Product Description


Autoclave For Composites For Sale
Product Introduction:
The composite material autoclave mainly used to the composite materials military products,space vehicle by high temperature and high pressure.It also can be applied to strengthen the carbon fiber,glass fiber,boron fiber and ect.More over,it also can change the metallic/nonmetallic joint components,such as airplane door,fairing,airborne radar and so on.



TinWing can provide a key solution according to the specific needs of your process or equipment control for you . Engineers ,electrical engineers as well as service team in TinWing control department are experts in both the full system and the upgrading . When you purchase a TinWing control system meaning that you received a key overall solution .


System Composition:
Autoclave is able to achieve temperature, pressure, vacuum , cooling, process parameters such as the timing of the cycle , real-time online control system equipment, consisting mainly consists of the following subsystems :
( 1 ) tank : the tank , the tank door mechanism , motor temperature , duct board insulation layer to form a high pressure , high temperature of the tank ;
( 2 ) Safety interlock device: automatic interlock by the pressure , manual interlocking , high pressure alarm device components.
( 3 ) Open the door device: Open the door manual electric dual-use design , the normal power outage shut down the tank door opens, the door is the most advanced way .
( 4 ) sealing device : cans door using silicone inflatable seals , high pressure 400 °. Never worn.
( 5 ) Pressure system : the compressor , tank , pressure control valves, piping, pressure transmitters and pressure gauges and other components transmission and control systems ;





( 6 ) Heating system: stainless steel heating pipes , heat fan , duct board , insulation , temperature control system components, the maximum temperature of the heating power to meet the requirements of the cavity and the heating rate requirements ;
( 7 ) Temperature cycling system: circulating fan , the air guide plate , the shroud component , accelerate heat transfer and circulation , a uniform temperature field ;
( 8 ) Vacuum system: vacuum pumps, piping, vacuum gauge and vacuum valve composed for the package provides composite preform vacuum conditions ;
( 9 ) Automatic control system: Siemens PLC control system, pressure , temperature, cooling the whole process parameters such as high-precision control and real-time recording .



  • Product Superiority

1.Powerful database system
2.Efficient network access
3.Control of multiple devices and stable dual computer redundancy structure
4.Recipe management efficient





Size Information


TYPE
1600*2500
2000*3500
2500*5500
3000*6500
3500*7500
4000*8500
MWP
3.8MPa
1.0MPa
1.0MPa
1.5MPa
1.2MPa
1.2MPa
Design Pressure
4.0MPa
1.2MPa
1.2MPa
1.6MPa
1.3MPa
1.3MPa
Maximum Working Temperature

0-400

0-250

250

0-250

250

250
Design Temperature
420
270
270
270
270
270
Heat Insulation Form
Internal insulation, 200mm
Internal insulation, 150mm
Internal insulation, 150mm
Internal insulation, 150mm
Internal insulation, 150mm
Internal insulation, 100-150mm
Total Power
60kw
90kw
210kw
330kw
510kw
780kw


Application Fields


Aerospace Industry
Automobile Industry
The New Field Of Energy


Glass Industry
Ballistics Industry
The Nuclear Industry
