Tolerance | ±20% | |
Resistance Taper | A.B.C, taper. | |
Power Rating | B taper: 0.05W ; Other taper: 0.03W | |
Max. operating Voltage | 50V AC/20V DC | |
Slide Noise | Less than 100mV | |
Residual Resistance Value | Less than 20Ω | |
Dielectric Voltage | For 1 minute or more AC 250V | |
Insulation resistance | More than 100MΩ at DC 250 | |
Mechanical characteristics | ||
Total Rotational Angle | 280°±10° | |
Rotational Torque | 10gf.cm~100 gf.cm | |
Stop Strength | 2kgf.cm | |
Push & Pull Strength | 2kgf | |
