Характеристики



Product Description

Factory Direct Sale 20FT Food Grade Tank Container







Related Products


Click the product image below to view more products







Parameter


























































































Specifications - T11 Food Grade ISO tank container


Frame Dimensions (L x W x H)


6058 x 2438 x 2591 mm


Nominal Capacity


25000 litre (±0.75%)


Maximum Gross Mass


36000kgs


Tare Mass


3510 kg (± 3%)


Design Temperature (Frame & Tank)


-40 to +130 °C



Material



Tank (Shell & Ends)


SANS 50028-7 Type 1.4402/1.4404 (C≤0.03%)


Frame


SPA-H or equivalent


Insulation


Shell


Rockwool (50kg/m3) 50mm thick on aluminium foil.


Ends


Glasswool (16kg/m3) thickness to suit on aluminium foil.







Steam Heating


6 runs.
110mm width stainless steel 304.
1" BSP inlet, 1" BSP outlet both with captive caps and cable.
4 bar working pressure, 6 bar test with warning decals and markings.
A condensate drain is fitted.



Manhole




500mm low profile, 8 point fixing with Super Tanktyt Lid seal.






Safety Relief
Assembly



1-off.
2½" BSP Supermaxi Highflow relive, without flameproof gauze.
Pressure only set at +4.4 bar (63.8psi).
The assembly is situated off centre on a tangential tank pad.






Air Inlet



assembly




DN 40 ball valve terminating with 1½" BSP connection and cap.
The assembly is situated off centre on a tangential tank pad.






Top Discharge






DN80 stainless steel 316 tank pad with a blind flange.
The assembly is fitted on centre on a horizontal tank pad.




Bottom
Discharge




DN80 45° Univalve Internal Footvalve part no. TBC fitted with an integrated butterfly
valve terminating with a 3" BSP spigot with 3" BSP blind cap and chain.



Document
holder


A clear plastic document holder ø110mm is fitted to the rear right hand side beam.
A drain hole is provided at the lowest point.


Calibration


A calibration plate marked in cm/litres is fitted on the spillbox side wall.
No calibrated stainless steel grade dipstick and bracket fitted.


Design Code


ASME VIII DIV. 1


Approval


IMDG, US DOT CFR 49, RID/ADR, CSC, TC, TIR / Customs, UIC, ISO 1496/3





Company Information


 Workshop


.jpg


Our factory with more than 20 years' experience. Being famous in domestic and foreign countries, we concentrate on tank container and trailer's research and development. Our aim is to provide high quality and low price products for the customer. Experienced and technological team customize the best productions for customers. For any reliability& safety and economic related questions, we all have mature solutions at any time.


Certification




Henan Lishixin Logistics Equipment Co., Ltd is located in Zhengzhou FTA, Henan Province, China, with a registered capital of 3, 500, 000USD. Lishixin is specialized in the R & D, mass production and sales of kinds of the 20FT, 30FT,40FT ISO Storage Tank Containers and Storage Tanks as well as other special logistic Transportation equipments.Based on rich transportation advantages and resource of Central China, Lishixin is committed to supply high quality and cost-effective transportation equipment for clients all over the world.





Packaging & Shipping


 Packing:


There is no package requirement about the 10ft/20ft/30ft/40ft ISO containers.


Delivery:


Generally, we can arrange the delivery of the containers within 25 days after getting your deposit..jpg





FAQ&Purchasing Guide


 Q:What kind of Payment can you accept?


A:T / T and  L/C is all right to us.


Q:Does your iso tank container meet with international requirement?


A:All of our tank container will be approval by BV or LR or CCS and meet with International Standard.


Q:How long will it takes to ship?


A:Around 15-25 working days.


Q: How about the Color , Specific configuration things?


A:It's up to you , most of them are optional and can be changed by your needs.





1.You want to install           tons/cbm?
2.You need         units?


3.The container is used to transport                           ?
4.Certification requirements                           ?


5.Other Special requirements                                      .


If you can provide those information, we will be able to make a quotation for you as soon as possible.





This is Leon from Henan LiShiXin, Contact us to get more details!
