Мощный шлифовальный станок 3100 кВт M2120A с размером станка 1450*1470 *
- Категория: Internal Grinding Machines >>>
- Поставщик: Shenzhen,Shengmingfa,Technology,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-17-2025 | 0.31 $* | 0.26 $* |
| Aug-17-2025 | 0.62 $* | 0.94 $* |
| Jul-17-2025 | 0.33 $* | 0.14 $* |
| Jun-17-2025 | 0.95 $* | 0.31 $* |
| May-17-2025 | 0.82 $* | 0.89 $* |
| Apr-17-2025 | 0.47 $* | 0.56 $* |
| Mar-17-2025 | 0.78 $* | 0.34 $* |
| Feb-17-2025 | 0.68 $* | 0.42 $* |
| Jan-17-2025 | 0.17 $* | 0.53 $* |
Характеристики
Product Description
Feed and dressing movements are controlled by means of two independent driving system. Size metric grinding is adopted.
Feed movement can be carried out both manually and hydraulically.Because the machine is equipped with jumping mechanism, it is unnecessary to reset the tool after returning grinding wheel for measurement or dressing.The machine is equipped with a hydraulic switch valve to ensure safety during loading and unloading workpieces.
A grinding spindle with 18000r/min is optional for grinding bore diameter ranging from 20 to 50 mm
Machine Model | M2120A | |
Dia.to be ground(mm) | 50-200 | |
Max. depth to be ground(mm) | 200 | |
Rotating dia.(mm) | inner hood (mm) | 400 |
Outer hood (mm) | 600 | |
Max. rotating angle of machine head (°) | 30° | |
Workpieces speed (r/min) | 100-500 (stepless) | |
Wheel speed (r/min) | 4000-6000\\8000-11000 | |
Machine total power (kw) | 8.6 | |
Workpiece motor power (kw) | 2.2 | |
Wheel motor power (kw) | 4 | |
Machine size (mm) | 3100*1450*1470 | |
Machine weight (kg) | 3400 | |
Machine power source | 3N-50HZ 380V | |
Working accuracy | Bore roundness (mm) | 0.003 |
Bore cylindricity(mm) | 0.008 | |
Bore surface roughness | 0.63Ra | |
Company Information
Shenshika is Located in Shenzhen City of China, we are the exclusive sole representative agent in China for Injection Machine, CNC, Grinding Machine, Milling Machine,EDM spark machine and Drilling Machine etc.. And selling the same second-hand machines to over 30 countries with 100% guaranteed quality and good reputation since 2010. We usually buy in secondhand machines from bankcrupt/ closed-down factories. We have a mature and stable supply chain in China and Hongkong. We exam machines and control quality very strictly. We swear that every machine you'll receive from us can work well in good condition..
