UE-PB автомобильной плоский тормозной обнаружения вагон-платформа линия технического осмотра испытательная машина автоматическое
- Категория: Testing Equipment >>>
- Поставщик: Shanghai,Ue,Automotive,Technology,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-17-2025 | 1131.52 $* | 1188.10 $* |
| Aug-17-2025 | 1121.5 $* | 1177.33 $* |
| Jul-17-2025 | 941.78 $* | 988.3 $* |
| Jun-17-2025 | 1102.28 $* | 1157.76 $* |
| May-17-2025 | 960.53 $* | 1008.7 $* |
| Apr-17-2025 | 1083.7 $* | 1137.58 $* |
| Mar-17-2025 | 1074.2 $* | 1128.54 $* |
| Feb-17-2025 | 1064.68 $* | 1117.74 $* |
| Jan-17-2025 | 1055.3 $* | 1108.54 $* |
Характеристики
Product Description
Product Parameters
project | PB-2 | PB-10 |
Maximum allowable wheel load (kg) | 1500 | 5000 |
Braking force measurement range (N) | 0-12500X2 | 0-40000x2 |
Wheel weight measuring range (kg) | 0-1500 | 0-5000 |
Side slip measurement range (m/km) | ±15.0 | ±15.0 |
Dimensions (mm) | 1950x700x65 | 1600x1000x160 |
Equipment weight (kg) | 250 | 475 |
Dimensions of side slide (mm) | 600x500 | 1000x1000 |
structure type | Double board / four board, built-in sliding | Double board, built-in sliding |
Test speed (km/h) | 10-May | 10-May |
voltage | AC 220V, 50Hz, ground | AC 220V, 50Hz, ground |
Features
Features:
The flat-panel car testing platform adopts advanced multi-channel parallel data acquisition technology, which can automatically detect the performance of car braking, slip measurement, axle load and suspension.
Technical characteristics:
1. The surface of the tablet adopts a sticky sand surface
2. It does not need to be a concrete foundation, which occupies a small area and is easy to install and debug;
3. Multi-channel acquisition intelligent version with independent intellectual property rights to ensure the preparation of test data;
4. New windows operation interface, with Chinese graphics, clear display and simple operation;
5. High-efficiency and compound detection function: the data of axle system, brake, slip measurement and suspension system can be tested with only one foot brake operation;
6. The device is available with two tablets and four tablets. The four-plate brake detection platform is suitable for detecting four-wheel drive vehicles.
The flat-panel car testing platform adopts advanced multi-channel parallel data acquisition technology, which can automatically detect the performance of car braking, slip measurement, axle load and suspension.
Technical characteristics:
1. The surface of the tablet adopts a sticky sand surface
2. It does not need to be a concrete foundation, which occupies a small area and is easy to install and debug;
3. Multi-channel acquisition intelligent version with independent intellectual property rights to ensure the preparation of test data;
4. New windows operation interface, with Chinese graphics, clear display and simple operation;
5. High-efficiency and compound detection function: the data of axle system, brake, slip measurement and suspension system can be tested with only one foot brake operation;
6. The device is available with two tablets and four tablets. The four-plate brake detection platform is suitable for detecting four-wheel drive vehicles.
