Индивидуальный Регулируемый гидравлический цилиндр для фитнеса
US $2.90-$10.00
Прецизионный Электрический цилиндрический приводной линейный винтовой ход 1000 мм для подъемного оборудования китайские
- Категория: Cylinders >>>
- Поставщик: Guangzhou,Nanjie,Machinery,Manufacturing,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-16-2025 | 333.27 $* | 350.80 $* |
| Aug-16-2025 | 330.12 $* | 347.54 $* |
| Jul-16-2025 | 277.56 $* | 291.76 $* |
| Jun-16-2025 | 325.87 $* | 341.9 $* |
| May-16-2025 | 283.13 $* | 297.41 $* |
| Apr-16-2025 | 319.2 $* | 335.81 $* |
| Mar-16-2025 | 316.1 $* | 332.19 $* |
| Feb-16-2025 | 314.23 $* | 330.4 $* |
| Jan-16-2025 | 311.16 $* | 327.30 $* |
Характеристики
Specification
G series electric cylinder, the driving power is DC24V, DC48V, AC220V, AC380V, power 200W-3000W. 400 kg to 5 tons of thrust (the thrust is calculated according to the standard lifting trolley movement speed), the speed is 15mm/S-60mm/S, the installation is simple and fast, only need to connect the power supply and the movement direction control line to operate, the speed and thrust can be custom made.
Cylinder Diameter/mm | 32 | 40 | 50 | 50 | 63 | 63 | 80 | 80 | |||
Power/W | 210 | 300 | 550 | 570 | 1000 | 1500 | 2000 | 3000 | |||
Voltage/V | DC24V/DC48V | DC24V/DC48V | DC24V/DC48V/AC220V | DC24V/DC48V/AC220V | AC220V | ||||||
Rated Speed/mm/s | 21mm/s-50mm/s | 21mm/s-50mm/s | 21mm/s-50mm/s | 21mm/s-50mm/s | 21mm/s-50mm/s | ||||||
Rated Thrust/KG | 450KG, 380KG, 320KG, 250KG, 200KG | 600KG, 500KG, 420KG, 350KG, 250KG | 1100KG, 950KG, 750KG, 650KG, 450KG | 1550KG, 1300KG, 1100KG, 900KG, 650KG | 1900KG, 1600KG, 1300KG, 1100KG, 800KG | 2800KG, 2400KG, 2000KG, 1600KG, 1150KG | 3600KG, 3100KG, 2500KG, 2100KG, 1550KG | 5400KG, 4600KG, 3800KG, 3000KG, 2250KG | |||
Standard Stroke/mm | 5-400mm | 5-400mm | G01: 5-500mm; G02: 800mm, 1000mm | G01: 5-600mm; G02: 800mm, 1000mm | 5-800mm | ||||||
Application
electric cylinder used in Electric Lift Table
electric cylinder used in Stacker
electric cylinder used in Automatic Loading and Unloading Equipment
electric cylinder used in Motion Simulation Platform
electric cylinder used in Packaging Machinery
electric cylinder used in Automated Production Line
Product Description
Certifications
Exhibition
Products Packaging
Company Profile
Guangzhou Nanjie Machinery Manufacturing Co., Ltd.
We are a high-tech company integrating with r&d, design, production, sales and after-sales services.
With the advanced technical level, we quickly moved to the field of industrial intelligence.We have successfully developed and launched a series of electric products, such as ELECTRIC TROLLEY, ELECTRIC STANDING OR SITTING DRIVING FLAT CART, ELECTRIC LIFTING TROLLEY, INTELLIGENT DRIVERLESS ALL-TERRAIN VEHICLE, DISINFECTION ROBTO, ELECTRIC CYLINDER LINEAR ACTUATOR and so on.
Our products widely used in bank vault, hospital pharmacy and laundry, airport or station logistics, hotel rooms and laundry, warehouse logistics, library or archives, administrative organization logistics, factory production line and other industries.
With skills as the core, quality as the life, and customers as the god, we are dedicated to providing customers with efficient, safe, environmentally friendly and intelligent electrical equipment. Super first-class product quality and technical services have won praise from users.
We continuously exchanges and cooperates with domestic scientific research institutions and colleges to develop and design new product together. Our innovation ability keeps improving and we have become the technology innovation leader in the domestic electric equipment industry.
We are a high-tech company integrating with r&d, design, production, sales and after-sales services.
With the advanced technical level, we quickly moved to the field of industrial intelligence.We have successfully developed and launched a series of electric products, such as ELECTRIC TROLLEY, ELECTRIC STANDING OR SITTING DRIVING FLAT CART, ELECTRIC LIFTING TROLLEY, INTELLIGENT DRIVERLESS ALL-TERRAIN VEHICLE, DISINFECTION ROBTO, ELECTRIC CYLINDER LINEAR ACTUATOR and so on.
Our products widely used in bank vault, hospital pharmacy and laundry, airport or station logistics, hotel rooms and laundry, warehouse logistics, library or archives, administrative organization logistics, factory production line and other industries.
With skills as the core, quality as the life, and customers as the god, we are dedicated to providing customers with efficient, safe, environmentally friendly and intelligent electrical equipment. Super first-class product quality and technical services have won praise from users.
We continuously exchanges and cooperates with domestic scientific research institutions and colleges to develop and design new product together. Our innovation ability keeps improving and we have become the technology innovation leader in the domestic electric equipment industry.
Why Choose Us
1. OEM and ODM are available.
2. We will offer you sample.
3. We will reply your inquiry in 1 hours.
4. 1 year warranty period, besides we offer online technology support.
5. We have over 30 patents, CE certificate and ISO certificate.
2. We will offer you sample.
3. We will reply your inquiry in 1 hours.
4. 1 year warranty period, besides we offer online technology support.
5. We have over 30 patents, CE certificate and ISO certificate.
FAQ
Q1. What is your terms of packing?
A: Generally, we pack our goods in neutral white boxes and brown wooden cartons. If you have legally registered patent, we can pack the goods in your branded boxes after getting your authorization letters.
Q2. What is your terms of payment?
A: T/T 30% as deposit, and 70% before shipping. We'll show you the photos of the products and packages before you pay the balance.
Q3. What is your terms of delivery?
A: EXW, FOB, CFR, CIF, DDU.
Q4. How about your delivery time?
A: Generally, it will take 15 days to produce the products, and 30 days of shipping time by sea. The specific delivery time depends on the items and the quantity of your order.
Q5: How is the warranty system?
A: 1 year.
Q6. Can you produce according to the samples?
A: Yes, we can produce by your samples or technical drawings. We can build the molds and fixtures.
Q7. What is your sample policy?
A: We can supply the sample, but the customers have to pay the sample cost and the courier cost.
Q8. Do you test all your goods before delivery?
A: Yes, we have 100% test before delivery.
Q9: How do you make our business long-term and good relationship?
A:1. We keep good quality and competitive price to ensure our customers benefit ;
2. We respect every customer as our friend and we sincerely do business and make friends with them, no matter where they come from.
A: Generally, we pack our goods in neutral white boxes and brown wooden cartons. If you have legally registered patent, we can pack the goods in your branded boxes after getting your authorization letters.
Q2. What is your terms of payment?
A: T/T 30% as deposit, and 70% before shipping. We'll show you the photos of the products and packages before you pay the balance.
Q3. What is your terms of delivery?
A: EXW, FOB, CFR, CIF, DDU.
Q4. How about your delivery time?
A: Generally, it will take 15 days to produce the products, and 30 days of shipping time by sea. The specific delivery time depends on the items and the quantity of your order.
Q5: How is the warranty system?
A: 1 year.
Q6. Can you produce according to the samples?
A: Yes, we can produce by your samples or technical drawings. We can build the molds and fixtures.
Q7. What is your sample policy?
A: We can supply the sample, but the customers have to pay the sample cost and the courier cost.
Q8. Do you test all your goods before delivery?
A: Yes, we have 100% test before delivery.
Q9: How do you make our business long-term and good relationship?
A:1. We keep good quality and competitive price to ensure our customers benefit ;
2. We respect every customer as our friend and we sincerely do business and make friends with them, no matter where they come from.
