Машина для текстильного окрашивания
Высокотемпературная машина для окрашивания пряжи типа

Высокотемпературная машина для окрашивания пряжи типа

Категория: Машина для текстильного окрашивания >>>
Поставщик: Buentex,Machinery,Trading,Co.,Ltd.

Цена:*

Количество:

Описание и отзывы

Трекер стоимости

Месяц	Минимальная цена	Макс. стоимость
Sep-18-2025	0.76 $*	0.93 $*
Aug-18-2025	0.26 $*	0.78 $*
Jul-18-2025	0.60 $*	0.99 $*
Jun-18-2025	0.94 $*	0.96 $*
May-18-2025	0.37 $*	0.51 $*
Apr-18-2025	0.10 $*	0.44 $*
Mar-18-2025	0.86 $*	0.52 $*
Feb-18-2025	0.61 $*	0.30 $*
Jan-18-2025	0.59 $*	0.83 $*

Характеристики

Product Description

The new weir flow type spray pipes, the dyeing pipes and yarn rotating pipes are combined together, which avoid twisting and knotting. Rewind easily after dyeing, and it has low loss rate.

The water adjuster with special design can adjust water quantity according to the quantity of dyeing yarns, yarn count and sorts.

Compact structure, low bath radio. Save raw materials, reduce the cost.

Maximum work temperature	140 degree
Maximum work pressure	0.4Mpa
Temperature rising rate	about 5℃/min
Temperature dropping rate	about 4℃/min

1. The body of machine and spray pipes are made of high quality corrosion resistant stainless steel.
2. High-performance stainless steel pump.
3. Charging barrel is equipped with functions of stirring, heating, backflowing, and feeding.
4. Reliable PLC program controller.
5. Automatic water level indicator.
6. Equipped with secure operating system.
7. It is convenient to hang yarns on, take out yarns and clean the spray pipes.

Detailed Images

This machine adopts special designed mixed-flow pump which has low energy consumption, high lift and great flow rate. It won’t be affected under high temperature process.

Size Information

Size Chart of This Design

Model	Carrying amount: kg	Power: kw	Dimension: mm	Weight: kg
GSH-1/2X2	10	2.2	2000x2400x1700	1500
GSH-2	20	3	2000x3500x1700	1700
GSH-3	30	4	2200x3500x1700	2100
GSH-4	40	5.5	2340x3800x1870	2500
GSH-6	60	7.5	2600x4200x2050	3800
GSH-6×2	120	15	5800x4200x2050	5400
GSH-8×2	160	22	6040x4300x2160	6300
