ODOELEC HL-5030 250V 10A Регулируемый Поворотный роликовый рычаг запчасти лифта концевой выключатель с
- Категория: Limit Switches >>>
- Поставщик: Yueqing,Wodu,Electric,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-16-2025 | 0.52 $* | 0.73 $* |
| Aug-16-2025 | 0.41 $* | 0.99 $* |
| Jul-16-2025 | 0.85 $* | 0.63 $* |
| Jun-16-2025 | 0.59 $* | 0.35 $* |
| May-16-2025 | 0.66 $* | 0.48 $* |
| Apr-16-2025 | 0.65 $* | 0.13 $* |
| Mar-16-2025 | 0.2 $* | 0.80 $* |
| Feb-16-2025 | 0.24 $* | 0.76 $* |
| Jan-16-2025 | 0.36 $* | 0.36 $* |
Характеристики
Product Description
Limit switch HL-5030 with good price
Feature
Metallic bottom shell
Stainless steel roller, punch and spring
Strong electric proporty 10A 250V for 500.000 times
Characterstics
Protection | IP67 | |
Mechanical | Ten milion times above | |
Electrical | Electric life curve 5mm~0.5m /sl | |
Operation speed | 5mm~0.5m/sl | |
Mechanical | 120 times/m | |
Electrical | 30 times/m | |
Insulation resistance | 100mΩ DC500V | |
Contact resistance | <25mΩ | |
Withstand voltage (50/60HZ 1min) | Between the terminals of same pole | AC 1000V |
Between charged metal parts | AC 1500V | |
Between charged metal parts each terminal | AC 1000V | |
Vibration | Misoperation | 10~15Hz amplitude 1.5mm |
Load | AC 250V 5A | |
AC 380V 5A | ||
AC 125V 3A | ||
AC 250V 3A |
Operating Characteristics
Model | HL-5000 | HL-5030 | HL-5050 | HL-5100 | HL-5200 |
OF (Max) | 750g-cm | 750g-cm | 750g-cm | 750g-cm | 900g-cm |
RF (Min) | 100g-cm | 100g-cm | 100g-cm | 200g | 200g |
PT(Max) | 20° | 20° | 20° | 1.8mm | 1.8mm |
OT (Min) | 22.5° | 22.5° | 22.5° | 2.0mm | 2.0mm |
MD (Max) | 10° | 10° | 10° | 1.2mm | 1.2mm |
EP (Max) | 75° | 75° | 75° | 4.0mm | 4.0mm |
OP (mm) | 95° | 95° | 95° | 5.8mm | 5.8mm |
Model | HL-5220 | HL-5300 | HL-5330 | HL-5381 | HL-5391 |
OF (Max) | 900g-cm | 150g | 150g | 150g | 550g-cm |
RF (Min) | 200g | 30g | 30g | 30g | 100g-cm |
PT(Max) | 1.8mm | 30mm | 30mm | 30mm | 20° |
OT (Min) | 2.0mm | 22.5° | 22.5° | 22.5° | 22.5° |
MD (Max) | 1.2mm | 14° | 14° | 14° | 14° |
EP (Max) | 4.0mm | 20mm | 20mm | 20mm | 75° |
OP (mm) | 5.8mm | 50mm | 50mm | 50mm | 95° |
