Комплект панелей солнечных водонагревателей RV солнечные панели для горячей воды система нагрева дома
- Категория: Electric Water Heaters >>>
- Поставщик: Wuxi,Longmax,Technology,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-17-2025 | 536.45 $* | 563.67 $* |
| Aug-17-2025 | 531.21 $* | 558.48 $* |
| Jul-17-2025 | 446.48 $* | 468.32 $* |
| Jun-17-2025 | 522.66 $* | 548.53 $* |
| May-17-2025 | 455.25 $* | 478.17 $* |
| Apr-17-2025 | 513.70 $* | 539.47 $* |
| Mar-17-2025 | 509.55 $* | 534.42 $* |
| Feb-17-2025 | 504.16 $* | 529.64 $* |
| Jan-17-2025 | 500.28 $* | 525.22 $* |
Характеристики
Product Paramenters
Model | GF-50L(PV） | GF-60L(PV） | GF-80L(PV） | GF-100L(PV） | |||||||||||
Volume | 50L | 60L | 80L | 100L | |||||||||||
TYPE | Wall Mounted | Wall Mounted | Wall Mounted | Wall Mounted | |||||||||||
Panel power | 550W | 550W | 825W | 1000W | |||||||||||
DC Voltage V | 1-150V | 1-150V | 1-150V | 1-150V | |||||||||||
DC Power W | 1-1200W | 1-1200W | 1-1200W | 1-1200W | |||||||||||
AC Power W | 2000W | 2000W | 2000W | 2000W | |||||||||||
AC Voltage V | 220V | 220V | 220V | 220V | |||||||||||
Controlling Method | Computer | Computer | Computer | Computer | |||||||||||
AC Temperature adjustment range | 30-75℃ | 30-75℃ | 30-75℃ | 30-75℃ | |||||||||||
DC Controller | 65℃ ON 75℃ OFF | 75℃OFF | 65℃ ON 75℃ OFF | 75℃OFF | 65℃ ON 75℃ OFF | 75℃OFF | 65℃ ON 75℃ OFF | 75℃OFF | |||||||
DC Heating tube material | 216 stainless steel | 216 stainless steel | 216 stainless steel | 216 stainless steel | |||||||||||
AC controller（Thermostat） | NTC | NTC | NTC | NTC | |||||||||||
Material of AC heating pipe | 216 stainless steel | 216 stainless steel | 216 stainless steel | 216 stainless steel | |||||||||||
Tank material surface treatment | Cold plate enamel | Cold plate enamel | Cold plate enamel | Cold plate enamel | |||||||||||
Inner steel plate thickness | 1.8MM | 1.8MM | 1.8MM | 1.8MM | |||||||||||
Warranty | 5 years | 5 years | 5 years | 5 years | |||||||||||
Foaming thickness | 25MM | 25MM | 25MM | 25MM | |||||||||||
Specification of magnesium bar | φ16*110 | φ16*110 | φ16*110 | φ16*110 | |||||||||||
Heater Surface treatment | Cold-rolled sheet sprayed with matte paint | Cold-rolled sheet sprayed with matte paint | Cold-rolled sheet sprayed with matte paint | Cold-rolled sheet sprayed with matte paint | |||||||||||
Cover material surface treatment | PT | PT | PT | PT | |||||||||||
Plug power wire | With false negatives 10A | With false negatives 10A | With false negatives 10A | With false negatives 10A | |||||||||||
Packing | Carton packing and plastic sealing | Carton packing and plastic sealing | Carton packing and plastic sealing | Carton packing and plastic sealing | |||||||||||
Waterproof level | IPX4 | IPX4 | IPX4 | IPX4 | |||||||||||
Product size Heater (mm) | φ390*785 | ø390×795 | ø440×780 | φ470*915 | |||||||||||
Packing Size Heater (mm) | 525×455×875mm | 525×455×850mm | 575×525×823mm | 598×535×985mm | |||||||||||
Product size of 2 PV panels(mm) | 992*1650*35/per panel | 992*1650*35/per panel | 992*1650*35/per panel | 992*1650*35/per panel | |||||||||||
Packing size of 2 PV panels(mm) | 992*1650*35/per panel | 992*1650*35/per panel | 992*1650*35/per panel | 992*1650*35/per panel | |||||||||||
Panels+Heater Net weight(kg) | 17KG/17.5 | 17KG/21.5 | 17KG/22 | 17KG/23 | |||||||||||
Panels+Heater Gross weight(kg) | 17KG/20.5 | 17KG/23.7 | 17KG/24 | 17KG/25 | |||||||||||
Accessories | One electric water heater, one manual, one safety valve, one pair of MC4 joints, one drain pipe, one remote control, one M6 expansion bolt, one M10 expansion bolt with hook | ||||||||||||||
Lead time | 14-20 days | 14-20 days | 14-20 days | 14-20 days | |||||||||||
Certifications | CE/3C | CE/3C | CE/3C | CE/3C | |||||||||||
FOB Shanghai PRICES in USD | 450.5 | 495.5 | 555.5 | 615.5 | |||||||||||
Advantages description: | 1 level 1 energy efficiency technology, comprehensive energy improvement; 2. Built-in anti-electric wall, safety protection; 3. 2000/3000 two levels power conversion; 4. White LED large screen display, advanced touch control function; 5. Electronic remote control, intelligent and convenient; 6. 2000W, 3000W dual-group dynamic heating engine, comfortable and fast; 7. Capacity expansion function to meet users' high temperature needs; 8. Appointment timing, self-defined heating time. | ||||||||||||||
Product Description
Save 1,472 kWh every year!
Calculated on 20% rainy days and a family of 5.
Starting voltage 1V DC!
Good weak light utilization!
Can provide hot water in really cold days, as long as there's sunshine!
Because we transport solar power only by cables, and store hot water indoor.
Even there's NO sunshine, you can also use AC electricity supply to heat!
DC/AC Auto or Manual Switch!
Become A Distributor
We can do your local safety certification if you become our distributor.
Packing & Delivery
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
