150lb WCB литая сталь

Категория: Запорные клапаны >>>
Поставщик: Tianjin,Tanggu,Jinbin,Valve,Co.,Ltd.

Цена:69,00 $*

Количество:

Описание и отзывы

Трекер стоимости

Месяц	Минимальная цена	Макс. стоимость
Aug-15-2025	88.2 $*	90.14 $*
Jul-15-2025	71.56 $*	72.91 $*
Jun-15-2025	86.91 $*	88.76 $*
May-15-2025	86.52 $*	88.18 $*
Apr-15-2025	68.44 $*	69.56 $*
Mar-15-2025	84.22 $*	86.18 $*
Feb-15-2025	83.62 $*	85.85 $*
Jan-15-2025	83.83 $*	85.39 $*

Характеристики

Product Description

Features

1. The valve uses unilateral forced seal,not only seal reliably, but remove the deposition to achieve sealing.
2.The material of valve body can be cast steel, cast iron, stainless steel etc. to meet the requirements of
corrosion, antiwear and so on
3.The structure is short length, light weight. Easy to install and maintain

Application

1. Mining, washing coal, steel industry - for washing coal pipelines, slurry pipelines, ash pipes;
2. Purification device - for wastewater, mud, dirt and water with suspended solids;
3. Paper industry - for any concentration of pulp, water mixture;
4. Ash power station - for the ash slurry.

Performance specification
Nominal Pressure			150LB
Testing Pressure			Shell: 1.5 times rated pressure, Seat: 1.1 times rated pressure.
Working Temperature			≤425°C
Suitable Media			slurry, water with suspended solids

Material of main parts
Body material					WCB, Stainless steel
Knife material					Stainless steel
Sealing ring material					Teflon, NBR, EPDM,VIiton
Graphite material					Graphite
Stem material					Carbon steel + Cr

Related Products

Company Introduction

Tianjin Tanggu Jinbin Valve Co., ltd with brand THT is large manufacture in China engaged in research, development and production of valves.

Tianjin tanggu jinbin valve co.,ltd was founded in 2004,with registered capital of 113 million yuan,covering an area of 20000 square meters,including 15100 square meters for factories and offices.

THT products have been exported to more than 30 countries and region, such as UK, USA, UAE, Russia, South Korea, region of mid-east, south and south east Asia, South America and Africa!

Our customers

Certifications

Production process

FAQ

Q1: Can I have my own customized product?
A: Yes, your customized requirements for color, size, package, mark, etc.

Q2: How long is your delivery time?
A: Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to
quantity.

Q3: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample for free charge but do not pay the cost of freight.

Q4: What is your terms of payment ?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance,balance before shippment
