Индукционная плавильная печь промежуточной частоты индукционный нагреватель

Индукционная плавильная печь промежуточной частоты индукционный нагреватель

Категория: Промышленные источники питания >>>
Поставщик: Zhengzhou,Kechuang,Electronic,Co.,Ltd.

Цена:*

Количество:

Описание и отзывы

Трекер стоимости

Месяц	Минимальная цена	Макс. стоимость
Sep-16-2025	0.60 $*	0.7 $*
Aug-16-2025	0.85 $*	0.23 $*
Jul-16-2025	0.94 $*	0.1 $*
Jun-16-2025	0.57 $*	0.54 $*
May-16-2025	0.85 $*	0.3 $*
Apr-16-2025	0.97 $*	0.56 $*
Mar-16-2025	0.53 $*	0.43 $*
Feb-16-2025	0.12 $*	0.81 $*
Jan-16-2025	0.56 $*	0.93 $*

Характеристики

Products Description

Model	XZG160	XZG200	XZG250
Input voltage	380V 50HZ	380V 50HZ	380V 50HZ
Input power	160KVA	200KVA	250KVA
Oscillating frequency	10-30Khz	10-30Khz	10-30Khz
Power regulation range	0.1%-100%(Digital regulation)	0.1%-100%(Digital regulation)	0.1%-100%(Digital regulation)
Power Factor	>0.95	>0.95	>0.95
Startup time	0.1sec	0.1sec	0.1sec
Power stability	<±0.1%	<±0.1%	<±0.1%

Features:

The short induction hardening and tempering production line series induction heating machine tools are suitable for induction hardening and tempering of various shaft parts. The machine tool consists of a bed, a transistor heating power supply, a high-temperature tempering power supply, a workpiece loading and unloading assembly, a heating sensor, a tempering sensor, and a cooling system. The PLC control system is used to automatically load, feed, heat, Parameter monitoring and record control. The short bar quenching and tempering production line series induction heating machine has the advantages of fast tempering, less scale, both tempering, and energy saving.

Configuration

1. High-strength welding bed, finishing after aging treatment, stable performance.

2. Workpiece feed motor: variable frequency speed regulation.

3. Temperature measurement: On-line temperature measurement of quenching heating temperature and tempering temperature can realize temperature closed-loop control.

4. Sensor replacement: manual.

5. Adjustable sensor matching.

6, water pressure protection, flow protection, air pressure protection.

7. Control box: Rotary operation box / control cabinet integrated control box.

8. Alarm: sound / light failure alarm, control interface displays alarm and records.

9. Sensor and sprinkler cooling interface: stainless steel / brass quick-change connector.

10. Electric control mode: PLC / touch screen + PLC simple CNC.

11. The machine tool control system can monitor and record various processing parameters, with functions such as historical query, online monitoring, and output printing.

12. Loading and unloading: Fully automatic loading and unloading mechanism can be configured to realize automatic loading and unloading. It can be connected with the upper order automatically for processing.

Product Application

1.Heat treatment for various hardware and tools, such as plier, wrench, hammer, ax,screwing tools.

2.·Heat treatment for various automobile and motorcycle fittings, such as crankshaft,connecting rod, piston pin, chain wheel, aluminum wheel, valve,rock arm shaft,semi drive shaft, small shaft and fork.
3.Heat treatment for various electric tools, such as gear and axes.

4.Heat treatment for machine tools,such as lathe deck and guide rail. 5. Hardening for various hardware metal parts and machined parts, such as shaft,gear chain wheel, cam,chuck and clamp.

6. Heating for hardware molds, such as small-size mold, mold accessory and inner hole of mold.
7. Annealing of various stainless steel products, such as stainless steel basin,annealed and extruded can, annealed folded edge, annealed sink, stainless steel tube, tableware and cup.

·8. Forging of various other metal work pieces, such as round steel, sheet/plate, pipe and others.

Why choose us

Our company

Company profile

Zhengzhou kechuang Electronics Co.,Ltd was established in 31th,August 2001.Kechuang has been developed hundreds of products which has been widely spread and enjoyed by both national and international market since 2001. In 2016,in order to meet the high-end users' demand both in domestic and overseas.We produced much higher performance,higher percision and higher cost-effective intelligent IGBT power supply. Kechuang always has always regard "more energy-saving","more reliable" as the product development direction.Completing the products automatic,intelligent and robotic functions , which leads in the first of national induction heating technology.All of our products and technologies can provide.
