GB/T 10855b аксессуары для высокоскоростного подъемника бесшумная цепь зубьев поддерживающая Звездочка серии
- Категория: >>>
- Поставщик: Ningjin,County,Rongda,Machinery,Manufacturing,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Aug-16-2025 | 1.3 $* | 1.39 $* |
| Jul-16-2025 | 1.56 $* | 1.52 $* |
| Jun-16-2025 | 1.13 $* | 1.58 $* |
| May-16-2025 | 1.82 $* | 1.5 $* |
| Apr-16-2025 | 1.46 $* | 1.25 $* |
| Mar-16-2025 | 1.24 $* | 1.77 $* |
| Feb-16-2025 | 1.97 $* | 1.85 $* |
| Jan-16-2025 | 1.55 $* | 1.14 $* |
Характеристики
silent chain
[ Abstract ] Facing the disadvantage of greater vibration,impact and serious weal"to the inverted tooth
l chain with round pin,a kind of vtwious-pitch inverted tooth chain with rolling pin joint was put forward
the various pitch fundamental of various pitch inverted tooth chain was demonstrated,the meshing charac- teristics between various pitch inverted tooth chain and sprocket were analyzed,and the formulas of separa
tion distance between two hole-centers dunng meshing and the diameter ofreference circle were obtained in the end the reference tooth shape of sprocket was given and the related desigh parameters of the hob used to machining the sprocket were discussed.The results showed that the diameter of the reference circle Was the basic circle in the course ofchain drive and it was determined by the nominal pitch,the structure parameter
of rolling pin and the tooth number of sprockea At the same time it was known that the hob Was a general
one its reference tooth shape was determined by thechain pitch but not the tooth number of the sprocket
Key words:Mechanical manufacture and automation;Various-pitch inverted tooth chain Meshing characteristic Sprocket HobToothed conveyor chain systemic advantage: variable, multifunctional, reliable, durable,Unlimited application opportunities, whether large or small, heavy or light, circular or square, silent chains can be accurate, reliable, accurate, safe, cost-effective transportation of them
chain is ideal for applications where heavy loads (50 to 6000 horsepower) are to be transmitted at moderate to high speeds. It is also ideal where compact design is important. features a pin and rocker joint which reduces friction and provides pitch elongation through its rolling action. This results in a reduction of chordal action and a significant increase in horsepower capacity.Silent chain is an inverted tooth chain offering low to moderate horsepower for applications. The exclusive rocker joint eliminates friction during chain articulation permitting high rotative speed with less wear and heat High speed gear chain (Hawa chain) transmitting power for 50~6000 horsepower, more than 3000 rpm to high speed applications, compact design, it is an ideal transmission chain chain. She is a kind of high precision gear chain belt, both the smooth and compact chain drive, economic life and long. Characterized by a pin shaft hinge and rolling action between tiles to reduce friction and realize pitch elongation, the result is the effective growth of power transmission capacity and reduce the damage. The polygon effect after shot peening and prestressed chain plate processing, which has larger bearing capacity with a power capacity of three. In the times of the silent chain, with high speed range at high speed roller chain work ability decreased sharply, is the ability to continuously improve the Hawar chain. So the Hawa chain has on many occasions beyond all dispute, remarkable advantages Applicable to all applications of high speed prime mover, such as diesel and gas turbine power transmission and so on
Shipping specification
| number of teeth | GBchain NO | pitch | chcain width |
| 17 | SC3 | 9.525mm | 46.5 |
Ning Jin Rong Da Machinery Manufacturing Co.,Ltd
George.Qi
Manager
Add:Daqi lndustrial Park .Ningjin County.Shandong province .China
Tel:+86-534-5535628 Fax:5532182
Mobile:+86- 13706392448
https://rongdaconveyor.en.alibaba.com
www.wirenetbelt.com
